Precision Ceramic
Ball Grid Arrays
CHC-Precision Series
•
Same footprint as the industry standard SOIC-N package
•
Superior TaNFilm
®
resistors on ceramic substrate
•
Custom array solutions also available
•
Absolute tolerances to ±0.1%
•
Ratio tolerances to ±0.05%
IRC Adv
Division
IRC Advanced Film Division
IRC's TaNFilm
®
ceramic Precision Ball Grid Array offers precision tolerances in a ceramic BGA package.
In addition, the TaNFilm
®
CHC Series provides all the unique qualities of our other TaNFilm
®
package
configurations.
Precise state-of-the-art laser trimming provides close tolerances and tight ratios. The TaNFilm
®
process
enables IRC to manufacture custom circuit configurations and multiple resistance values without
sacrificing the tightest tolerance and tracking characteristics of precision networks. The Tantalum Nitride
resistor material is self-passivating for environmental protection surpassing military requirements and
guaranteeing exceptional ratio stability.
For applications requiring a high degree of reliability, stability, accuracy and low noise, plus the advantages
of new resistor configurations, specify the IRC Precision Ceramic Ball Grid Arrays.
Electrical Data
Power R ating at 70° C
Package
Element
8-Pad
100mW
Network
400mW
Temperature
R ange
Maximum
Voltage
Noise
Substrate
Termination
Solder plated
over nickel
barrier
Solder plated
over nickel
barrier
Manufacturing Capabilities
Res i s t an c e
Ran g e
10
Ω
- 25
Ω
25.1
Ω
- 50
Ω
50.1
Ω
- 200
Ω
201
Ω
- 100K
Ω
Avai l abl e
Ab s o l u t e To l er an c es
J G F D C
J G F D C
J G F D C B
J G F D C B
Avai l abl e
Rat i o To l er an c es
(Rat i o t o R1)
G F D
G F D C
G F D C B
G F D C B A
B es t
Ab s o l u t e TCR
±100ppm/°C
±50ppm/°C
±25ppm/°C
±25ppm/°C
Tr ack i n g TCR
(Tr ack t o R1)
±20ppm/°C
±10ppm/°C
±5ppm/°C
±5ppm/°C
General Note
IRC reser ves the right to make changes in product specification without notice or liability.
All information is subject to IRC’s own data and is considered accurate at time of going to print.
A subsidiary of
TT electronics plc
CHC-Precision Series Issue March 2004
© IRC Advanced Film Division
• Cor pus Christi Texas 78411 USA
Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Email: afdsales@irctt.com • Website: www.irctt.com
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
50V
-55° C to + 50° C
1
(not to exceed
Ö
P
x
R )
50V
-55° C to + 50° C
1
(not to exceed
Ö
P
x
R )
< -25dB
99.5%
Alumina
99.5%
Alumina
16-Pad
100mW
800mW
< -25dB
Precision Ceramic
Ball Grid Arrays
Physical Data
A1
L
IRC Adv
Division
IRC Advanced Film Division
0.250”
±
0.003
# of Columns
“N”
4
8
Standard Schematics
(view from top)
Length “L”
0.200”
±
0.003
0.400”
±
0.003
1
A
2
3
4
CH4A
R1
(view from top)
E*
0.025”
±
0.010
0.050”
±
0.010
0.058”
±
0.005
0.025”
±
0.003
1
A
2
3
4
5
6
7
8
E*
CH8A
0.200”
±
0.010
99.6% Alumina
Substrate
A
N
1
2
(view from bottom)
* Rows B,C, & D not populated
R1
E*
0.030” ±0.002
10/90 Sn/Pb
Solder Balls
Environmental Data
Environmental Test
per MIL-PRF-83401
Thermal Shock and
Power Conditioning
Low Temperature Operation
Short Time Overload
Moisture Resistance
Shock
Vibration
Life
High Temperature Exposure
Low Temperature Storage
Maximum
∆R
±0.1%
±0.05%
±0.05%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±0.05%
Typical
∆R
±0.02%
±0.02%
±0.02%
±0.03%
±0.03%
Power Derating
100
% Of Rated Power
50
10
25°
70°
150°
±0.03%
±0.03%
±0.03%
±0.01%
Temperature in °C
© IRC Advanced Film Division
• Cor pus Christi Texas 78411 USA
Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Email: afdsales@irctt.com • Website: www.irctt.com
CHC-Precision Series Issue March 2004
Precision Ceramic
Ball Grid Arrays
Ordering Procedure
○
○
○
○
○
○
○
○
○
IRC Adv
Division
IRC Advanced Film Division
CH4A: 8-pad
CH8A:16-pad
○
○
○
○
○
○
○
○
01 = ±100ppm/°C Commercial Grade
02 = ±50ppm/°C Commercial Grade
03 = ±25ppm/°C Commercial Grade
○
○
○
○
○
For additional information or to discuss your specific requirements,
please contact our Applications Team using the contact details below.
© IRC Advanced Film Division
• Cor pus Christi Texas 78411 USA
Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Email: afdsales@irctt.com • Website: www.irctt.com
CHC-Precision Series Issue March 2004
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
TCR Code
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
Model
○
○
○
○
○
○
○
○
○
Prefix
CHC - CH8A - 03 - 1002 - B
B
Optional R1 Ratio Tolerance Code
F = ±1%; D = ±0.5%; B = ±0.1%; A = ±0.05%
Absolute Tolerance Code
J = ±5%; G = ±2%; F = ±1%
D = ±0.5%; C = ±0.25%; B = ±0.1%
Resistance Code
4-Digit resistance code
Ex: 1002 = 10KΩ; 49R9 = 49.9Ω
