H
Ø1
.02
Number of
Contacts
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Dimensions
A
2.54
5.08
7.62
10.16
12.70
15.24
17.78
20.32
22.86
25.40
27.94
30.48
33.02
35.56
38.10
40.64
43.18
45.72
48.26
50.80
53.34
55.88
58.42
60.96
63.50
66.04
68.58
71.12
73.66
76.20
78.74
81.28
83.82
86.36
88.90
91.44
93.98
96.52
99.06
B
5.58
8.12
10.66
13.20
15.74
18.28
20.82
23.36
25.90
28.44
30.98
33.52
36.06
38.60
41.14
43.68
46.22
48.76
51.30
53.84
56.38
58.92
61.46
64.00
66.54
69.08
71.62
74.16
76.70
79.24
81.78
84.32
86.86
89.40
91.94
94.48
97.02
99.56
102.10
2.54
2.50
2.54
G
Recommended PCB Layout
H=8.50: Pin = 0.60mm x 0.40mm
H=5.65: Pin = 0.74mm x 0.40mm
H=8.50: Minimum Insertion Depth = 2.00 ref.
H=5.65: Minimum Insertion Depth = 1.75 ref.
2.50
F
Minimum Insertion Depth
E
2.54
A±0.25
B±0.38
D
Specifications
规格
Material
物料
Contact
端子
: Copper Alloy
Insulator Material
绝缘½
:
Standard
标准
: Polyamide, Nylon 6T, UL 94V-0
Options
可选
: Polyester, LCP, UL 94V-0
Electrical
电气
Current Rating
电流额定值
: 3 Amp
Insulator Resistance
绝缘电阻值
: 1000 MΩ min.
Contact Resistance
接触电阻值
: 20 mΩ max.
Dielectric Withstanding
耐电压
: AC 600 V
Ordering Grid
C±0.2
H
BG115
No. of Contacts
02 to 40
XX
X
X
XXXX
X
X
Request Samples
and Quotation
29
30
31
32
33
34
35
36
37
38
39
40
C
Contact Plating
A = Gold Flash All Over (Standard)
B = Selective Gold Flash Contact
Area/Tin On Tail
C = Tin All Over
G = 10µ" Gold Contact Area/Tin On Tail
I = 30µ" Gold Contact Area/Tin On Tail
Insulator Height "H"
2 = 5.65mm
(Standard)
1 = 8.50mm
Packing Options
H = Tray
(Standard)
D = Tube
G = Plastic Box
(2 position only)
Insulator Material
N = Nylon 6T
(Standard)
L = LCP
Dimension C
(1/100mm) (Tail Length)
0320 = 3.20mm
(Standard where H = 8.50mm)
0300 = 3.00mm
(Standard where H = 5.65mm )
Or specify custom Tail Length
eg 0250 = 2.50mm
B
A
Environmental & Mechanical
机械
&
环境
Operating Temperature
工½温度
: -40° to +105°C
Soldering Process
可焊性
:
Nylon 6T (Standard
标准物料
) -
IR Reflow
回流焊
: 260°C for 10 sec.
Wave
波峰焊
: 230°C for 5-10 sec.
Manual Solder
人工焊接
: 350°C for 3-5 sec
LCP (Option
可选物料
) -
IR Reflow
回流焊
: 260°C for 10 sec.
Wave
波峰焊
: 250°C for 5-10 sec.
Manual Solder
人工焊接
: 350°C for 3-5 sec
Part Number
Product Description
BG115
Drawing Date
Mates with
配套之母座
(Subject
to pin length
在端子长度适合的条件下
)
BG025
BG040
BG045
BG050
BG065
BG070
BG085
30th October 2006
By
Detail
Revision
Date
AJO
BG115
G PCN
G
22/07/15
Length
2.54mm Pitch Socket
Single Row, Through-Hole, Vertical
Tolerances
(Except as Noted)
Angle
1
2
3
4
5
X.° ± 5°
X. ± 0.30
X.X° ± 2°
X.X ± 0.20
X.XX ± 0.15 X.XX° ± 1°
X.XXX ± 0.10 X.XXX° ± 0.5°
Units:
Metric (mm)
C
7
3rd Angle Projection
This drawing is confidential and
copyright of Global Connector
Technology, Ltd (GCT).
This drawing must not be copied
or disclosed without written
consent. E & OE
Global Connector Technology
GC
Drawn By
LYH
www.gct.co
Not to
Scale
Sheet No.
1/1
6
