HIGH-REPETITION PICOSECOND LIGHT PULSER
Model PLP-10
New
High repetition up to 100 MHz
from
Hamamatsu
Wavelength range from 375 to 1,550 nm
The picosecond light pulser PLP-10 is an ultrashort pulsed light source that utilizes a laser diode (LD) head. It consists
of a controller and an LD head. Ten LD head types are available to accommodate various wavelengths, enabling optical
output over a broad wavelength range of 375 to 1,550 nm.
The PLP-10 is ideal for frequency characteristics evaluation of POF optical communications, response characteristics
evaluation of a photodetector device, and an excitation light source of a fluorescence lifetime measurement system.
Optical output is selectable from a window output or FC connector output.
FEATURES
q
Ultrashort pulses with FWHM of 100 ps or less
q
High-repetition frequency up to 100 MHz
q
Stable output power and oscillation timing
q
Easy to use and maintenance free operation
q
Built-in trigger delay
q
LED heads (optonal)
q
APPLICATIONS
q
Frequency characteristics evaluation of POF
and Gigabit Ethernet optical fiber
q
Pulse response measurement of high-speed
photodetectors
q
Record evaluation of an optical recording medium
q
Excitation light source for fluorescence lifetime
measurements
Please consult with our sales office.
SPECIFICATIONS
q
M8903 Laser diode head
•
Output form type: window: PLP10-xxx / FC connector (for multi-mode optical fiber) : PLP10-xxxC
Parameter
Emission wavelength
Wavelength tolerance
Spectral half-width
Pulse width
Beam divergence angle*
Window output
FC connector output
max.
typ.
θ
||
θ
⊥
typ
.
min.
typ
.
min.
Unit
nm
nm
nm
ps
deg.
PLP10-038 PLP10-041 PLP10-044 PLP10-063 PLP10-065 PLP10-067 PLP10-078 PLP10-085 PLP10-130 PLP10-155
PLP10-041C PLP10-044C PLP10-063C PLP10-065C PLP10-067C PLP10-078C PLP10-085C PLP10-130C PLP10-155C
******
405
635
650
670
780
850
375
440
1300
1550
<±10
<±10
<±10
<±20
<±10
<±10
<±10
<±10
<±30
<±30
<10
<5
<5
<5
<5
<5
<10
<10
<10
<20
100
110
100
100
100
100
100
100
100
100
70
90
80
80
70
70
70
70
70
70
11
16
15
12
15
13
10
10
25
25
34
35
35
40
30
32
30
28
30
30
100
70
70
70
70
100
70
80
20
10
50
30
30
30
30
50
30
40
10
5
50
30
30
30
30
50
20
10
5
***
25
10
10
10
10
25
10
5
2
***
Peak
power
mW
*Measured using a window output type.
Note: Measured with 100MHz. The values can be changed depending on the frequency. The PLP head should be selected according to wavelength and output form and can be exchangeable with the
controller C8898.
q
C8898 Controller
•
Repetition frequency (Hz)
Internal trigger ....... 100 MHz, 50 MHz, 20 MHz, 10 MHZ, 5 MHz,
2 MHz, 1 MHz, 500 kHz, 200 kHz, 100 kHz,
50 kHz, 20 kHz, 10 kHz, 5 kHz, 2 kHz, 1 kHz,
500 Hz, 200 Hz, 100 Hz, 50 Hz, 20 Hz, 10 Hz,
5 Hz, 2 Hz
External trigger ......................................... Single shot to 50 MHz
•
External trigger output
Amplitude ........................................................... –4 to +4 V/50
Ω
Minimum pulse width ........................................................... 10 ns
•
Synchronous trigger output
Amplitude (Selectable) ..................................... +2 to +3 V / 50
Ω
or -500 to 700 mV / 50
Ω
Pulse width ................................................................. 5 ns
±
3 ns
Timing ........................ before or after optical output (selectable)
Delay time .... t
0
(reference time)
±∆t; ∆t=
0 ns, 20 ns, 40 ns, 60 ns
80 ns 100 ns
•
Line voltage ......................................... 100 to 240 V AC 50/60 Hz
•
Power consumption .............................................................. 90 VA
q
Common specifications
•
Ambient operating temperature ................................ +10 to +30˚C
•
Ambient storage temperature ................................... –10 to +50˚C
•
Ambient operating/storage humidity ... 70% or less (non-condensing)
LASER SAFETY
Conforming to international laser safety standards (USA:21 CFR 1040.10
CDRH, other areas: IEC Pub.825), which obligate manufacturers to provide
preventive safety measures, Hamamatsu lasers are classified, and
appropriate safety measures and labeling are provided. Duaring operation,
users must also use their preventive safety measures according to laser-
related regulations.
