Optiva OTS-2 40 GHz Unamplified
Microwave Band Fiber Optic Links
DATASHEET | APRIL 2019
MICROWAVE
Performance Highlights
Parameter
Frequency Range
RF Input Power
Wavelength
Optical Output Power
Operating Temperature Range
Min
1
--
--
9
-10
Typical
--
--
1550
--
--
Max
40
20
--
11
50
Units
GHz
dBm
nm
dBm
°C
40 GHz Wideband S21
Frequency Response
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to
the device. These are absolute stress ratings only. Functional operation of the device
is not implied at these or any other conditions in excess of those given in the opera-
tional sections of the datasheet. Exposure to absolute maximum ratings for extended
periods can adversely affect device reliability.
Parameter
Operating Temperature
Storage Temperature
RF Input
Symbol
T
OP
T
STG
S
in
Min
-20
-40
--
Max
60
85
25
Units
°
C
°
C
dBm
Enclosure Options
Transmitter & Receiver Optical Characteristics
Parameter
Wavelength
Optical Output Power
Connector Return Loss
Optical Connector Type
Receiver Optical Input Power
Receiver Responsivity
Symbol
l
P
L
--
--
Condition
--
Min
1530
9
40
--
--
0.5
Typical
1550
10
--
--
--
--
Max
1562
11
--
--
+10
--
Units
nm
dBm
dB
dBm
dBm
A/W
--
--
SC/APC
--
--
P
in
--
Note: In order to prevent reflection-induced distortion degradation, the laser should be connected to an optical cable having a return
loss of at least 55 dB for discrete reflections and 30 dB for distributed reflections.
Information contained herein is deemed to be reliable and accurate as of the issue date. EMCORE reserves the right to change the design or specifications at any time without notice.
EMCORE is a registered trademark of EMCORE Corporation in the U.S. and other countries.
Optiva OTS-2 40 GHz Unamplified
Microwave Band Fiber Optic Links
DATASHEET | APRIL 2019
MICROWAVE
Transmitter & Receiver RF Characteristics
Parameter
Operational Bandwidth
*
RF Input Impedance
RF Return Loss
Amplitude Flatness Tx
Amplitude Flatness Rx
2nd Harmonic Suppression
1 dB Compression Point
RF Connector
S
Out
- S
In
P
R
- S
Out
Symbol
Condition
--
--
--
Min
1
--
--
--
--
--
--
--
+15
+15
Typical
--
50
--
--
--
--
--
-70
--
Max
40
--
-6
2.5
11.0
3.5
9.0
-50
--
Units
GHz
ohm
dB
dB, p-p
dB, p-p
dBc
dBm
Any 500 MHz
1 GHz - 40 GHz
Any 500 MHz
1 GHz - 40 GHz
RF Input 0 dBm
@20 GHz
@40 GHz
2.92 mm (K) Female
*RF response below 50 MHz and above the maximum stated RF frequency is provided with degraded performance and not guaranteed.
**Test point performance beyond the stated frequency range is provided; only the test point reference value tolerance may increase beyond the
above stated +/- 1 dB
DC Power Consumption - Max
Module Type
Transmitter
Receiver
Input Voltage (VDC)
+12
+12
Max Current (@+70 oC)
750 mA
750 mA
Link Performance - 40 GHz Wideband
Parameter
RF Bandwidth
Link Gain (+10 dBmo Rx optical input)
*^
Link Gain (+0 dBmo Rx optical input)
*^
Noise Figure (+10 dBmo Rx optical input)
^
Input IP3
^
Spurious Free Dynamic Range
^
Gain Variation
Symbol
--
Condition
--
Min
1
-29
-33
-49
-53
--
--
25
25
-
-
--
--
Typical
--
--
--
--
--
--
--
--
--
105
95
--
--
Max
40
--
--
--
--
35
52
--
--
--
--
17.0
4.5
Units
GHz
dB
dB
dB
dBm
dB-Hz
2/3
dB
G
G
G
G
NF
NF
IIP3
IIP3
SFDR
SFDR
--
--
@ 20 GHz
@ 40 GHz
@ 20 GHz
@ 40 GHz
@ 20 GHz
@ 40 GHz
@ 20 GHz
@ 40 GHz
@ 20 GHz
@ 40 GHz
1 GHz - 40 GHz
Any 500 MHz
*Link Gain output will change 2 dB for every 1 dB of optical attenuation.
