RJ-1.824SHP: Description1 watt dip14 single & dual output; File Size107KB，3 Pages; ManufacturerRECOM Power GmbH; Websitehttps://www.recom-power.com/

Download Datasheet View All

RJ-1.824SHP Overview

1 watt dip14 single & dual output

Preview

Download Datasheet

View All

Features

Unregulated

Converters

Selection Guide

Part

Number

DIP 14

RJ-xx1.8S

RJ-xx3.3S

RJ-xx05S

RJ-xx09S

RJ-xx12S

RJ-xx15S

RJ-xx24S

RG-xx1.8D

RG-xx3.3D

RG-xx05D

RG-xx09D

RG-xx12D

RG-xx15D

RG-xx24D

4kV

(H)

●

Dual Output from a Single Input Rail

3kVDC & 4kVDC Isolation

Optional Continuous Short Circuit Protected

Custom Solutions Available

UL94V-0 Package Material

Efficiency to 84%

ECONOLINE

DC/DC-Converter

Series

1 Watt

DIP14

Single

Dual

Output

Input

Voltage

(VDC)

1.8, 3.3, 5, 9, 12, 15, 24

Output

Voltage

(VDC)

1.8

3.3

±1.8

±3.3

±5

±9

±12

±15

±24

Output

Current

(mA)

303

200

111

±152

±100

±56

±42

±33

±21

Efficiency

(%)

70-78

78-82

74-83

70-78

75-80

78-84

80-84

xx = Input Voltage

* add Suffix “P” for Continuous Short Circuit Protection, e.g.

RJ-0505S/P, RG-0505D/HP

EN-60950-1 Certified

EN-60601-1 Certified

Specifications

(Core Operating Area)

Input Voltage Range

Output Voltage Accuracy

Line Voltage Regulation

Load Voltage Regulation

(10% to 100% full load)

Output Ripple and Noise (20MHz limited)

Operating Frequency

Efficiency at Full Load

No Load Power Consumption

Isolation Voltage

Rated Working Voltage

Isolation Voltage

Rated Working Voltage

Isolation Capacitance

Isolation Resistance

Short Circuit Protection

P-Suffix

Operating Temperature Range (free air convection)

Storage Temperature Range

Relative Humidity

Package Weight

H-Suffix

(tested for 1 second)

(long term isolation)

(tested for 1 second)

(long term isolation)

±10%

±5%

1.2%/1% of Vin typ.

1.8V, 3.3V output types

20% max.

5V output type

15% max.

9V, 12V, 15V, 24V output types

10% max.

100mVp-p max.

57kHz min. / 90kHz typ. / 105kHz max.

70% min. / 80% typ.

102mW min./180mW typ./260mW max.

3000VDC min.

see Application Notes.

4000VDC min.

see Application Notes

Output Power (%)

100

Derating-Graph

(Ambient Temperature)

20pF min. / 65pF max.

15 GΩ min.

1 Second

Continuous

-40°C to +85°C (see Graph)

-55°C to +125°C

95% RH

2.5g

continued on next page

Safe Operating Area

Operating Temperature °C

-40

100

150

www.recom-international.com

July-2006
