Cannon, VEAM, BIW
Defining and Championing Innovation
A Historical Achievement of Technology Leadership
Showcasing a portfolio of creativity, ITTʼs “Engineered For Life” execution embraces products which have become
ubiquitous in a broad collection of markets including: Military/Aerospace, Civil Aircraft, Industrial Instrumentation,
Medical, Oil & Gas, Energy, Transportation, Telecom/Handset, Computer, Consumer, and Automotive.
ITTʼs rich interconnect history embraces contributions to both technological breakthroughs and social movements.
With one of the industryʼs broadest product offerings, ITTʼs interconnect products have supported:
•
•
•
•
•
Every Free World space mission, bringing the universe to our doorstep.
Motion picture, radio, and television equipment, serving laughter and entertainment to millions.
Computerized tools, reshaping the information highway.
•
Commercial and military communications systems, linking the voices of the world.
Aircraft, rapid transit, and automobiles, mobilizing our expanding society.
Oil and natural gas production, powering the worldʼs economies.
Agricultural equipment, attacking the roots of world hunger.
•
First
“Cannon Plug”
4 Pole Power
Connector
Cannon pioneers
sound and film
connectors with
the M Series
Cannon creates
“K” series
connectors for
DC-1’s
The first aviation
circular & rack
panel connectors
developed by
Cannon
Cannon creates
“AN” military
plugs
Cannon develops
the first
Tri-Service
connector, the
mother of modern
day military
spec’s
Cannon originates
the first “D-Sub”
connectors
Cannon pioneers
guided missle
umbilical
connectors
The first commercial and power connectors
Cannon connectors made possible the first
radio microphones, the first black and white
television cameras as well as the first
color television equipment.
leaders to develop
the first complete
fiber optic
systems
Cannon develops Cannon establishes
the first “Micro” an aviation milestone
through the expansion
connectors
of Rack and Panel
connectors with the
Cannon partners
BKAD/E Series
with technology
1980
+2000
Breakaway
Technology
Leadership
Lean
manufacturing
Internet deployed
systems
Pioneering
technologies
Engineered
solutions
Growth
Chip-on-Flex
PHD
Cannon
founded by
James Cannon
Cannon’s
Cannon’s AF
Firewall connectors X connector is the
first microminiature
used in early
audio connector
DC-3 transports
1950
1940
1970
1960
Quadrax
1915
1920
1930
The
Beginning
Power, Film,
Commercial
Photo courtesy of The Academy of
Motion Pictures, Arts and Sciences.
Cannon’s first entry
into the Medical
Electronics market
Military
Telecom
Space
Medical,
Transportation
Stacking
Charting
the Future
Aviation
2
www.ittcannon.com
ITT Interconnect Solutions
ITT Interconnect Solutions is a division of the multi-
national ITT Corporation, a $7.8 billion dollar global
enterprise representing the brands Cannon, VEAM,
and BIW. Our connector portfolio remains the most
extensive in the industry offering the most reliable and
cost effective range of interconnect solutions. These
innovations have enabled ITT to provide products and
technologies to such markets as:
•
•
•
•
•
•
•
Automotive
Computer/Consumer
Industrial/Instrumentation
Military/Aerospace
Oil Fields
Telecom/Handset
Transportation
advanced manufacturing facilities allows ITT to offer
products at market driven prices. Our capabilities,
especially in robotics, computerized precision tooling,
Kaizen Project Management, Six Sigma tools, and
testing, give ITT the most optimized global manufactur-
ing footprint in the interconnect industry.
The Custom Difference
As the industry leader in harsh environment intercon-
nect applications, ITT’ s world class engineering
teams will work directly with our customers to design
and develop cost effective solutions for their applica-
tions. In many cases we may modify one of our stan-
dard designs to ensure a highly reliable solution where
timing is critical. Yet, in those cases where a complete
custom interconnect solution is required, ITT will work
with our customer’ s Engineers to design an intercon-
nect solution which will be cost effective yet highly
reliable. As professional consultants, our Engineering
teams will provide a thorough systems and mechanical
analysis of any proposed solution. These analyses
provide our customers with sophisticated electrical
signal and mechanical characterizations to determine
the best solution for their application.
When you specify a Cannon, VEAM or BIW connector,
you can rely on a product designed, developed, and
manufactured to the highest quality and reliability
standards. This tradition of excellence is based on
ITT’ s corporate culture of operating its businesses
under the principles of Six Sigma. At ITT, Six Sigma is
not just a quality philosophy but a complete corporate
culture that drives the entire business. Our Value Based
Management and Value Based Product Development
systems are two cornerstones that allow for the
development of both leadership and product
engineering principles, ensuring the correct industry
leading products are developed to the
accepted market driven lead times. These principles
have allowed ITT to become the market leader in all of
our business portfolios.
RoHS Compliance Information
ITT has implemented a strict parts control plan for all
ITT electronics plants worldwide that allows the
Cannon, VEAM, and BIW connector product portfolios
to meet the requirements of European Union Directive
2002/95/EC better know as the Reduction of
Hazardous Substances initiative. As appropriate,
specific Cannon, VEAM, and BIW products may be
ordered with an R prefix number which insures our cus-
tomers will receive RoHS compliant parts for their com-
mercial electronics applications and equipment. Since
most RoHS hazardous substances center around spe-
cific metal plating and lead solder coatings, ITT's prod-
ucts for RoHS compliance are available in the following
plating finishes: electroless nickel, stainless steel,
Anodize over aluminum and Gold plating. It should be
noted that gold plating would be recommended
as the replacement for tin-lead solder when
ordering board mount connectors.
Six Sigma Manufacturing
ITT operates manufacturing facilities in the United
States, Germany, Italy, Mexico, China, Japan and the
UK, all of which have particular product area strengths
allowing ITT to offer a truly global footprint to our
customers. Our facilities are world class and
accommodate full vertical integration utilizing the latest
manufacturing technologies including: automated and
robotic machining centers, Super Market manufacturing
cells, Kanban pull systems, and automated electrical,
mechanical, and optical test and inspection equipment.
The combination of our manufacturing strength and our
www.ittcannon.com
3
Cannon
Table of Contents
Quadrax
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Overview Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
How to Order Quadrax Circular Connector, KJAQ Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
KJAQ0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
KJAQ2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
KJAQ6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
KJAQ7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Insert Arrangements KJAQ Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
How to Order Rack and Panel Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
BKA Connector Layouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Size 2 and 3
Insert Arrangement Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-15
Insert Arrangements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Contact Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cannon Quadrax Overview Guide
BKAD/E/F
ARINC 600
KJAQ
MIL-DTL 38999
Quadrax Specifications
Size
Current Rating
Contact Resistance
Contact Material
Shell Material
Platings
Termination Type
Gender
Size 5 & 8
see ARINC 600
see ARINC 600
Copper Alloy
Copper Alloy
Gold over Nickel
P.C. Solder & Crimp
Pin/Receptacle Socket/Plug
Size 8
see ARINC 600
see ARINC 600
Copper Alloy
Copper Alloy
Gold over Nickel
P.C. Solder & Crimp
Pin & Socket in Either Housing
www.ittcannon.com
5
