DS276S datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> DS276S

DS276S: DescriptionLINE TRANSCEIVER, PDSO8, 0.150 INCH, SOIC-8; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size866KB，14 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Related ProductsFound1parts with similar functions to DS276S

Download Datasheet Parametric Compare View All

DS276S Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	DS276S	-	-	View	Buy Now

DS276S Overview

LINE TRANSCEIVER, PDSO8, 0.150 INCH, SOIC-8

DS276S Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	SOIC
package instruction	0.150 INCH, SOIC-8
Contacts	8
Reach Compliance Code	unknown
Differential output	NO
Number of drives	1
Input properties	SCHMITT TRIGGER
Interface integrated circuit type	LINE TRANSCEIVER
Interface standards	EIA-232-E
JESD-30 code	R-PDSO-G8
JESD-609 code	e0
length	4.9 mm
Humidity sensitivity level	NOT APPLICABLE
Number of functions	1
Number of terminals	8
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	245
Certification status	COMMERCIAL
Number of receiver bits	1
Maximum seat height	1.75 mm
Maximum supply voltage	5.5 V
Minimum supply voltage	2.7 V
Nominal supply voltage	3 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	3.9 mm
Base Number Matches	1
