DC Fan
ø
San Ace 172 9E
type
■
General Specifications
172
×
150
×
51
mm
Sidecut type
rated voltage)
Locked rotor burnout protection, Reverse polarity protection
For details, please refer to p. 529.
50/60 Hz, 500 VAC, for 1 minute (between lead wire conductors and frame)
10 MΩ or more with a 500 VDC megger (between lead wire conductors and frame)
At 1 m away from the air inlet
-30 to +70˚C (Non-condensing)
Black or Blue
Sensor
・
Material
…………………………………………
Frame: Aluminum, Impeller: Plastic (Flammability: UL 94V-1)
・
Expected life
……………………………………
See the table below. (L10 life: 90% survival rate for continuous operation in free air at 60˚C,
・
Motor protection function
…………………
・
Dielectric strength
……………………………
・
Insulation resistance
…………………………
・
Sound pressure level (SPL)
………………
・
Storage temperature
………………………
・
Lead wire
………………………………………
Red
・
Mass
………………………………………………
760 g
Yellow
■
Specifications
The models listed below
have pulse sensors.
Model no.
Rated voltage Operating voltage range Rated current Rated input
[V]
[V]
[A]
[W]
Rated speed
[min
-1
]
Max. airflow
[m³/min]
[CFM]
Max. static pressure
[Pa]
SPL
[dB (A)]
Operating temperature Expected life
[˚C]
[h]
109E5712K501
109E5712Y501
109E5712H501
109E5712F501
109E5712M501
109E5724C501
109E5724K501
109E5724H501
109E5724F501
109E5724M501
109E5748C501
109E5748K501
109E5748H501
109E5748F501
109E5748M501
12
10.2 to 13.8
24
20.4 to 27.6
48
40.8 to 55.2
2.9
2.3
1.2
0.68
0.48
2.3
1.3
0.58
0.35
0.2
1.2
0.7
0.28
0.19
0.11
34.8
27.6
14.4
8.16
5.76
55.2
31.2
13.92
8.4
4.8
57.6
33.6
13.44
9.12
5.28
4100
3800
3050
2500
2000
4800
4100
3050
2500
2000
4800
4100
3050
2500
2000
8.5
8
6.4
5.1
4.2
9.9
8.5
6.4
5.1
4.2
9.9
8.5
6.4
5.1
4.2
300
282
226
180
148
350
300
226
180
148
350
300
226
180
148
243.0
210
137.2
95
67.6
308.0
243.0
137.2
95
67.6
308.0
243.0
137.2
95
67.6
[inchH²O]
0.976
0.84
0.551
0.38
0.271
1.237
0.976
0.551
0.38
0.271
1.237
0.976
0.551
0.38
0.271
60
60
52
47
41
66
60
52
47
41
66
60
52
47
41
-
20 to
+
60
-
20 to
+
70
-
20 to
+
70
40000/60˚C
-
20 to
+
60
-
20 to
+
70
Other sensor specifications are available as options. Refer to the index (p. 543).
■
Airflow - Static Pressure Characteristics
109E5712K501
With pulse sensor
109E5712Y501
With pulse sensor
109E5712H501
With pulse sensor
Operating voltage range
(inch H
2
O) (Pa)
Operating voltage range
(inch H
2
O) (Pa)
Operating voltage range
(inch H
2
O) (Pa)
1.2
1.0
300
250
200
150
100
50
0
0
2
100
4
6
200
8
300
10
(m
3
/min)
1.2
13.8 V
12 V
10.2 V
1.0
300
250
200
150
100
50
0
0
2
100
4
6
200
8
300
10
(m
3
/min)
0.8
200
13.8 V
150
100
50
0
0
12 V
10.2 V
Static
静圧
pressure
Static
静圧
pressure
0.8
0.6
0.4
0.2
0
0.8
0.6
0.4
0.2
0
12 V
10.2 V
Static
静圧
pressure
13.8 V
0.6
0.4
0.2
0
1 2 3 4 5 6 7 8
(m
3
/min)
風量
Airflow
400
(CFM)
風量
Airflow
400
(CFM)
50 100 150 200 250 300
(CFM)
風量
Airflow
210
■
Dimensions
(unit: mm)
4-
ø
4.5
±
0.3
Mounting hole
取付用穴
10
ø
172
±
0.8
162
±
0.5
+30
30 0 0
Lead wire
リー
ド線
AWG24
UL 1007
or
または
AWG22
UL 1430
150
±
0.8
7.5
±
0.4
7.5
±
0.4
51
±
0.8
回転方向
Rotating direction
風吹出方向
Airflow direction
■
Reference Dimensions of Mounting Holes and Vent Opening
(unit: mm)
Inlet side, Outlet side
148
162
±
0.3
2-
R4
8.5
2-
ø
4.5
■
Options
Finger guards
Model no.: 109-319E, 109-319H, 109-320
page: p. 515
212
.25
ø
1
68
