GS82582QT20E-400 datasheet, PDF

Datasheet> All Categories > storage> storage> GS82582QT20E-400

GS82582QT20E-400: DescriptionStandard SRAM, 16MX18, 0.45ns, CMOS, PBGA165, 15 X 17 MM, 1 MM PITCH, FPBGA-165; Categorystorage storage; File Size372KB，25 Pages; ManufacturerGSI Technology; Websitehttp://www.gsitechnology.com/

Download Datasheet Parametric View All

GS82582QT20E-400 Overview

Standard SRAM, 16MX18, 0.45ns, CMOS, PBGA165, 15 X 17 MM, 1 MM PITCH, FPBGA-165

GS82582QT20E-400 Parametric

Parameter Name	Attribute value
Objectid	1242103482
package instruction	LBGA,
Reach Compliance Code	compliant
Country Of Origin	Taiwan
ECCN code	3A991.B.2.A
YTEOL	8
Maximum access time	0.45 ns
JESD-30 code	R-PBGA-B165
length	17 mm
memory density	301989888 bit
Memory IC Type	STANDARD SRAM
memory width	18
Number of functions	1
Number of terminals	165
word count	16777216 words
character code	16000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	85 °C
Minimum operating temperature
organize	16MX18
Package body material	PLASTIC/EPOXY
encapsulated code	LBGA
Package shape	RECTANGULAR
Package form	GRID ARRAY, LOW PROFILE
Parallel/Serial	PARALLEL
Maximum seat height	1.5 mm
Maximum supply voltage (Vsup)	1.9 V
Minimum supply voltage (Vsup)	1.7 V
Nominal supply voltage (Vsup)	1.8 V
surface mount	YES
technology	CMOS
Temperature level	OTHER
Terminal form	BALL
Terminal pitch	1 mm
Terminal location	BOTTOM
width	15 mm

Preview

Download Datasheet

View All

Preliminary

GS82582QT20/38E-500/450/400/375

165-Bump BGA

Commercial Temp

Industrial Temp

Features

• 2.5 clock Latency

• Simultaneous Read and Write SigmaQuad™ Interface

• JEDEC-standard pinout and package

• Dual Double Data Rate interface

• Byte Write controls sampled at data-in time

• Dual-Range On-Die Termination (ODT) on Data (D), Byte

Write (BW), and Clock (K, K) inputs

• Burst of 2 Read and Write

• 1.8 V +100/–100 mV core power supply

• 1.5 V or 1.8 V HSTL Interface

• Pipelined read operation

• Fully coherent read and write pipelines

• ZQ pin for programmable output drive strength

• Data Valid Pin (QVLD) Support

• IEEE 1149.1 JTAG-compliant Boundary Scan

• 165-bump, 15 mm x 17 mm, 1 mm bump pitch BGA package

• RoHS-compliant 165-bump BGA package available

288Mb SigmaQuad-II+

Burst of 2 SRAM

500 MHz–375 MHz

1.8 V V

1.8 V and 1.5 V I/O

SRAMs. The GS82582QT20/38E SigmaQuad SRAMs are just

one element in a family of low power, low voltage HSTL I/O

SRAMs designed to operate at the speeds needed to implement

economical high performance networking systems.

Clocking and Addressing Schemes

The GS82582QT20/38E SigmaQuad-II+ SRAMs are

synchronous devices. They employ two input register clock

inputs, K and K. K and K are independent single-ended clock

inputs, not differential inputs to a single differential clock input

buffer.

Each internal read and write operation in a SigmaQuad-II+ B2

RAM is two times wider than the device I/O bus. An input data

bus de-multiplexer is used to accumulate incoming data before

it is simultaneously written to the memory array. An output

data multiplexer is used to capture the data produced from a

single memory array read and then route it to the appropriate

output drivers as needed. Therefore the address field of a

SigmaQuad-II+ B2 RAM is always one address pin less than

the advertised index depth (e.g., the 16M x 18 has an 8M

addressable index).

SigmaQuad™ Family Overview

The GS82582QT20/38E are built in compliance with the

SigmaQuad-II+ SRAM pinout standard for Separate I/O

synchronous SRAMs. They are 301,989,888-bit (288Mb)

Parameter Synopsis

-500

tKHKH

tKHQV

2.0 ns

0.45 ns

-450

2.2 ns

0.45 ns

-400

2.5 ns

0.45 ns

-375

2.66 ns

0.45 ns

Rev: 1.01 12/2012

1/25

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.

Preliminary

GS82582QT20/38E-500/450/400/375

Background

Separate I/O SRAMs, from a system architecture point of view, are attractive in applications where alternating reads and writes are

needed. Therefore, the SigmaQuad-II+ SRAM interface and truth table are optimized for alternating reads and writes. Separate I/O

SRAMs are unpopular in applications where multiple reads or multiple writes are needed because burst read or write transfers from

Separate I/O SRAMs can cut the RAM’s bandwidth in half.

SigmaQuad-II B2 SRAM DDR Read

The read port samples the status of the Address Input and R pins at each rising edge of K. A low on the Read Enable-bar pin, R,

begins a read cycle. Clocking in a high on the Read Enable-bar pin, R, begins a read port deselect cycle.

SigmaQuad-II B2 SRAM DDR Write

The write port samples the status of the W pin at each rising edge of K and the Address Input pins on the following rising edge of

K. A low on the Write Enable-bar pin, W, begins a write cycle. The first of the data-in pairs associated with the write command is

clocked in with the same rising edge of K used to capture the write command. The second of the two data in transfers is captured on

the rising edge of K along with the write address. Clocking in a high on W causes a write port deselect cycle.

Special Functions

Byte Write Control

Byte Write Enable pins are sampled at the same time that Data In is sampled. A High on the Byte Write Enable pin associated with

a particular byte (e.g., BW0 controls D0–D8 inputs) will inhibit the storage of that particular byte, leaving whatever data may be

stored at the current address at that byte location undisturbed. Any or all of the Byte Write Enable pins may be driven High or Low

during the data in sample times in a write sequence.

Each write enable command and write address loaded into the RAM provides the base address for a 2beat data transfer. The x18

version of the RAM, for example, may write 36 bits in association with each address loaded. Any 9-bit byte may be masked in any

write sequence.

Example x18 RAM Write Sequence using Byte Write Enables

Data In Sample Time

Beat 1

Beat 2

BW0

BW1

D0–D8

Data In

Don’t Care

D9–D17

Don’t Care

Data In

Resulting Write Operation

Byte 1

D0–D8

Written

Beat 1

Byte 2

D9–D17

Unchanged

Byte 3

D0–D8

Unchanged

Beat 2

Byte 4

D9–D17

Written

Rev: 1.01 12/2012

5/25

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
