GSM Dualband TX VCO
PMB 2110
Version 1.1
Product Info
General Description
s
The PMB 2110 is a Transmit VCO for
Dualband (900/1800) GSM mobiles.
P-TSSOP-10-1
Features
s
s
s
s
Fully integrated, monolithic solution
Very small outline and low profile
TSSOP10 package
Two single ended RF power outputs to
drive the power amplifier
Low power balanced output for PLL
downconverter for optimized bill of
material (no external power splitter
required)
s
s
s
Band select and power down function
Supply voltage range 2.7V to 2.95V
-20°C to +75°C operational tempera-
ture range
Application
s
Transmit VCO for GSM Dualband
(900/1800) transceivers
Type
PMB 2110
Specification
Ordering Code
Q67034-H0005
5
Package
P-TSSOP-10
2001-07-30
