DUAL-IN-LINE SOCKETS
Vertical Display Sockets
(See also page 61 for Right Angle DIP Sockets)
7,62
Series 296, 299, 594
2,54
12,7
3,6
1,27
0,64 DIA.
5,08
6,35
17,78
2,54
Fig. 1
11,0
1,5
2,0
6,35
9,91
8,2
5,3
0,5
1,6
1,1
1,3
0,64
2,79
5,08
2,54
2,29
2,29
2,54
0,64 DIA.
•
Series 296, 299 & 594 vertical display sockets
are used to mount dot matrix and 7-segment
LED displays at the edge of and perpendicular to
a printed circuit board. This positions the display
directly behind the translucent front panel of the
equipment.
•
Series 299 & 594 are through hole mount and
can be wave or intrusive reflow soldered.
•
Series 296 is surface mount and can be sup-
plied on carrier tape for automated “pick ‘n place”
assembly.
•
Insulators are high temp. Nylon 46, suitable for
all soldering processes including “lead-free”.
1,6
FOOTPRINT
Fig. 2
For RoHS compliance
select
plating code.
Fig.
No. of
pins
Ordering Information
299-99-210-12-001800
Plating Code
2002/95/EC
1
10
1,1
2,0
RoHS
20,96
1,91
1,27
17,78
1,57
4,45
2,79
296-XX-010-30-691800
(Discrete sockets)
2
13,81
2,5
0,51
10
296-XX-010-30-692800
(Supplied on 24mm wide carrier
tape per EIA-481: 450 per 330 reel)
10,0
2,54
3,43
1,27
5,0
15,0
2,97
7,62
19,05
10,0
1,27
0,64 DIA.
594-XX-020-01-007032
3
20
Plating Code
2002/95/EC
RoHS
For Electrical,
Mechanical & Enviromental
Data, See pg. 4
Fig. 3
XX=Plating Code
See Below
SPECIFY PLATING CODE XX=
99
44
Sleeve (Pin)
Contact (Clip)
5,08μm Sn/Pb 5,08μm Sn
5,08μm Sn/Pb 5,08μm Sn
w w w. m i l l - m a x . c o m
62
516-922-6000
