87018-8061

Description
Board to board/mezzanine connector ebbi recpt R/A 80p thru-hole
CategoryThe connector    The connector
File Size35KB,1 Pages
ManufacturerMolex
Websitehttps://www.molex.com/molex/home
Download Datasheet Parametric View All

87018-8061 Online Shopping

Suppliers Part Number Price MOQ In stock
87018-8061 - - View Buy Now

87018-8061 Overview

Board to board/mezzanine connector ebbi recpt R/A 80p thru-hole

87018-8061 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerMolex
Reach Compliance Codecompli
ECCN codeEAR99
Other featuresEBBI
body width0.319 inch
subject depth0.372 inch
body length2.717 inch
Body/casing typeRECEPTACLE
Connector typeTELECOM AND DATACOM CONNECTOR
Contact to complete cooperationNOT SPECIFIED
Contact point genderFEMALE
Contact materialNOT SPECIFIED
contact modeRECTANGULAR
Contact resistance30 mΩ
DIN complianceNO
Dielectric withstand voltage500VAC V
empty shellNO
Filter functionNO
IEC complianceNO
maximum insertion force.8896 N
Insulation resistance1000000000 Ω
Insulator colorBLACK
insulator materialGLASS FILLED LIQUID CRYSTAL POLYMER
MIL complianceNO
Manufacturer's serial number87018
Plug contact pitch0.05 inch
Plug informationMULTIPLE MATING PARTS AVAILABLE
Mixed contactsNO
Installation methodRIGHT ANGLE
Installation typeBOARD
PCB row number2
Number of rows loaded2
Maximum operating temperature105 °C
Minimum operating temperature-55 °C
OptionsGENERAL PURPOSE
PCB contact patternRECTANGULAR
PCB contact row spacing2.54 mm
Plating thickness30u inch
Rated current (signal)1 A
GuidelineUL
reliabilityCOMMERCIAL
Shell materialGLASS FILLED LIQUID CRYSTAL POLYMER
Terminal length0.1 inch
Terminal pitch1.27 mm
Termination typeSOLDER
Total number of contacts80
UL Flammability Code94V-0
Evacuation force-minimum value.139 N
Base Number Matches1
This document was generated on 11/22/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Description:
Replacement Part
Number:
Documents:
Drawing (PDF)
0870188061
Obsolete
1.27mm (.050") Pitch EBBI™ 50D Receptacle, Through Hole, Right Angle, Reverse D,
with Towers
None
image - Reference only
EU RoHS
Not RoHS Compliant
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Not Reviewed
China RoHS
Series
Agency Certification
CSA
UL
LR19980
E29179
General
Product Family
Series
Application
Obsolete Date
Product Name
Replacement Part Number
PCB Receptacles
87018
Board-to-Board, Signal
2005/04/01
EBBI™
None
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
Circuits (Loaded)
Durability (mating cycles max)
Flammability
Glow-Wire Compliant
Lock to Mating Part
Material - Plating Mating
Material - Plating Termination
Number of Rows
Orientation
PCB Retention
Packaging Type
Pitch - Mating Interface
Plating min - Mating
Plating min - Termination
Polarized to PCB
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
80
500
94V-0
No
None
Gold
Tin-Lead
2
Right Angle
Yes
Tray
1.27mm (.050")
0.762µm (30µ")
2.540µm (100µ")
Yes
Yes
-55°C to +105°C
Through Hole
Search Parts in this Series
87018Series
Mates With
87571 , 87012 , 87641
Electrical
Current - Maximum per Contact
Voltage - Maximum
1A
30V
Solder Process Data
Replacement RoHS Compliant Part Number
None
Material Info
Country of Origin
HK, SG, SI
This document was generated on 11/22/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
