PMB2208 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Telecom circuit> PMB2208

PMB2208: DescriptionMixer and IF Vector Modulator; CategoryWireless rf/communication Telecom circuit; File Size449KB，27 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/; Environmental Compliance

Download Datasheet Parametric View All

PMB2208 Overview

Mixer and IF Vector Modulator

PMB2208 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Infineon
Parts packaging code	TSSOP
package instruction	TSSOP, TSSOP24,.25
Contacts	24
Reach Compliance Code	compli
JESD-30 code	R-PDSO-G24
length	7.8 mm
Humidity sensitivity level	3
Number of functions	1
Number of terminals	24
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Encapsulate equivalent code	TSSOP24,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
power supply	2.7/4.5 V
Certification status	Not Qualified
Maximum seat height	1.2 mm
Maximum slew rate	0.014 mA
Nominal supply voltage	3.6 V
surface mount	YES
technology	BIPOLAR
Telecom integrated circuit types	RF AND BASEBAND CIRCUIT
Temperature level	OTHER
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	4.4 mm

Preview

Download Datasheet

View All

Wireless Components

Mixer and IF Vector Modulator

PMB 2208 Version V1.2

Specification August 1999

preliminary

Table of Contents

2.1

2.2

2.3

2.4

3.1

3.2

3.3

3.4

3.5

4.1

4.2

5.1

5.1.1

5.1.2

5.1.3

5.2

5.2.1

5.2.2

5.2.3

5.3

Table of Contents

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Product Description

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Package Outlines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Functional Description

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Pin Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Pin Definition and Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Internal Input/Output Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Functional Block Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Circuit Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Applications

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Hints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Reference

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Electrical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Operating Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

AC/DC Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

S-Parameters and Input/Output Impedances . . . . . . . . . . . . . . . . . . . 5-7

Mixer Input RX/RFX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8

Mixer Input IF/IFX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9

Mixer Output MO/MOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10

Test Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
