Corcom Product Guide
Catalog: 1654001
Issue Date: 08.2010
High Performance RFI Filters for Switching Power Supplies
G Series
UL Recognized
CSA Certified
VDE Approved
10EG1 / 10VG1
1
RFI Power Line Filters
6EG1 / 6VG1
G Series
• Designed to provide excellent attenuation for
most digital electronics equipment
• Broad frequency range of performance from
20kHz to 30MHz
• Size and cost-effective solution
• Designed to help comply with EN55022 Level A
and FCC Part 15J Class B
Specifications
Maximum leakage current each Line to Ground:
EG Models
VG Models
@ 120 VAC 60 Hz:
@250 VAC 50 Hz:
Hipot rating (one minute):
Line to Ground:
Line to Line:
Rated Voltage (max):
Operating Frequency:
Rated Current:
.30 mA
.50 mA
1.2 mA
2.0 mA
2250 VDC
1450 VDC
250 VAC
50/60 Hz
6 & 10A
Ordering Information
10 E G 1
Input / Output Style
1 – .250 [6.3] spade terminals
G Series
Leakage current designation
E – Low leakage
(<0.5 mA)
V – Standard
Current Rating
6 or 10A
Operating Ambient Temperature Range
(at rated current Ir):
-10°C to +40°C
In an ambient temperature (Ta) higher than +40°C
the maximum operating current (Io) is calculated as
follows: Io = Ir
√(85-Ta)/45
Electrical Schematics
6EG1 & 6VG1
LINE
LOAD
Available Part Numbers
6EG1
10EG1
6VG1
10VG1
10EG1 & 10VG1
LINE
LOAD
35
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
tycoelectronics.com/help
corcom.com
Corcom Product Guide
Catalog: 1654001
Issue Date: 08.2010
High Performance RFI Filters for Switching Power Supplies
(continued)
G Series
Case Styles
Case Dimensions
Part No.
6EG1/VG1
A
(max)
B
(max)
C
(max)
± .015
± .38
D
E
(max)
B
10EG1/VG1
3.56
90.4
4.69
119.1
2.15
54.6
2.27
57.7
1.56
39.6
1.8
45.7
2.938
74.63
4.063
103.2
3.38
85.8
4.47
113.5
D
E
A
Typical Dimensions:
Line/Load Terminals (4):
Ground Terminal (1):
Mounting Holes (2):
C
.250 [6.3] with .07 [1.8] Dia. hole
.250 [6.3] with .07 x .16 [1.8
x 3.8]
slot
.188 [4.78] Dia.
Performance Data
Typical Insertion Loss
Measured in closed 50 Ohm system
Common Mode / Asymmetrical (L-G)
Differential Mode / Symmetrical (L-L)
6EG1
db
100
90
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
30
Frequency in MHz
6VG1
db
100
90
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
30
Frequency in MHz
10EG1
db
100
90
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
30
Frequency in MHz
10VG1
db
100
90
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
30
Frequency in MHz
Minimum Insertion Loss
Common Mode / Asymmetrical (Line to Ground)
Current
Frequency – MHz
Rating .01 .05 .07 .1 .15 .5
1
5
EG Models
6A
10A
VG Models
6A
10A
4
5
18
10
21
24
25
37
30
50
56
72
55
70
53
70
45
60
45
60
6
8
19
10
23
15
25
18
29
42
48
64
44
65
43
65
40
60
40
60
10
30
Differential Mode / Symmetrical (Line to Line)
Current
Frequency – MHz
Rating .01 .05 .07 .1 .15 .5
1
5
EG Models
6A
10A
VG Models
6A
10A
4
5
7
5
7
7
26
26
39
39
67
65
75
60
68
60
55
70
55
70
4
5
6
5
10
5
24
26
37
40
66
65
75
65
72
60
50
70
50
70
10
30
36
