BT100-8
Sensitive Gate Silicon Controlled Rectifiers
Features
◇
Repetitive Peak Off-State Voltage : 600V
◇
R.M.S On-State Current (IT(RMS)=0.8 A)
◇
Low On-State Voltage (1.2V(Typ.)@ITM)
General Description
Sensitive triggering SCR is suitable for the application
where gate current limited such as small motor control,
gate driver for large SCR, sensing and detecting circuits.
Absolute Maximum Ratings
(TJ=25
℃
unless otherwise specified)
Symbol
V
DRM
I
T(AV)
I
T(RMS)
I
TSM
I
2 t
P
GM
P
G(AV)
I
FGM
V
RGM
T
J
T
STG
Parameter
Repetitive Peak Off-state Voltage
Average On-State Current
R.M.S On-State Current
Surge On-State Current
I²
t
for Fusing
Forward Peak Gate Power
Dissipation
Forward Average Gate Power
Dissipation
Forward Peak Gate Current
Reverse Peak Gate Voltage
Operating Junction Temperature
Storage Temperature
Condition
Ratings
600
Units
V
A
A
A
A²
S
W
W
A
V
Half Sine Wave : T
C
=74℃
All Conduction Angle
1/2 Cycle, 60Hz, Sine Wave Non-
Repetitive
t = 8.3ms
T
A
=25℃, Pulse Width≤1.0㎲
T
A
=25℃, t=8.3ms
0.5
0.8
10
0.415
2
0.1
1
5.0
-40
-40
~
~
125
150
℃
℃
1
