Fuse Holders and Blocks
In-line Fuse Holders
HR and HM
Series
Specifications
Description:
In-line
fuse holders for SFE
and
1
⁄
4
" dia. x various
length fuses.
Dimensions:
See
Dimensions
illustration.
Ratings:
Volts: — 32V
Amps: — 20A
Features and Benefits
• HR and HM Universal in-line fuse
holder for SFE and various length
1
⁄
4
"
diameter fuses with #14 lead wires.
Typical Applications
• Supplemental, Low Voltage, Low
Amperage Control Circuits
Catalog Numbers
Catalog
Numbers
HRJ*
HRI
HRH
HRE
HRG
HRF
HMJ**
HMI
HMH
HME
HMG
HMF
Includes
Fuse
SFE-20
SFE-14
SFE-9
SFE-7
1
⁄
2
SFE-6
SFE-4
SFE-20
SFE-14
SFE-9
SFE-7
1
⁄
2
SFE-6
SFE-4
Wire Length
& Size
HFA Series
HHT Series
19” of #14
Specifications
Description:
In-line water-resistent
fuse holders for
1
⁄
4
" x 1
1
⁄
4
" fuses.
Dimensions:
See Dimensions
illustration.
Construction:
Phenolic body with
copper crimp contact leads.
Ratings:
Volts: — 250V
Amps: — 20A
Agency Information:
CE, UL
Recognized, (Guide IZLT2, File
E14853) UL.
Flammability Rating:
UL 94HB.
Features and Benefits
• HFA in-line, water-resistent fuse holder
for
1
⁄
4
" x 1
1
⁄
4
" fuses.
Specifications
Description:
In-line fuse holders for
5 x 15mm or 5 x 20mm fuses.
Dimensions:
See Dimensions
illustration.
Construction:
Black thermoplastic
body with brass contacts, wire: 16
AWG, red.
Ratings:
Volts: — 32V
Amps: — 5A (5 x 15mm)
— 10A (5 x 20mm)
Features and Benefits
• HHT in-line fuse holders for 5 x 15mm
and 5 x 20 mm fuses.
Typical Applications
• Supplemental, Low Voltage, Low
Amperage Control Circuits
Catalog Numbers
Catalog Number
HHT
Fuse Size
5 x 15mm & 5 x 20mm
8” of #14
* Also available as in-line fuse holder only with lead wire
contacts, HRJ-LESS-Fuse.
** Also available as in-line fuse holder only with lead wire
contacts, HMJ-LESS-Fuse.
Typical Applications
• Supplemental, Low Voltage, Low
Amperage Control Circuits
Refer to data sheet for recommend
crimp tools
Catalog Numbers
Catalog
Numbers
HFA
HFA-HH*
Terminals
Crimp #12 - #16
1
⁄
4
" Quick Connect
HHJ-A
HHJ-B
HHI-B
For
1
⁄
4
" x 1
1
⁄
4
" fuse, no wire or fuse
included, accepts #18 - #22 wire.
For
1
⁄
4
" x 1
1
⁄
4
" fuse, no wire or fuse
included, accepts #12 - #16 wire.
For
1
⁄
4
" x 1
1
⁄
16
" fuse, no wire or fuse
included, accepts #12 - #16 wire.
Dimensions - in
1/4"
±
1/32"
6-3/16"
±
1/4"
1.84"
(IN ASSEMBLED POSITION)
6-1/16"
±
1/4"
Replacement Contacts
Catalog
Number
9838
9841
Symbol
HHJ-A
HHJ-B
*No UL Recognition.
WIRE LENGTH: 13"
±
0.5"
Dimensions - in (mm)
2.34"
(59.5mm)
0.42" DIA.
1.84"
Dimensions - in (mm)
2.19"
(55.6mm)
.800"
(20.3mm)
.600"
(15.2mm)
0.75"
(19.1mm)
0.69"
(17.5mm)
1.56"
(39.7mm)
0.38"
(9.5mm)
Data Sheet: 2122
Data Sheet: 2115
Data Sheet: 2138
278
For product data sheets, visit www.cooperbussmann.com/datasheets/ulcsa
