Embedded Power for
Business-Critical Continuity
BXB150 Series
Single output
Total Power:
150 W
Input Voltage:
18 - 36 Vdc
36 - 75 Vdc
# of Outputs:
Single
Rev.05.13.08
bxb150
1 of 4
Electrical Specifications
Output
Special Features
• Industry standard footprint
MTBF >1.4 million hours
(Bellcore 332)
• Input voltage to ETS300-132-2
• Adjustable output voltage
• No minimum load required
• Separate case ground pin
• 2:1 input range for battery
powered applications
• Undervoltage lockout (UVLO)
• UL, VDE and CSA
safety approvals
• Available RoHS compliant
• 2 year warranty
Voltage adjustability:
Setpoint accuracy:
Line regulation
Load regulation
Minimum load
Overshoot
Undershoot
Ripple and noise
5 Hz - 20 MHz (see note 1)
Temperature coefficient
Transient response (see note 2)
Remote sense
Low line to high line
Full load to min. load
At turn on and turn-off
3.3 V and 5 V
12V and 15 V
60% to 110%
±1.0%
±0.5%
±0.10%
0%
None
None
75 mV pk-pk,
20 mV rms
100 mV pk-pk,
30 mV rms
±0.01% /
ºC
±2.0% max. deviation
170 μsrecovery
to within ±1.0%
0.5 Vdc transmission
line drop compensation
Safety
VDE0805/EN60950/IEC950
UL1950
CSA C22.2 No. 950
Embedded Power for
Business-Critical Continuity
Input
Input voltage range
Input current
Input current (max.)
(See note 4)
Input reflected ripple
Active low remote ON/OFF
Logic compatiblity
ON
OFF
Undervoltage lockout:
24 Vin nominal
48 Vin nominal
No load
Remote OFF
24 Vin
48 Vin
(See note 6)
(See note 7)
Open collector ref to -input
1.2 Vdc max.
Open circuit
24 Vin: power-up
24 Vin: power-down
48 Vin: power-up
48 Vin: power-down
Power-up
Remote ON/OFF
17 V
16.3 V
34 V
32.5 V
20 ms
20 ms
Level A
Level A
Level A
See table
1500 Vdc
1500 Vdc
1500 Vdc
500 kHz typ.
VDE0805, EN60950, IEC950
UL1950, CSa c22.2 No. 950
18 - 36 Vdc
36 - 75 Vdc
130 mA max.
20 mA max.
9.0 A max. @ lo max.
and Vin = 0 to 75 V
6.5 A max. @ lo max.
and Vin = 0 to 75 V
5 mA pk-pk
Rev.05.13.08
bxb150
2 of 4
Startup time (see note 8)
EMC Charateristics
Conducted emissions (see note 3) Bellcore 1089
FCC part 15
EN55022, CISPR22
General Specifications
Efficiency
Isolation voltage
Input/case
Input/output
Output/case
Fixed
Switching frequency
Approvals and
standards (see note 5)
Case material
Weight
MTBF
Aluminum baseplate with plastic case
110 g (3.88 oz)
Bellcore 332
1,400,000 hours
MIL-HDBK-217F
580,000 hours min.
@ 40 °C, 100% FL
Environmental Specifications
Thermal performance
Altitude
Vibration
Protection
Short-circuit
Overvoltage
Undervoltage
Thermal
Operating case temp.
Non-operating
Operating
Non-operating
5 - 500 Hz
-40 ºC to +100 ºC
-55
ºC
to +125
ºC
10,000 feet max.
40,000 feet max.
2.4 G rms (approx.)
Continuous, automatic recovery
Non-latching
Non-latching
110 °C baseplate, automataic recovery
Telecom Specifications
Central office
interface A
ETS300-132-2
Embedded Power for
Business-Critical Continuity
Ordering Information
Output
Power
(Max.)
Input
Voltage
OVP
Output
Voltage
Output
Current
(Min.)
Output
Current
(Max.)
Efficiency
(Typ.)
