ST
Vishay
SuperTan
®
Wet Tantalum Capacitors
with Hermetic Seal
FEATURES
•
Terminations: Standard Tin/lead (Sn/Pb)
100 % Tin (RoHS compliant)
availableTerminations:
•
Very High Capacitance
•
10 to 1800 µF
•
25 to 125 VDC
•
- 55 °C to + 125 °C
•
Very Low ESR
•
High Ripple Current
•
All Tantalum Case
•
Hermetically Sealed
•
Low DCL
Pb-free
Available
RoHS*
COMPLIANT
Application Notes
Vishay ST represents a major breakthrough in wet tantalum
capacitor technology. Its unique cathode system provides
the highest capacitance per unit volume. The design
facilitates a doubling of capacitance, lower ESR and higher
ripple current rating compared with conventional wet
tantalum products. Moreover, the ST has the capacitance
stability of a solid tantalum capacitor and there are no circuit
impedance restrictions.
The ST is housed in an all tantalum, hermetically sealed case
and is manufactured to withstand hazardous environments.
The ST is used widely in the defense and aerospace
industries and whenever there is a space problem
a) No continuous reverse voltage permissible.
b)Transient reverse voltage surges are acceptable under
the following conditions:
The peak reverse voltage does not exceed 1.5 V and the
peak current times the duration of the reverse transient
does not exceed 0.05 ampere seconds. In addition, the
repetition frequency of the reverse voltage surge is less
than 10 Hz.
c) The peak of the applied AC ripple and the applied DC
voltage must not exceed the DC voltage rating of the
capacitor.
d) Ripple current ratings by part number at 85 °C and 40 kHz
are included in the table. Ripple current correction factors
for other temperatures and frequencies are given on the
next page.
DIMENSIONS
in inches [millimeters]
TERMINAL WELDED
TO CASE
0.250 (6.35)
MAX.
0.025 + 0.002
(0.64 + 0.05)
0.094 (2.38)
MAX.
E
L
E
"D" DIA.
TERMINAL LOCATION
WITHIN 0.031 OF CENTER
CASE CODE
D MAX. INSULATED
D ± 0.016 (0.41)
T1
0.219 (5.56)
0.188 (4.78)
T2
0.312 (7.92)
0.281 (7.14)
L2
0.312 (7.92)
0.281 (7.14)
T3
0.406 (10.31)
0.375 (9.52)
T4
0.406 (10.31)
0.375 (9.52)
NOTES:
1. Material at egress is tantalum
2. Insulation sleeving will lap over the ends of the capacitor case.
L + 0.031 (0.79) UNINSULATED
0.453 (11.51)
0.641 (16.28)
1.008 (25.60)
0.766 (19.46)
1.062 (26.97)
Approx. Weight
T1: 2.3 grams, T2: 5.7 grams
T3: 9.4 grams, T4: 14.8 grams
E ± 0.250 (6.35) MAX.
1.500 (38.10)
2.250 (57.15)
2.250 (57.15)
2.250 (57.15)
2.250 (57.15)
ORDERING INFORMATION
ST
SUPERTAN
COMMERCIAL
CAP.TYPE*
220
CAPACITANCE
µF
100
85 °C RATED DC
VOLTAGE
T4
CASE CODE
M
CAPACITANCE
TOLERANCE
M = ± 20 %
M = ± 10 %
I
INSULATING
SLEEVE
I = Insulated
X = Uninsulated
E3
RoHS COMPLIANT
E3 = 100 % tin termination
(RoHS compliant)
Blank = SnPb termination
(standard design)
NOTES:
1. See DSCC drawing 93026 for MIL version of SuperTan.
* Pb containing terminations are not RoHS compliant, exemptions may apply
www.vishay.com
1
For technical questions, contact: wettants@vishay.com
Document Number: 43000
Revision: 29-MAR-07
SuperTan® Wet Tantalum Capacitors
with Hermetic Seal
RATINGS AND CASE CODES
CAP. AT
25 °C
&
120 Hz
(µF)
CASE
CODE
MAX.
ESR
Ω
120 Hz
MAX. DCL µA
25 °C
85 °C
& 125 °C
MAX. IMP.
