Product Brief
PMB 5699
SMARTi U Single-Chip
W- C D M A / U MTS Tra nsce i ve r
SMARTi U – First Single-Chip
U M T S / W - C D M A R F -Tr a n s ce i v e r
Infineon has designed the first single-chip UMTS/ W-CDMA RF-transceiver
IC SMARTi U to be used in mobile applications according 3GPP
(FDD, 2100 MHz) requirements.
SMARTi U (PMB 5699) offers lowest component count and smallest
PCB area at lowest current consumption.
The full homodyne architecture and flexible control concept reduces
significantly implementation efforts and time-to-market.
General
■
■
■
■
■
■
■
Supply voltage: 2.7 - 3.0 V
3-Wire bus programmable
Low external component count
Temperature range -25 to 85°C
P-VQFN-40 leadless package
6.5 x 5.5 mm, 0.5 mm pitch
Integrated synthesizers
Rx
■
■
■
Features
■
■
■
■
■
■
■
■
Integration of receive and transmit path
– Smallest size
– Lowest component count
– Less requirements on PCB layout
Fully integrated synthesizers
– No external tank circuit
– No external frequency adjustment required
Fully homodyne architecture
– No IF (intermediate frequency) stage
– No IF-SAW filter
– Easiest frequency concept
Lowest current consumption
– Highest stand-by and talk time
Integrated receive channel filter
– Reduced baseband efforts
Integrated transmit filter
– Reduced baseband signal requirements
Flexible baseband interface
– Supporting various baseband solutions
– Various reference frequencies
– Adjustable I/Q interface
– Flexible 3-wire-bus concept
– Supporting multi-mode
Lowest external component count
– No external components for DC-offset compensation
– No external components for channel filtering
Direct conversion receiver
Integrated channel filter
Integrated DC-offset compensation
Tx
■
■
■
Direct modulation transmitter
Integrated VGA
Dynamic range > 85 dB
Applications
■
■
■
■
■
■
■
UTRA FDD standard
Power class 3
Fixed and variable duplex
Compressed mode
Dual-receive
Cellular phones
PDAs and handhelds
www.infineon.com/mobilesolutions
Mobile Solutions
N e v e r
s t o p
t h i n k i n g .
Product Brief
Block Diagram SMARTi U
I
Ix
0˚
UMTS Rx
90˚
Q
Qx
2140 MHz
LNA
3-Wire-Bus
Control 1
VCO
PLL
SMARTi U
3-Wire-Bus
Control 2
VCO
PLL
f
ref
I
Ix
0˚
UMTS Tx
90˚
Q
Qx
P-VQFN-40 (6.5 x 5.5 mm)
1950 MHz
2-Stage PA