q
Labels
Hamamatsu model PLP-10 uses lasers to be classified, Class 3B.
DIMENSIONAL OUTLINES (Unit: mm)
q
M8903 Laser diode head (approx. 0.5 kg)
Description Label (Sample)
Caution Label
q
C8898 Controller (approx. 5.1 kg)
OPERATION FREQUENCY (Hz)
EXT.TRIG.
LEVEL
800K
8M
80M
OPTICAL OUTPUT
SYNC.DELAY
(ns)
X1/5
INTERNAL TRIGGER
80K
8K
800
80
8
X1
X1/2
EMISSION
POWER
HEAD DRIVE
EXT.
18.1
86
117.4
9.4
+2
0
14.7
86
114
EXT.
TRIG.
(50Ω)
SYNC.
OUT.
(50Ω)
170
±2
28
28
33
33
232
±1
6
±2
98.5
±1
POWER
ADJUST.
READY
28
±2
255
±2
304.2
±1
40
60
40
60
- Window output type -
- FC connector output type -
ISO 9001
Certificate: 09 105 79045
5
Product and software package names noted in this documentation are trademarks or registered trademarks of their respective manufacturers.
q
q
Subject to local technical requirements and regulations, availability of products included in this promotional material may vary. Please consult with our sales office.
.
Information furnished by HAMAMATSU is believed to be reliable. However, no responsibility is assumed for possible inaccuracies or omissions.
Specifications and external appearance are subject to change without notice.
.
© 2003 Hamamatsu Photonics K.K.
Homepage Address http://www.hamamatsu.com
HAMAMATSU PHOTONICS K.K., Systems Division
812 Joko-cho, Hamamatsu City, 431-3196, Japan, Telephone: (81)53-431-0124, Fax: (81)53-435-1574, E-mail:export@sys.hpk.co.jp
U.S.A. and Canada:
Hamamatsu Photonic Systems: 360 Foothill Road, Bridgewater, N.J. 08807-0910, U.S.A., Telephone: (1)908-231-1116, Fax: (1)908-231-0852, E-mail: usa@hamamatsu.com
Germany:
Hamamatsu Photonics Deutschland GmbH: Arzbergerstr. 10, D-82211 Herrsching am Ammersee, Germany, Telephone: (49)8152-375-0, Fax: (49)8152-2658, E-mail: info@hamamatsu.de
,
France:
Hamamatsu Photonics France S.A.R.L.: 8, Rue du Saule Trapu, Parc du Moulin de Massy, 91882 Massy Cedex, France, Telephone: (33)1 69 53 71 00, Fax: (33)1 69 53 71 10, E-mail: infos@hamamatsu.fr
United Kingdom:
Hamamatsu Photonics UK Limited:
2 Howard Court, 10 Tewin Road, Welwyn Garden City, Hertfordshire, AL7 1BW,
U.K., Telephone: (44) 1707-294888, Fax: (44) 1707-325777, E-mail: info@hamamatsu.co.uk
North Europe:
Hamamatsu Photonics Norden AB: Smidesvägen 12, SE-171-41 Solna, Sweden, Telephone: (46)8-509-031-00, Fax: (46)8-509-031-01, E-mail: info@hamamatsu.se
-
Cat. No. SSCS1055E02
Italy:
Hamamatsu Photonics Italia S.R.L.: Strada della Mois, 1/E 20020 Arese (Milano), Italy, Telephone: (39)02-935 81 733, Fax: (39)02-935 81 741, E-mail: info@hamamatsu.it
AUG/2003 HPK
Created in Japan (PDF)
