End of Life May-2021
RJU
www.vishay.com
Vishay Dale
Metal Oxide Resistors, Special Purpose, High Power,
Ultra High Value
FEATURES
•
•
•
•
•
Wattages to 400 W at +25 °C
Derated to 0 at +230 °C
Available
Voltage testing to 100 kV
Tolerance: ± 1 %; ± 2 %; ± 5 %; ± 10 %
Two terminal styles, style 3 - tab terminal and
style 4 - ferrule terminal
• TCR: ± 200 ppm/°C and ± 100 ppm/°C
Available
available, measured between +25 °C and
+125 °C
• Coating: blue flameproof
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Note
*
This datasheet provides information about parts that are
RoHS-compliant and / or parts that are non RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information / tables in this datasheet for details
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL
MODEL
HISTORICAL
MODEL
POWER RATING MAXIMUM WORKING
P
25 °C
VOLTAGE
(1)
W
V
40
25K
50
33K
70
40K
95
35K
95
35K
140
65K
140
65K
275
90K
275
90K
150
40K
150
40K
400
125K
400
125K
RESISTANCE
RANGE
Ω
1K to 1G
1K to 1G
1K to 1G
1K to 1G
1K to 1G
1K to 1G
1K to 1G
100K to 1G
100K to 1G
100K to 1G
100K to 1G
100K to 1G
100K to 1G
TOLERANCE
±%
1, 2, 5, 10
1, 2, 5, 10
1, 2, 5, 10
1, 2, 5, 10
1, 2, 5, 10
1, 2, 5, 10
1, 2, 5, 10
1, 2, 5, 10
1, 2, 5, 10
1, 2, 5, 10
1, 2, 5, 10
1, 2, 5, 10
1, 2, 5, 10
TEMPERATURE
COEFFICIENT
± ppm/°C
100, 200
100, 200
100, 200
100, 200
100, 200
100, 200
100, 200
100, 200
100, 200
100, 200
100, 200
100, 200
100, 200
RJU040
RJU-40
RJU050
RJU-50
RJU070
RJU-70
RJU095
RJU-95
RJU095..1
RJU-95-1
RJU140
RJU-140
RJU140..1
RJU-140-1
RJU275
RJU-275
RJU275..1
RJU-275-1
RJU150
RJU-150
RJU150..1
RJU-150-1
RJU400
RJU-400
RJU400..1
RJU-400-1
Notes
• All resistance values are calibrated at 100 V
DC
. Calibration at other voltages upon request
(1)
Continuous working voltage shall be
P
x
R
or maximum working voltage, whichever is less
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: RJU0952M50KKF071 (preferred part numbering format)
R
J
U
0
9
5
2
M
5
0
K
K
F
0
7
1
PACKAGING
SPECIAL
Blank = Standard
(Dash number)
(Up to 3 digits)
From
1 to 999
as applicable
1
= Ferrule terminal
GLOBAL MODEL
(see Standard Electrical
Specification table)
RESISTANCE VALUE
K
= kΩ
M
= MΩ
G
= GΩ
1K00
= 1.0 kΩ
10M0
= 10 MΩ
1G00
= 1.0 GΩ
TOLERANCE CODE
F
=
±
1%
G
=
±
2%
J
=
±
5%
K
=
±
10 %
TEMP. COEFFICIENT
K
= 100 ppm
N
= 200 ppm
E07=
Lead (Pb)-free, foam
F07
=Tin/lead, foam
Historical Part Number: RJU-95-12M50KK (will continue to be accepted)
RJU-95-1
HISTORICAL MODEL
2M50
RESISTANCE VALUE
K
TOLERANCE CODE
K
TEMP. COEFFICIENT
F07
PACKAGING
Note
• For additional information on packaging, refer to the Through Hole Resistor Packaging document (www.vishay.com/doc?31544)
Revision: 11-Jan-2021
Document Number: 31035
1
For technical questions, contact:
ff2aresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
