KTK-R-1/8: Descriptionfuse 1/8A 600v fast UL csa; CategoryCircuit protection Circuit protection; File Size260KB，3 Pages; ManufacturerEaton

Download Datasheet Parametric View All

KTK-R-1/8 Overview

fuse 1/8A 600v fast UL csa

KTK-R-1/8 Parametric

Parameter Name	Attribute value
Maker	Eaton
Reach Compliance Code	unknow
ECCN code	EAR99
Fusing characteristics	FAST
body height	38.1 mm
Body length or diameter	10.3 mm
Circuit protection type	ELECTRIC FUSE
Manufacturer's serial number	KTK-R
Installation features	INLINE/HOLDER
method of packing	BOX
physical size	10.3mm x 38.1mm
Rated breaking capacity	200000 A
Rated current	0.125 A
Rated voltage (AC)	600 V
Guideline	CSA; UL
surface mount	NO
Terminal surface	NICKEL
Terminal shape	END CAP

Preview

Download Datasheet

View All

IMITRON

™ Class CC

KTK-R — 600Vac,

⁄

-30A, Fast-Acting Fuses

Dimensions – in (mm)

1.5" (± 0.031)

(38.1mm)

0.41" (± 0.005)

(10.3mm)

Description:

Advanced protection Class CC current-limiting,

fast-acting fuses.

Catalog Symbol:

KTK-R-(amp)

Ratings:

Volts — 600Vac

Amps —

⁄

-30A

IR — 200kA Vac RMS Sym.

Agency Information:

CE, UL Listed, Std. 248-4, Class CC, Guide JDDZ, File E4273

CSA Certified, C22.2 NO. 248.4, File 53787, Class 1422-02

RoHS Compliant

Catalog Numbers (amps)

KTK-R-

⁄

KTK-R-

⁄

KTK-R-

⁄

KTK-R-

⁄

KTK-R-

⁄

KTK-R-

⁄

KTK-R-

⁄

Amp Rating

⁄

–30

KTK-R-

⁄

KTK-R-

⁄

KTK-R-1

KTK-R-1-

⁄

KTK-R-2

KTK-R-2-

⁄

KTK-R-3

Carton Qty.

KTK-R-3-

⁄

KTK-R-4

KTK-R-5

KTK-R-6

KTK-R-7

KTK-R-8

KTK-R-9

KTK-R-10

KTK-R-12

KTK-R-15

KTK-R-20

KTK-R-25

KTK-R-30

Features

• Provides 10X better current limitation to help prevent

equipment damage caused by short-circuit events.

• 200kA interrupting rating complies with NEC

Section 110.9

for today's large capacity systems.

• Fast-acting fuse helps prevent equipment damage caused

by short-circuit events.

• Rejection type fuse fits both standard and rejection-style

holders.

• Ideal for critical industrial or commercial applications that

have specific current limitation requirements.

Recommended Fuse Blocks and Holders

Fuse Amps

0-30

1-Pole

2-Pole

Open Blocks

BC6031_

BC6032_

DIN-Rail Holders

CHCC1D_

CHCC2D_

—

Panel Mount Holders

HPS

—

HPF

—

In-Line Holders

—

HEY

HEZ

—

3-Pole

BC6033_

CHCC3D_

OPM-NG-_

OPM-1038_

OPM-1038_SW

—

0-30

Carton Quantity:

0-30

For additional information on the Class CC fuse blocks and

holders, see Data Sheets:

• Open Blocks # 1105 (BC Series)

• DIN-Rail Holders, # 3185 (CHCC), # 1109 (OPM),

# 1102 (OPM-1038), # 1103 (OPM-1038_SW),

• Panel Mount Holders # 2113 (HPS), # 2114 (HPF)

• In-Line Holders # 2126 (HEY), # 2130 (HEZ)

0813

BU-SB13727

Page 1 of 3

Data Sheet # 1015
