Bussmann
®
LIMITRON
®
Fast-Acting Fuses
600 Volt, 1/10 - 30 Amps
Dimensional Data
• LIMITRON
®
fast-acting fuse.
• Melamine tube.
• Nickel-plated bronze endcaps.
KTK
6/10
3/4
1
1-1/2
2
2-1/2
3
4
5
6
7
8
(±0.031)
(38.1mm)
1.5
Time-Current Characteristic Curves–Average Melt
AMPERE
RATING
20
10
15
25
30
100
.41
(±0.004)
(10.3mm)
10
Catalog Symbol:
KTK
Fast-Acting
1/10 TO 30A
600Vac (or less)
Interrupting Rating:
100,000A RMS Sym. (UL)
UL Listed, STD. 248-14, (Guide #JDYX, File #E19180)
CSA Certified:
C22.2 NO. 248.14
(File #53787—Class #1422-01)
HRC-MISC
TIME IN SECONDS
1
Electrical Ratings (Catalog Symbol and Amperes)
600Vac - UL Listed and C.S.A.
KTK-1/10
KTK-1/8
KTK-2/10
KTK-1/4
KTK-3/10
KTK-4/10
KTK-1/2
KTK-6/10
KTK-3/4
KTK-1
KTK-1-1/4
KTK-1-1/2
KTK-2
KTK-2-1/2
KTK-3
KTK-3-1/2
KTK-4
KTK-5
KTK-6
KTK-7
KTK-7-1/2
KTK-8
KTK-9
KTK-10
KTK-12
KTK-15
KTK-20
KTK-25
KTK-30
—
—
—
—
.9
1
.1
—
—
RMS SYMMETRICAL CURRENT IN AMPERES
Carton Quantity and Weight
Ampere
Ratings
1-30
Carton
Qty.
10
Weight*
Lbs.
.180
Kg.
.082
*Weight per carton.
Recommended fuseblocks/fuseholders for
13/32” x 1-1/2” fuses
See Data Sheets listed below
• Open fuseblocks - 1104, 2104
• Finger-safe fuseholders - 1109, 1102, 1103, 1151
• Panel-mount fuseholders - 2114, 2113, 2108,
2112, 2109, 2140
• In-line fuseholders - 2127, 2126
CE logo denotes compliance with European Union Low Voltage Directive
(50-1000Vac, 75-150Vdc). Refer to Data Sheet: 8002 or contact Bussmann
Application Engineering at 636-527-1270 for more information.
The only controlled copy of this Data Sheet is the electronic read-only version located on the Bussmann Network Drive. All other copies of this Data Sheet are by definition uncontrolled. This bulletin is intended to clearly
present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change design or construction of any products
and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information contained in this bulletin. Once a product has been selected, it
should be tested by the user in all possible applications.
100
11-13-02
N02177
Form No. KTK
Page 1 of 1
Data Sheet: 1011
800
10
—
.01
