80CPQ020

Description
Schottky (diode and rectifier) ​​80 amp 20 volt common cathode
CategoryDiscrete semiconductor    diode
File Size99KB,6 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

80CPQ020 Online Shopping

Suppliers Part Number Price MOQ In stock
80CPQ020 - - View Buy Now

80CPQ020 Overview

Schottky (diode and rectifier) ​​80 amp 20 volt common cathode

80CPQ020 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerVishay
Parts packaging codeTO-247AC
package instructionR-PSFM-T3
Contacts3
Reach Compliance Codeunknow
ECCN codeEAR99
Samacsys DescriptiDIODE ARRAY SCHOTTKY 20V TO247AC
Other featuresFREE WHEELING DIODE, HIGH RELIABILITY
applicationHIGH POWER
Shell connectionCATHODE
ConfigurationCOMMON CATHODE, 2 ELEMENTS
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)0.55 V
JEDEC-95 codeTO-247AC
JESD-30 codeR-PSFM-T3
Maximum non-repetitive peak forward current2200 A
Number of components2
Phase1
Number of terminals3
Maximum operating temperature150 °C
Minimum operating temperature-55 °C
Maximum output current40 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum repetitive peak reverse voltage20 V
surface mountNO
technologySCHOTTKY
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
Base Number Matches1
80CPQ020
Vishay High Power Products
Schottky Rectifier, 2 x 40 A
FEATURES
Base
common
cathode
2
TO-247AC
1
3
Anode
Anode
2
1
2
Common
cathode
150 °C T
J
operation
Center tap configuration
Optimized for 3.3 V application
Ultra low forward voltage drop
High frequency operation
Guard ring for enhanced ruggedness and long term
reliability
• High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
• Designed and qualified for industrial level
DESCRIPTION
PRODUCT SUMMARY
I
F(AV)
V
R
I
RM
2 x 40 A
20 V
1100 mA at 125 °C
This center tap Schottky rectifier has been optimized for ultra
low forward voltage drop specifically for 3.3 V output power
supplies. The proprietary barrier technology allows for
reliable operation up to 150 °C junction temperature. Typical
applications are in parallel switching power supplies,
converters, reverse battery protection, and redundant power
subsystems.
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
I
F(AV)
V
RRM
I
FSM
V
F
T
J
t
p
= 5 µs sine
40 Apk, T
J
= 150 °C (per leg)
Range
CHARACTERISTICS
Rectangular waveform
VALUES
80
20
2200
0.32
- 55 to 150
UNITS
A
V
A
V
°C
VOLTAGE RATINGS
PARAMETER
Maximum DC reverse voltage
SYMBOL
V
R
80CPQ020
20
UNITS
V
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Maximum average
forward current
per leg
per device
SYMBOL
I
F(AV)
TEST CONDITIONS
50 % duty cycle at T
C
= 138 °C, rectangular waveform
5 µs sine or 3 µs rect. pulse
I
FSM
E
AS
I
AR
10 ms sine or 6 ms rect. pulse
T
J
= 25 °C, I
AS
= 6 A, L = 1.5 mH
Current decaying linearly to zero in 1 µs
Frequency limited by T
J
maximum V
A
= 1.5 x V
R
typical
Following any rated
load condition and with
rated V
RRM
applied
VALUES
40
80
2200
500
27
6
mJ
A
A
UNITS
Maximum peak one cycle
non-repetitive surge current per leg
Non-repetitive avalanche energy per leg
Repetitive avalanche current per leg
Document Number: 93394
Revision: 16-Oct-08
For technical questions, contact: diodes-tech@vishay.com
www.vishay.com
1