Regulation
Line
Load
Model Number
Rev.05.13.08
bxb150
3 of 4
100 W
100 W
150 W
150 W
150 W
Notes
18 - 36 Vdc
36 - 75 Vdc
36 - 75 Vdc
36 - 75 Vdc
36 - 75 Vdc
4.3 Vdc
4.3 Vdc
6.5 Vdc
14.5 Vdc
17.5 Vdc
3.3 V
3.3 V
5V
12 V
15 V
0A
0A
0A
0A
0A
30 A
30 A
30 A
12.5 A
10 A
77%
79%
84%
84%
88%
±0.05%
±0.05%
±0.05%
±0.05%
±0.05%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
BXB150-24S3V3FLTJ
BXB150-48S3V3FLTJ
BXB150-48S05FLTJ
BXB150-48S12FLTJ
BXB150-48S15FLTJ
Measured with 10 μF tantalum capacitor and 1 μF ceramic capacitor across
output.
2
di/dt = 0.1 A/1 μs, Vin = 48 Vdc, Tc = 25 °C, load change = 0.5 lo max. to 0.75 lo
max. and 0.75 lo max. to 0.5 lo max.
3
Units should be characterised within systems. External components required.
4
Input fusing is recommended based on surge current and maximum input
current.
5
This product is only for inclusion by professional installers within other
equipment and must not be operated as a stand alone product.
6
Simulated source impedance of 12
μ
H. 12
μ
H inductor in series with +Vin.
7
Active high remote ON/OFF option is available (standard product is active low),
designate with the suffix ‘FHT’ e.g.
BXB150-48S05FHTJ.
Consult factory for
further details and options.
8
Start-up into resistive load.
9
The ‘J’ suffix indicates that these parts are Pb-free (RoHS 6/6) compliant.
TSE RoHS 5/6 (non Pb-free) compliant versions may be available on special
request, please contact your local sales representative for details.
10
NOTICE: Some models do not support all options. Please contact your local
sales representative or use the on-line model number search tool at
http://www.powerconversion.com to find a suitable alternative.
1
External Output Trimming
Output can be externally trimmed
by using the method shown.
8
Pin connections
Pin Number
Function
TRIM
UP
7
RT1
OR
RT2
TRIM
DOWN
6
1
2
3
4
5
6
7
8
9
+Vin
Remote ON/OFF
Case
-Vin
-Vout
-Sense
Trim
+Sense
+Vout
Mechanical Drawing
VIEW SHOWN
PIN SIDE UP
1.90
(48.26)
0.500 (12.69) 0.010 (0.25)
+SEN TRIM -SEN
0.190 (4.83) 0.010 (0.25)
0.200 (5.08) Min.
Length for all Input
and Output Pins
1.000 (25.40)
0.400 (10.16)
1.400 (35.56)
CASE
Vo (-)
VI (-)
0.700 (17.77)
0.400 (10.16)
1.000 (25.40)
2.000 (50.80)
2.40 (60.96)
Max.
ON/OFF
1.400 (35.56)
7 x Ø.040 (1.02) 0.002 (0.05)
0.190 (4.83) 0.010 (0.25)
2.28 (57.91) Max.
2 x Ø.080 (2.03) 0.002 (0.05)
4 x M3 x 0.5 Through
0.500 (12.70)
ALL DIMENSIONS IN INCHES (mm)
Tolerance : x.xx 0.02in. (0.51mm)
x.xxx
0.010in. (0.254mm)
Vo(+)
VI(+)
Embedded Power for
Business-Critical Continuity
Americas
5810 Van Allen Way
Carlsbad, CA 92008
USA
Telephone: +1 (760) 930 4600
Facsimile: +1 (760) 930 0698
Rev.05.13.08
bxb150
4 of 4
Europe (UK)
Waterfront Business Park
Merry Hill, Dudley
West Midlands, DY5 1LX
United Kingdom
Telephone: +44 (0) 1384 842 211
Facsimile: +44 (0) 1384 843 355
Asia (HK)
14/F, Lu Plaza
2 Wing Yip Street
Kwun Tong, Kowloon
Hong Kong
Telephone: +852 2176 3333
Facsimile: +852 2176 3888
For global contact, visit:
www.powerconversion.com
techsupport.embeddedpower
@emerson.com