AT
- 55 °C
& 120 Hz
Ω
MAXIMUM CAPACITANCE
CHANGE %
- 55 °C
85 °C
AC RIPPLE
85 °C
40 kHz
125 °C
mA
rms
15 VDC at 125 °C
+ 12
1250
+ 15
2100
+ 30
2500
+ 18
2600
+ 20
3100
20 VDC at 125 °C
+ 12
1200
+ 18
1800
+ 30
2200
+ 18
2500
+ 20
3000
30 VDC at 125 °C
+ 15
1050
+ 15
1800
+ 15
2200
+ 15
2100
+ 20
2750
40 VDC at 125 °C
+ 12
1050
+ 15
1800
+ 35
2200
+ 15
2100
+ 15
2750
50 VDC at 125 °C
+9
1050
+ 10
1650
+ 15
2000
+ 10
2100
+ 10
2750
65 VDC at 125 °C
+ 10
1050
+ 12
1650
+ 15
1800
+ 12
2100
+ 12
2750
85 VDC at 125 °C
+ 10
1050
+ 12
1650
+ 10
1800
+ 12
2100
+ 12
2750
ST
Vishay
PART NUMBER
25 VDC at 85 °C
120
T1
1.3
1
5
25
- 42
+8
ST120-25T1MI
560
T2
0.83
2
10
12
- 65
+ 10
ST560-25T2MI
1100
L2
0.5
3
25
7
- 60
+ 15
ST1100-25L2MI
1200
T3
0.65
5
20
7
- 70
+ 12
ST1200-25T3MI
1800
T4
0.5
6
25
7
- 72
+ 12
ST1800-25T4MI
30 VDC at 85 °C
100
T1
1.3
1
5
25
- 38
+8
ST100-30TMI
470
T2
0.85
2
10
15
- 65
+ 10
ST470-30T2MI
950
L2
0.5
5
30
7
- 45
+ 15
ST950-30L2MI
1000
T3
0.7
7
25
7
- 70
+ 10
ST1000-30T3MI
1500
T4
0.6
12
35
6
- 72
+ 10
ST1500-30T4MI
50 VDC at 85 °C
68
T1
1.5
1
5
35
- 25
+8
ST68-50T1MI
220
T2
0.9
2
10
17.5
- 50
+8
ST220-50T2MI
450
L2
0.6
3
25
7
- 45
+ 10
ST450-50L2MI
470
T3
0.75
3
25
10
- 45
+8
ST470-50T3MI
680
T4
0.7
5
40
8
- 58
+ 10
ST680-50T4MI
60 VDC at 85 °C
47
T1
2.0
1
5
44
- 25
+8
ST47-60T1MI
150
T2
1.1
2
10
20
- 40
+8
ST150-60T2MI
370
L2
0.6
3
25
9
- 30
+ 10
ST370-60L2MI
390
T3
0.9
3
25
15
- 45
+8
ST390-60T3MI
560
T4
0.8
5
40
10
- 58
+8
ST560-60T4MI
75 VDC at 85 °C
33
T1
2.5
1
5
66
- 25
+5
ST33-75T1MI
110
T2
1.3
2
10
24
- 35
+6
ST110-75T2MI
250
L2
0.8
5
30
10
- 20
+5
ST250-75L2MI
330
T3
1.0
3
30
12
- 45
+6
ST330-75T3MI
470
T4
0.9
5
50
12
- 50
+6
ST470-75T4MI
100 VDC at 85 °C
15
T1
3.5
1
5
125
- 18
+3
ST15-100T1MI
68
T2
2.1
2
10
37
- 30
+4
ST68-100T2MI
120
L2
1.0
3
25
18
- 20
+5
ST120-100L2MI
150
T3
1.6
3
25
22
- 35
+6
ST150-100T3MI
220
T4
1.2
5
50
15
- 40
+6
ST220-100T4MI
125 VDC at 85 °C
10
T1
5.5
1
5
175
- 15
+3
ST10-125T1MI
47
T2
2.3
2
10
47
- 25
+5
ST47-125T2MI
90
L2
1.3
5
15
24
- 15
+5
ST90-125L2MI
100
T3
1.8
3
25
35
- 35
+5
ST100-125T3MI
150
T4
1.6
5
50
20
- 35
+6
ST150-125T4MI
(K = ± 10 %, M = ± 20 %) and insulation letter (I = Insulation, X = Uninsulated)
• Part Numbers shown are for units with ± 20 % capacitance tolerance and uninsulated capacitors. For ± 10 units,changethe digit following the
letter “X” from “0” to “9”. For units with outer plastic-film insulation, substitute “2” for “0” at the end of the Part Number.
• For RoHS compliant add “E3” suffix.
RIPPLE CURRENT MULTIPLIERS VERSUS FREQUENCY, TEMPERATURE AND APPLIES PEAK VOLTAGE
FREQUENCY OF
APPLIED
RIPPLE
CURRENT
120 Hz
800 Hz
1 kHz
10 kHz
40 kHz
100 kHz
AMBIENT STILL
≤
55 85 105 125
≤
55 85 105 125
≤
55 85 105 125
≤
55 85 105 125
≤
55 85 105 125
≤
55 85 105 125
AIR TEMP. IN °C
100 %
% of
90 %
85 °C
80 %
rated
70 %
peak
voltage
66 2/3 %
0.60
0.60
0.60
0.60
0.60
0.39 -
-
0.46 -
-
0.52 0.35 -
0.58 0.44 -
0.60 0.46 0.27
0.71
0.71
0.71
0.71
0.71
0.43 -
-
0.55 -
-
0.62 0.42 -
0.69 0.52 -
0.71 0.55 0.32
0.72
0.72
0.72
0.72
0.72
0.46 -
-
0.55 -
-
0.62 0.42 -
0.70 0.52 -
0.72 0.55 0.32
0.88
0.88
0.88
0.88
0.88
0.55 -
-
0.67 -
-
0.76 0.52 -
0.85 0.64 -
0.88 0.68 0.40
1.0
1.0
1.0
1.0
1.0
0.63 -
-
0.77 -
-
0.87 0.59 -
0.97 0.73 -
1.0 0.77 0.45
1.1
1.1
1.1
1.1
1.1
0.69 -
-
0.85 -
-
0.96 0.65 -
1.07 0.80 -
1.1 0.85 0.50
Document Number: 43000
Revision: 29-MAR-07
For technical questions, contact: wettants@vishay.com
www.vishay.com
2
