Part Number:
Status:
Description:
0877057005
Obsolete
1.00mm (.039") Pitch DDR-II DIMM 240 Circuits Socket, Vertical, 1.8 Voltage, 3.00mm
(.118") Tail Length, White Latches, Nylon 6/6 Glass-filled, Black Housing, 0.38µm
(15µ") Gold (Au), Beveled Metal Pins Width 2.70mm (.106"), Lead Free
Documents:
Drawing (PDF)
General
Product Family
Series
Comments
Component Type
JEDEC Outline
Product Name
Memory Module Sockets
87705
<LI>White Latches <LI>Insertion Force: 10Kg (98N)
Max. <LI>Beveled Metal Pin Width: 2.70mm (.106")
Socket
MO-237
DDR2 DIMM
Series
image - Reference only
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Low-Halogen Status
Not Reviewed
China RoHS
Physical
Circuits (Loaded)
Durability (mating cycles max)
Entry Angle
Keying to Mating Part
Material - Plating Mating
Material - Plating Termination
PC Tail Length
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Temperature Range - Operating
Termination Interface: Style
240
25
Vertical (Top Entry)
Yes
Gold
Tin
3.00mm (.118")
Yes
2.40mm (.094")
Tray
1.00mm (.039")
-10°C to +85°C
Through Hole
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Electrical
Current - Maximum per Contact
Voltage - Maximum
Voltage Key
0.5A
30V
1.8V, Center
Search Parts in this Series
87705Series
Mates With
JEDEC standard 1.27mm modules
Solder Process Data
Lead-free Process Capability
Process Temperature max. C
Wave Capable (TH only)
260
Material Info
