F-219
IDMD–24–D–12.00–G
(2.54 mm) .100"
SLIM BODY FLAT RIBBON IDC CABLES
SPECIFICATIONS
For complete specifications
see www.samtec.com?IDSS,
www.samtec.com?IDSD,
www.samtec.com?IDMS or
www.samtec.com?IDMD
Insulator Material:
Black Glass Filled Polyester
Plating:
Au over 50 µ" (1.27 µm) Ni or
Sn over 100 µ" (2.54 µm) Cu
or 50 µ" (1.27 µm) Ni
Wire:
28 AWG 7/36 stranded
Tinned Copper
Temperature Range:
-20 °C to +105 °C
(Rainbow Cable)
-40 °C to +105 °C
(Gray Cable)
Contact (IDSS/IDSD):
BeCu
Terminal (IDMS/IDMD):
Phosphor Bronze
Current Rating (IDSD/TST):
3.4 A per pin
(2 pins powered)
Current Rating (IDMD):
3 A per pin
(2 pins powered)
Lead Size Range:
(0.56 mm) .022" SQ to
(0.71 mm) .028" SQ
Lead Insertion Depth:
(5.59 mm) .220" to
(6.22 mm) .245"
RoHS Compliant:
Yes
Mates with:
TSW, MTSW, TSM, EJH,
PHT, HMTSW, HTSW,
HW, DW, EW, ZW, MTLW
IDSD Mates with:
TST, HTST, ZST,
BST, EJH
TYPE
STRIP
ROW
OPTION
NO. PINS
PER ROW
END
ASSEMBLY
= Single
S
–S
= Single
End
= Standard Tail Male Plug
IDM
IDS
= Socket
= Double
(Color coded
cable N/A for
31 thru 36
pins/row.
See –G
option.)
D
Socket or Male Plug on one end
–D
= Double
End
–02 thru –32
DOUBLE
Full size (64 positions):
(82.55) 3.250
Less than 64 positions:
No. Positions/row X (2.54) .100 + (1.68) .066
SINGLE
Full size (32 positions):
(81.53) 3.210
Less than 32 positions:
No. Positions/row X (2.54) .100 + (0.71) .028
IDMS
(Single)
(2.54)
.100
IDMD
(Double)
Socket or Male Plug on each end
(5.08)
.200
(6.10)
.240
MAX
–T
= Transfer
End
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
(0.48)
.019
(0.46)
.018
x
(0.48)
.019
(2.54)
.100
(3.18)
.125
(2.54)
.100
Male Plug on one end with socket on
other.
Begin part number with IDM.
FILE NO. E111594
(For square or long tail see HCMX Series)
–02 thru –36
DOUBLE
Full size (72 positions):
(92.71) 3.650
Less than 72 positions:
No. Positions/row x (2.54) .100 + (1.50) .059
SINGLE
Full size (36 positions):
(91.69) 3.610
Less than 36 positions:
No. Positions/row x (2.54) .100 + (0.48) .019
OTHER SOLUTIONS
Molded-To-Position
IDC Assemblies
IDSD
(Double)
(5.08)
.200
IDSS
(Single)
•
•
•
•
•
Low profile
Skinny side locks
Dual beam contacts
Single and double row
(3.05 mm) .120"
and (5.84 mm) .230"
length tail
available
(9.27)
.365
REF
Note:
This Series is non-standard,
non-returnable.
(2.54)
.100
(0.76)
.030
SQ
(2.54)
.100
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
IDSD–05–D–04.25–S02
IDSD–24–S–05.00
IDSS, IDSD, IDMS, IDMD SERIES
ASSEMBLED
LENGTH
OPTION
EJECTOR HEADERS
& LOCKING CLIPS
IDSS or IDSD
STRIP ASSEMBLY
= Assembled Length
Assembled Length in
INCHES (±
1
/
8
"
)
(2 inches minimum)
– “XX.XX”
• Ejector headers
• Locking clips
POLARIZING KEY
(0.64) .025
SQ
(5.84)
.230
Optional polarizing key for
use with IDSS & IDSD
Series. Also polarizes
SSW, SSQ, ESW & ESQ
Series. Black High
Temperature Thermoplastic
Order: Part Number PK-01-06
(Available in wheels of six each)
LOCKING
CLIP
PC
BOARD
.025" SQ
TERMINAL
STRIP (TSW)
See TSW Series.
See EJH Series.
–T
= Tin Plating
(Both ends)
–C
= 10 µ" (0.25 µm) Gold IDS
(-T End Assembly Required)
–A
= 10 µ" (0.25 µm) Gold IDM
Tin IDS
(-T End Assembly Required)
Tin IDM
= Stripped & Tinned
Specify Suffix from table.
All dimensions are ± 1/16".
Not available in 28 positions and higher.
–ST “X”
= Daisy Chain Single
“XX” ±
1
⁄
8
"
2"
min.
Single Row
Connectors
(IDSS)
–S “XX”
= Reversed
–R
Outer Most
4" minimum
Standard plating is selective
gold over BeCu contact for IDS;
Selective gold over phosphor
bronze for IDM.
1
–P “XX”
=Polarized
72
04
02
–ST8
–ST4
–ST2
–ST3
1/8" (3.18)
1/4" (6.35)
1/2" (12.70)
3/8" (9.53)
4
When mating double row
connector with two single row
connectors, the outer most
single will be connected to
Conductor #1 and the inside
single to Conductor #2.
8
= Middle Reversed
7
–M
–B “XX”
= Breakout
71
03
01
= Daisy Chain, Double
2"
min.
–D “XX”
Specify “XX” as position. For
Double the same position will
be polarized on both ends.
(Not available on IDM unless
transfer, then only the socket
is polarized.)
Specify “XX” as number of
conductors to be broken out.
“XX” ±
1
⁄
8
"
Double Row
Connectors
(IDSD or
IDMD)
Outer Most
Requires –SXX, –WXX or –DXX
8
2
“XX”
4" minimum
5"max.
2"min.
= Outside Reversed
–O
= Gray Cable
–G
7
Specify –G for Gray cable. Gray
cable has one red edge. IDSS
and IDMS uses .100" centerline
cable. IDSD and IDMD uses
.050" centerline cable. Cable is
28 AWG 7/36 copper wire.
Standard cable is same as
above except color coded.
3
Breakout starts with
Number 1 lead indicated
by brown wire or red stripe.
Shown on top side.
5
= Wiring Reversed
Daisy Chain, Single
–W “XX”
= Reversed Wiring
–RW
#1 wire opposite position #1.
6
Same as –S “XX” except outer
strip connected to Conductor
#2 and inside strip connected
to Conductor #1.
7
Requires –SXX, –WXX or –DXX
8
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
