CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
NOTE:
1.
θ
JA
is measured with the component mounted on a HIGH effective thermal conductivity test board in free air. See Tech Brief TB379 for details.
IMPORTANT NOTE: All parameters having Min/Max specifications are guaranteed. Typical values are for information purposes only. Unless otherwise noted, all tests
are at the specified temperature and are pulsed tests, therefore: T
J
= T
C
= T
A
Electrical Specifications
PARAMETER
V
ON
= 22V, V
OFF
= -5V, T
A
= -40°C to +85°C Unless Otherwise Specified. Typical values tested at 25°C
CONDITION
MIN
-5
(V
OFF
)
5.0
TYP
MAX
22
(V
ON
)
8.0
UNIT
V
mA
DESCRIPTION
Power Supplies Recommended Operating Voltages
I(V
ON
)
Supply Current
All Inputs low or high
No load
V
ON
= V
ON1
+ V
ON2
All Inputs low or high
No load
Each Input low or high
High = 1.8V, Low = 0.8V
IOH = -100µA
V
ON
= 22V
RL = 4700pF in parallel with 5kΩ
IOH = +100µA
V
OFF
= -5V
RL = 4700pF in parallel with 5kΩ
I(V
OFF
)
I
IN
VOH
Supply Current
Input Leakage
High Level Output Voltage
-8.0
-10
(V
ON
- 1.5V)
-5.0
mA
10
µA
V
±
3.5
21.2
VOL
Low Level Output Voltage
-4.3
(V
OFF
+
1.5V)
V
VIH
VIL
tplh
High Level Input Voltage
Low Level Input Voltage
Low to High Prop Delay
50% to 50%, Tested with
RL = 4700pF in parallel with 5kΩ,
f = 50kHz
Measured at 50% to 50%
f = 50kHz
RL = 4700pF in parallel with 5kΩ
Measured at 10% to 90%
f = 50kHz
RL = 4700pF in parallel with 5kΩ
Measured at 10% to 90%
f = 50kHz
RL = 4700pF in parallel with 5kΩ
1.8
0.8
190
400
V
V
ns
tphl
High to Low Prop Delay
230
400
ns
ttlh
Rise Time
260
400
ns
tthl
Fall Time
290
500
ns
3
FN6196.0
October 21, 2005
ISL24011
Pin Descriptions
PIN NUMBER
TSSOP-20
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
PIN NAME
GND
IN1
IN2
IN3
IN4
IN5
IN6
IN7
IN8
VOFF
VON2
OUT8
OUT7
OUT6
OUT5
OUT4
OUT3
OUT2
OUT1
VON1
EQUIVALENT
CIRCUIT
4
1
1
1
1
1
1
1
1
4
4
3
3
2
2
2
2
2
2
4
Ground pin
Level shifter input 1
Level shifter input 2
Level shifter input 3
Level shifter input 4
Level shifter input 5
Level shifter input 6
Level shifter input 7
Level shifter input 8
Negative output supply for all channels
Positive output supply for channels 7 and 8. V
ON2
is required to be greater than or equal to V
ON1
Lever shifter output 8
Lever shifter output 7
Lever shifter output 6
Lever shifter output 5
Lever shifter output 4
Lever shifter output 3
Lever shifter output 2
Lever shifter output 1
Positive output supply for channels 1 through 6. V
