RoHS Compliant
Pb - Lead Free
Ltr
Revisions
Date
Appr
Electrical Specifications:
Frequency Range
0.500 to 156.000
MHz
±100
±50
±30
PPM Max
±25
±20
±3
-10 to +70
-40 to +85
ºC
-55 to +125
1.8 ± 5% 2.5 ± 5% 3.3 ± 10%
Vdd
5
6
7
5
8
7
6
8
12
mA Max
15
20
20
15
20
25
20
25
30
25
30
40
90% (80% at 1.8)
Vdd Min
10% (20% at 1.8)
Vdd Max
40 to 60
%
45 to 55
15
pF Max
5
5
10
5
5
10
ns Max
4
4
8
3
3
5
3
3
4
1
1 ps Max RMS
Tri-State
-
150
300
ns Max
10
10
ms Max
10
ms Max
Temperature Stability
Aging per Year
Operating Temperature Range
Storage Temperature Range
Supply Voltage
0.500 to 9.999 MHz
10.000 to 19.999 MHz
20.100 to 31.999 MHz
32.000 to 49.999 MHz
50.000 to 79.999 MHz
80.000 to 99.999 MHz
100.000 to 156.000 MHz
Logic High (Voh)
Logic Low (Vol)
Standard
Tight
0.500 to 31.999 MHz
32.000 to 49.999 MHz
50.000 to 79.999 MHz
80.000 to 99.999 MHz
100.000 to 156.000 MHz
Standard
Extended
Input Current
Output Voltage
Output Symmetry (Duty Cycle)
Output Load
Rise and Fall Time
Phase Jitter (12 KHz to 20 MHz)
Enable-Disable Function
Output Disable Time
Output Enable Time
Start Up Time
Temperature stability is Inclusive of all conditions:
Calibration Tolerance at +25°C, frequency stability over the operating temperature range, supply voltage,
supply voltage change, output load changes, shock, vilbration, and 1st year aging at +25°C.
Specification Title:
Clock Oscillator
Low Profile
5 x 3.2 millimeter Surface Mount
General Product Specification
11-3 Chien-Kuo Rd T.E.P.Z. 4027 Taiwan, ROC
All dimensions are millimeters.
CAD:
TCR
EG
Review:
JL
Appr:
Page:
1/4
Date:
Feb 7, 2008
Part Number:
S5 Series
www.aker-usa.com
How to build a Part Number:
Series
Package
S
5
50
33
25
18
10
05
03
025
02
See Notes
T
-
Frequency 0.500 to 156.000
-
Temperature Range
Packaging
See Notes
X
-
R
Tape and Reel
-10 to +70 ºC
-40 to +85 ºC
MHz
Parameter
3.2 x 5.0 mm
+5.0 Vdd ± 10%
+3.3 Vdd ± 5%
+2.5 Vdd ± 5%
+1.8 Vdd ± 5%
±100 PPM
±50 PPM
±30 PPM
±25 PPM
±20 PPM
40 / 60 %
45 / 55 %
Supply Voltage
Temperature Stability
Duty Cycle
Part Number Example:
S53310-155.520-X-R
S5: 3.2 x 5.0 mm SMD Package
33: +3.3 ± 5% Vdd Supply Voltage
10: ±100 PPM Temperature Stability
155.520 MHz Nominal Frequency
X: -40 to + 85° C Extended Temperature Range
R: Tape and Reel Packaging
Notes:
1- Standard Duty Cycle and Temperature Range do not need to be included in
Part Number description.
2- Product is shipped in Tape and Reel configuration. Each reel contains
1000 pieces.
3- Quantities less than 1000 are shipped bulk in ESD pouches.
4- Specification subject to change without notice.
Page:
4/4
Date:
Feb 7, 2008
P/N:
S5 Series
