Three-state outputs drive bus lines or buffer memory address
registers
1.2μ
CMOS
- Latchup immune
High speed
Low power consumption
Single 5 volt supply
Available QML Q or V processes
Flexible package
- 20-pin DIP
- 20-lead flatpack
UT54ACS244 - SMD 5962-96570
UT54ACTS244 - SMD 5962-96571
DESCRIPTION
The UT54ACS244 and the UT54ACTS244 are non-inverting
octal buffer and line drivers which improve the performance and
density of three-state memory address drivers, clock drivers, and
bus-oriented receivers and transmitters.
The devices are characterized over full military temperature
range of -55°C to +125°C.
FUNCTION TABLE
INPUTS
1G, 2G
L
L
H
A
L
H
X
OUTPUT
Y
L
H
Z
PINOUTS
20-Pin DIP
Top View
1G
1A1
2Y4
1A2
2Y3
1A3
2Y2
1A4
2Y1
V
SS
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
V
DD
2G
1Y1
2A4
1Y2
2A3
1Y3
2A2
1Y4
2A1
20-Lead Flatpack
Top View
1G
1A1
2Y4
1A2
2Y3
1A3
2Y2
1A4
2Y1
V
SS
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
V
DD
2G
1Y1
2A4
1Y2
2A3
1Y3
2A2
1Y4
2A1
LOGIC SYMBOL
1G
1A1
(1)
(2)
EN
(18)
(16)
(14)
(12)
1Y1
1Y2
1Y3
1Y4
(4)
1A2
(6)
1A3
(8)
1A4
(19)
(11)
2G
2A1
EN
(9)
(7)
(5)
(3)
2Y1
2Y2
2Y3
2Y4
(13)
2A2
(15)
2A3
(17)
2A4
Note:
1. Logic symbol in accordance with ANSI/IEEE Std 91-1984 and IEC
Publication 617-12.
1
LOGIC DIAGRAM
1G (1)
2G (19)
1A1
(2)
(18)
1Y1
2A1
(11)
(9)
2Y1
1A2
(4)
(16)
1Y2
2A2
(13)
(7)
2Y2
1A3
(6)
(14)
1Y3
2A3
(15)
(5)
2Y3
1A4
(8)
(12)
1Y4
2A4
(17)
(3)
2Y4
2
OPERATIONAL ENVIRONMENT
1
PARAMETER
Total Dose
SEU Threshold
2
SEL Threshold
Neutron Fluence
LIMIT
1.0E6
80
120
1.0E14
UNITS
rads(Si)
MeV-cm
2
/mg
MeV-cm
2
/mg
n/cm
2
Notes:
1. Logic will not latchup during radiation exposure within the limits defined in the table
2. Device storage elements are immune to SEU affects.
ABSOLUTE MAXIMUM RATINGS
SYMBOL
V
DD
V
I/O
T
STG
T
J
T
LS
Θ
JC
I
I
P
D
Note:
1. Stresses outside the listed absolute maximum ratings may cause permanent damage to the device. This is a stress rating only, functional operation of the device at
these or any other conditions beyond limits indicated in the operational sections is not recommended. Exposure to absolute maximum rating conditions for extended
periods may affect device reliability.
PARAMETER
Supply voltage
Voltage any pin
Storage Temperature range
Maximum junction temperature
Lead temperature (soldering 5 seconds)
Thermal resistance junction to case
DC input current
Maximum power dissipation
LIMIT
-0.3 to 7.0
-.3 to V
DD
+.3
-65 to +150
+175
+300
20
±10
1
UNITS
V
V
°C
°C
°C
°C/W
mA
W
RECOMMENDED OPERATING CONDITIONS
SYMBOL
V
DD
V
IN
T
C
PARAMETER
Supply voltage
Input voltage any pin
Temperature range
LIMIT
4.5 to 5.5
0 to V
DD
-55 to + 125
UNITS
V
V
°C
3
DC ELECTRICAL CHARACTERISTICS
7
(V
DD
= 5.0V
±
10%; V
SS
= 0V
6
, -55°C < T
C
< +125°C); Unless otherwise noted, Tc is per the temperature range ordered.
SYMBOL
V
IL
PARAMETER
Low-level input voltage
1
ACTS
ACS
High-level input voltage
1
ACTS
ACS
Input leakage current
ACTS/ACS
Low-level output voltage
3
ACTS
ACS
High-level output voltage
3
ACTS
ACS
Output current
10
(Sink)
I
OH
Output current
10
(Source)
I
OZ
I
OS
P
total
I
DDQ
ΔI
DDQ
Three-state output leakage current
Short-circuit output current
2 ,4
ACTS/ACS
Power dissipation
2,8,9
Quiescent Supply Current
Quiescent Supply Current Delta
ACTS
V
IN
= V
DD
or V
SS
I
OL
= 12.0mA
I
OL
= 100μA
I
OH
= -12.0mA
I
OH
= -100μA
V
IN
= V
DD
or V
SS
V
OL
= 0.4V
V
IN
= V
DD
or V
SS
V
OH
= V
DD
- 0.4V
V
O
= V
DD
and V
SS
V
O
= V
DD
and V
SS
C
L
= 50pF
V
DD
= 5.5V
For input under test
V
IN
= V
DD
- 2.1V
For all other inputs
V
IN
= V
DD
or V
SS
V
DD
= 5.5V
C
IN
C
OUT
Input capacitance
5
Output capacitance
5
ƒ
= 1MHz @ 0V
ƒ
= 1MHz @ 0V
15
15
pF
pF
-30
-300
30
300
2.0
10
1.6
μA
mA
mW/
MHz
μA
mA
-12
mA
.7V
DD
V
DD
- 0.25
12
.5V
DD
.7V
DD
-1
1
0.40
0.25
CONDITION
MIN
MAX
0.8
.3V
DD
UNIT
V
V
IH
V
I
IN
V
OL
μA
V
V
OH
V
I
OL
mA
4
Notes:
1. Functional tests are conducted in accordance with MIL-STD-883 with the following input test conditions: V
IH
= V
IH
(min) + 20%, - 0%; V
IL
= V
IL
(max) + 0%, -
50%, as specified herein, for TTL, CMOS, or Schmitt compatible inputs. Devices may be tested using any input voltage within the above specified range, but are
guaranteed to V
IH
(min) and V
IL
(max).
2. Supplied as a design limit but not guaranteed or tested.
3. Per MIL-PRF-38535, for current density
≤
5.0E5 amps/cm
2
, the maximum product of load capacitance (per output buffer) times frequency should not exceed 3,765
pF/MHz.
4. Not more than one output may be shorted at a time for maximum duration of one second.
5. Capacitance measured for initial qualification and when design changes may affect the value. Capacitance is measured between the designated terminal and V
SS
at
frequency of 1MHz and a signal amplitude of 50mV rms maximum.
6. Maximum allowable relative shift equals 50mV.
7. All specifications valid for radiation dose
≤
1E6 rads(Si).
8. Power does not include power contribution of any TTL output sink current.
9. Power dissipation specified per switching output.
10. This value is guaranteed based on characterization data, but not tested.