^Performance based on OTS-2T/K5 without EDFA unamplified, OTS-2R/K5 unamplified
Information contained herein is deemed to be reliable and accurate as of the issue date. EMCORE reserves the right to change the design or specifications at any time without notice.
EMCORE is a registered trademark of EMCORE Corporation in the U.S. and other countries.
Optiva OTS-2 40 GHz Unamplified
Microwave Band Fiber Optic Links
DATASHEET | APRIL 2019
MICROWAVE
Ordering Information: Transmitter
Transmitter
OTS-2T / K5-2.040-10-WW-XX-1-OO-Z
When ordering replace “WW
” with one of the ITU Channel Options
When ordering replace “XX
” with one of the Optical Connector Options
When ordering replace “Z
” with one of the Enclosure Options
ITU Channel Options
(THz / nm)
“WW”
Standard:
00 = non-ITU: 1520-1580 nm
Optional:
22 = 192.2 THz/1559.79 nm
23 = 192.3 THz/1558.98 nm
24 = 192.4 THz/1558.17 nm
25 = 192.5 THz/1557.36 nm
26 = 192.6 THz/1556.56 nm
27 = 192.7 THz/1555.75 nm
28 = 192.8 THz/1554.94 nm
29 = 192.9 THz/1554.13 nm
30 = 193 THz/1553.33 nm
31 = 193.1 THz/1552.52 nm
32 = 193.2 THz/1551.72 nm
33 = 193.3 THz/1550.92 nm
34 = 193.4 THz/1550.12 nm
35 = 193.5 THz/1549.32 nm
36 = 193.6 THz/1548.51 nm
37 = 193.7 THz/1547.72 nm
Optical
Connector
Options
“XX”
SA = SC / APC
FA = FC / APC
EA = E2000 / APC
RF
Amplifier
Enclosure Options
“Z”
00 = No Amp
1 = Optiva
Indoor
Rack-Mount Installation
2 = Optiva Outdoor
MiniHub Installation
Ordering Information: Receiver
Receiver
OTS-2R / K5-2.040-10-XX-00-1-1-00-Z
When ordering replace “XX” with one of the Optical Connector Options
When ordering replace “Z” with one of the Enclosure Options
Information contained herein is deemed to be reliable and accurate as of the issue date. EMCORE reserves the right to change the design or specifications at any time without notice.
EMCORE is a registered trademark of EMCORE Corporation in the U.S. and other countries.
Optiva OTS-2 40 GHz Unamplified
Microwave Band Fiber Optic Links
DATASHEET | APRIL 2019
MICROWAVE
Mechanical Configuration
Each Transmitter and Receiver module occupies two slots in the EMCORE Optiva Chassis.
RX Power, Link Status
& Optical I/P Level
Status Indicators
Laser & TX Power
Status Indicators
RF Output
RF Input
Laser Power Key
Optical Output
Optical Input
Comm Port
Comm Port
Optical Output
Laser Safety
Receiver
Transmitter
This product meets the appropriate standard in Title 21 of the Code of Federal Regulations (CFR). FDA/CDRH Class 1M laser
product. All versions of this laser are Class 1M laser product, tested according to IEC 60825-1:2007 / EN 60825-1:2007. An ad-
ditional warning for Class 1M laser products. For diverging beams, this warning shall state that viewing the laser output with certain
optical instruments (for example: eye loupes, magnifiers, and microscopes) within a distance of 100 mm may pose an eye hazard.
For collimated beams, this warning shall state that viewing the laser output with certain instruments designed for use at a distance
(for example: telescopes and binoculars) may pose an eye hazard.
Wavelength = 1.3/1.5 μm.
Maximum power = 30 mW.
INVISIBLE LASER RADIATION
AVOID DIRECT EXPOSURE
TO BEAM
INVISIBLE LASER RADIATION IS
EMITTED FROM THE END OF
FIBER OR CONNECTOR
Wavelength: 1.5 µm
Max. Output: 50 mW
Class 1M Laser Product
Avoid direct exposure to beam
Do not view beam directly with
optical instruments
INVISIBLE LASER RADIATION EMITTED FROM END OF FIBER OR CONNECTOR
CLASS 1M LASER PRODUCT IEC 60825-1:2007 EN 60825-1:2007
MAX OUTPUT: 50 mW WAVELENGTH: 1.5 µm (+ 1460 to 1620 nm)
Complies with 21 CRF 1040.10 and 1040.11 except for deviations pursuant
to Laser Notice No. 50, dated June 24, 2007
G8760-073-001 REV.3
*Caution - Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
*IEC is a registered trademark of the International Electrotechnical Commision.
