PR1000R THRU PR1800R
PHOTOFLASH RECTIFIER
Reverse Voltage -
1000 to 1800 Volts
Forward Current -
0.5 Ampere
Features
Fast switching
Low leakage
Low forward voltage drop
High current capability
High surge capability
High reliability
Mechanical Data
Case:
Molded plastic, R-1
Epoxy:
UL94V-0 rate flame retardant
Lead:
MIL-STD-202E method 208C guaranteed
Mounting Position:
Any
Weight:
0.007 ounce, 0.20 gram
DIM ENSIONS
DIM
A
B
C
D
inches
Min.
0.114
0.095
0.020
1.000
Max.
0.138
0.099
0.024
-
Min.
2.9
2.42
0.5
25.40
mm
Max.
3.5
2.51
0.6
-
Note
Maximum Ratings and Electrical Characteristics
Ratings at 25
ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Symbols
PR1000R
PR1200R
PR1400R
PR1600R
PR1800R
Units
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
0.375" (9.5mm) lead length at T
A
=55
Peak forward surge current
8.3mS single half sine-wave superimposed
on rated load (MIL-STD-750D 4066 method)
Maximum instantaneous forward voltage at 0.5A DC
Maximum DC reverse current
at rated DC blocking voltage
T
A
=25
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
T
rr
C
j
T
J
, T
STG
1000
700
1000
1200
840
1200
1400
980
1400
500
30.0
1.5
5.0
300.0
10
-65 to +175
1600
1120
1600
1800
1260
1800
Volts
Volts
Volts
mAmps
Amps
Volts
A
nS
F
Maximum reverse recovery time (Note 1)
Typical junction capacitance (Note 2)
Operating and storage temperature range
Notes:
(1) Test conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A
(2) Measured at 1.0MHz and applied reverse voltage of 4.0 volts
1
