Type 8AG / 8AP
8AGD0202
1/4 x 1 inch Glass Tube
Fast Blow Fuse Series
Catalog
Number
Ampere
Rating
Typical
Volt-drop Melting I
2
T Melting I
2
T Maximum
Cold
@100%
In
< 10 mSec
@10
In
Power
Resistance
Dissipation
(ohm)
(Volt) max. (A
2
Sec)
(A
2
Sec)
(W)
8AG (P) 80
8AG (P) 100
80mA
100mA
125mA
150mA
200mA
250mA
350mA
500mA
750mA
1A
1.25A
1.5A
2A
2.5A
3A
3.5A
4A
5A
6A
7A
13.6
10.3
7.0
5.3
4.0
3.1
2.0
0.34
0.19
0.14
0.10
0.08
0.06
0.04
0.03
0.027
0.023
0.017
0.013
0.011
3.71
3.28
3.67
3.24
2.86
2.53
2.10
0.217
0.207
0.202
0.197
0.193
0.188
0.184
0.179
0.177
0.175
0.171
0.167
0.165
0.0013
0.002
0.004
0.007
0.013
0.023
0.054
0.23
0.69
1.20
2.09
3.6
6.4
11.1
19.3
25.5
34
59
102
135
0.001
0.002
0.003
0.006
0.011
0.019
0.046
0.22
0.68
1.21
2.13
3.8
6.7
11.8
20.9
27.8
37
65
116
154
0.43
0.48
0.68
0.72
0.84
0.93
1.10
0.16
0.23
0.30
0.37
0.44
0.55
0.68
0.81
0.92
1.03
1.26
1.49
1.71
Electrical Characteristics
(UL/CSA STD. 248-14)
Testing
current
100%
135%
200%
Blow Time
Minimum
4 Hrs.
N/A
N/A
Maximum
N/A
1 Hr
5 sec
8AG (P) 125
8AG (P) 150
8AG (P) 200
8AG (P) 250
8AG (P) 350
8AG (P) 500
8AG (P) 750
8AG (P) 1
8AG (P) 1.25
8AG (P) 1.5
8AG (P) 2
8AG (P) 2.5
8AG (P) 3
8AG (P) 3.5
8AG (P) 4
8AG (P) 5
8AG (P) 6
8AG (P) 7
Approvals
Safety Agency Approvals
Type
8AG / 8AP
Vßtc
Amp range / Volt @ I.R.
ability
80mA
.
- 2A / 250V AC@ 100A
80mA
.
- 7A / 125V AC@ 10000A
80mA
.
- 1A / 250V AC@ 35A
1A
.
- 2A / 250V AC@ 100A
80mA
.
- 5A / 125V AC@ 10000A
1A
.
- 5A / 125V AC@ 500A
>5A
.
- 15A / 125V AC@ 300A
V
Listed File No. E20624
ß
Certified File No. LR39772
8AG / 8AP
ov
e
t
Appr32-a1l 7F6il6 No. 32-1764 /
No.
File No. 32-1765
8AG / 8AP
8AG
Operating Temperature
-55ºC to +125ºC
Physical Specification
Materials
Glass body / Nickel Plated Brass Caps
Lead wire:
Tin-lead plated Copper, Diameter 0.032" thru’ 7A
Marking
On fuse:
“bel", “8AG", “Current Rating",“Voltage Rating",
and “Appropriate Safety Logos”
On label:
Above info plus “c” and interrupting rating
Voltage on fuse:
250V for 80mA to 2A; 125V for 2A and above
Packaging
1. In bulk:
8AG
- 1,000 pcs per box;
8AP
- 500 pcs per box
2. On Axial Tape & Reel:
1,000 pcs per reel
3. Tape & Reel specification:
per EIA-296-E & IEC 286-1
@ 10mm Pitch and 73mm inside Tape Spacing
Consult manufacturer for other ratings
Mechanical Dimensions
8AG
1.00"
±
0.03"
0.250"
±
0.004"
(25.4
±
0.8mm) (6.35
±
0.1mm)
1.50"
±
0.08"
1.03
±
0.03
(26.2
±
0.8mm)
0.270"
±
0.004"
(6.9
±
0.1mm)
8AP
(38.1
±
2mm)
SEE LEAD SIZE LISTED IN “ MATERIAL”
ORDERING INFORMATION SEE PAGES 67 & 68
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 • Tel: 201-432-0463 • Fax: 201-432-9542 • E-Mail: belfuse@belfuse.com
Website: www.belfuse.com
53
Specifications subject to change without notice
Type 8AG / 8AP
Fast Blow Fuse Series
1/4 x 1 inch Glass Tube
8AGC0801
8AG / 8AP - TIME CURRENT CHARACTERISTIC CURVE
- 80mA
- 100mA
- 125mA
- 150mA
- 200mA
- 250mA
- 350mA
- 500mA
- 750mA
- 1A
- 1.25A
- 1.5A
- 2A
- 2.5A
- 3A
- 3.5A
- 4A
- 5A
- 6A
- 7A
10000
1000
TIME IN SECONDS
100
10
1
0.1
0.01
0.01
0.1
1
10
100
1000
CURRENT IN AMPERES
NOTE - see important information under “User Guide”on P.08
Corporate Office
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302
Tel: 201-432-0463
Fax: 201-432-9542
E-Mail: belfuse@belfuse.com
Website: www.belfuse.com
Far East Office
Bel Fuse Ltd.
8F/8 Luk Hop Street
San Po Kong
Kowloon, Hong Kong
Tel: 852-2328-5515
Fax: 852-2352-3706
European Office
Bel Fuse Europe Ltd.
Preston Technology Management Centre
Marsh Lane, Preston PR1 8UD
Lancashire, U.K
Tel: 44-1772-556601
Fax: 44-1772-888366
Specifications subject to change without notice
54
