Introducing
TMS-90-SCE Military Grade
Heat-Shrinkable Wire Identification Sleeves
The TMS-90-SCE is a flame retardant military grade heat-shrinkable polyolefin tubing
used for wire identification. It is lightweight and ideal for aerospace applications. It is
manufactured from the same compound as the Raychem TMS-90 product, but offered
in TE Connectivity (TE) System 6 “Ladder” format for ease of thermal transfer printing.
Available in various sizes ranging from 3/32” to 1 1/2” and have a 2:1 shrink ratio.
KEY FEATURES
•
Product successor to the TMS-90 product
•
2 : 1 shrink ratio
•
Flame retardant
•
Thermal Transfer printable
•
Meets the performance requirements of
MECHANICAL
•
Tensile strength : 10.3MPA minimum (ASTM D638, 20 inches/min)
•
Ultimate elongation : 200% minimum (ASTM D638, 20 inches/min)
•
Longitudinal change : -10% min and +10% max (ASTM D2671)
•
Heat aging : 336 hours at 175°C (347°F)
•
Heat shock : No dripping, flowing or cracking and print legible after
SAE-AMS-DTL-23053/5 class 1
•
Meets the mark permanence requirements
4 hours at 250°C (482°F)
•
Low temperature flexibility : No cracking after 4 hours at -55°C (-67°F),
of SAE-AS81531 and MIL 202 Method 215J
Resistance to Solvents
•
-55°C to +135°C operating
11mm (7/16 inch) mandrel bend.
temperature range
•
UL Recognized Standard 224
STANDARDS AND SPECS
•
TE Connectivity (TE) : RW 2530
•
UL : Recognized Standard 224 (File E35586)
•
CSA : Certified (File LR31929)
•
Military : AMS-DTL-23053/5 class 1, AS-81531, and MIL STD-202 Method 215J
(File E35586)
•
CSA certified (File LR31929)
•
RoHS complaint
APPLICATIONS
•
Aerospace
•
Commerical
•
Defense
•
Electronic
•
Industrial
•
Lighting
•
Marine
•
Rail & Mass Transit
PRODUCT DIMENSIONS
in millimeters and (inches)
Nominal
weight per
piece (g)
0.1726
0.2440
0.3500
0.4727
0.6017
0.9120
1.704
3.5344
Minimum
Expanded
Inside Dia.
2.36
(0.093)
3.18
(0.125)
4.75
(0.187)
6.35
(0.250)
9.53
(0.375)
12.70
(0.500)
19.05
(0.750)
38.10
(1.500)
Maximum
Recovered
Inside Dia.
0.79
(0.031)
1.07
(0.042)
1.57
(0.062)
2.11
(0.083)
3.18
(0.125)
4.22
(0.166)
6.35
(0.250)
19.05
(0.750)
Recovered
Wall
Thickness
0.508 +/- 0.076
(0.020 +/- 0.003)
0.508 +/- 0.076
(0.020 +/- 0.003)
0.508 +/- 0.076
(0.020 +/- 0.003)
0.635 +/- 0.076
(0.025 +/- 0.003)
0.635 +/- 0.076
(0.025 +/- 0.003)
0.635 +/- 0.076
(0.025 +/- 0.003)
0.762 +/- 0.076
(0.030 +/- 0.003)
1.016 +/- 0.152
(0.035 +/- 0.003)
Sleeve
Progression
12.70 +/- 0.64
(0.500 +/- 0.025)
12.70 +/- 0.64
(0.500 +/- 0.025)
12.70 +/- 0.64
(0.500 +/- 0.025)
16.94 +/- 0.89
(0.667 +/- 0.035)
25.40 +/- 0.89
(1.000 +/- 0.035)
29.64 +/- 1.02
(1.167 +/- 0.040)
42.34 +/- 1.02
(1.667 +/- 0.040)
71.96 +/- 1.02
(2.833 +/- 0.040)
Part Number
TMS-90-SCE-3/32
TMS-90-SCE-1/8
TMS-90-SCE-3/16
TMS-90-SCE-1/4
TMS-90-SCE-3/8
TMS-90-SCE-1/2
TMS-90-SCE-3/4
TMS-90-SCE-1-1/2
ELECTRICAL
•
Dielectric strength : 19.7MV/m minimum
(ASTM D2671) materials
•
Flame retardant radiation cross-linked
homopolymer-based polyolefin
heat-shrinkable tubing
