Part Number:
Status:
Overview:
Description:
0850150335
Active
din_41612
2.54mm (.100") Pitch DIN 41612 Header, Through Hole, Vertical, Press-fit Style R, 1µm
(40µ") Gold (Au), 128 Circuit
Documents:
Drawing (PDF)
Product Specification PS-85013-0002 (PDF)
RoHS Certificate of Compliance (PDF)
Series
Agency Certification
CSA
UL
LR19980
E29179
image - Reference only
EU RoHS
China RoHS
Compliance Status
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
General
Product Family
Series
Application
Comments
Component Type
Overview
Product Name
Style
Backplane Connectors
85015
Backplane
"R" at Style Represents Vertical Male DIN Connectors
PCB Header
din_41612
IEC 603-2/DIN 41612
R
Physical
Circuits (Loaded)
Circuits (maximum)
Circuits Detail
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Guide to Mating Part
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length (in)
PC Tail Length (mm)
PCB Locator
PCB Retention
PCB Thickness Recommended (in)
PCB Thickness Recommended (mm)
Packaging Type
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Pitch - Term. Interface (in)
Pitch - Term. Interface (mm)
Polarized to PCB
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
128
128
Rows A, B, C & D
Gray
400
Yes
94V-0
No
Yes
Phosphor Bronze
Gold
Tin
32
Open Pin Field
4
Vertical
0.787 In
2.00 mm
No
Yes
0.063 In, 0.157 In
1.60 mm, 4.00 mm
Carton
0.100 In
2.54 mm
0.100 In
2.54 mm
Yes
No
No
-55°C to +125°C
Search Parts in this Series
85015Series
Mates With
85042 DIN 41612 Receptacle . 85052 DIN
41612 Header
Use With
85089-1081 Press-in Tool
Termination Interface: Style
Through Hole - Compliant Pin
Electrical
Current - Maximum per Contact
Data Rate
Voltage - Maximum
1A
622.0 Mbps
250V AC (RMS)
Material Info
Reference - Drawing Numbers
Product Specification
Sales Drawing
PS-85013-0002
SDA-85015-0335
