SF503GP-BP

Description
Rectifier Diode, 1 Phase, 1 Element, 5A, 300V V(RRM), Silicon, DO-201AD, HERMETIC SEALED PACKAGE-2
CategoryDiscrete semiconductor    diode
File Size215KB，2 Pages
ManufacturerMicro Commercial Components (MCC)
Environmental Compliance
Download Datasheet Parametric Compare View All

SF503GP-BP Overview

Rectifier Diode, 1 Phase, 1 Element, 5A, 300V V(RRM), Silicon, DO-201AD, HERMETIC SEALED PACKAGE-2

SF503GP-BP Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerMicro Commercial Components (MCC)
Parts packaging codeDO-201AD
package instructionHERMETIC SEALED PACKAGE-2
Contacts2
Reach Compliance Codecompliant
ECCN codeEAR99
applicationSUPER FAST RECOVERY
Shell connectionISOLATED
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
JEDEC-95 codeDO-201AD
JESD-30 codeO-XALF-W2
JESD-609 codee3
Maximum non-repetitive peak forward current150 A
Number of components1
Phase1
Number of terminals2
Maximum output current5 A
Package body materialUNSPECIFIED
Package shapeROUND
Package formLONG FORM
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum repetitive peak reverse voltage300 V
Maximum reverse recovery time0.035 µs
surface mountNO
Terminal surfaceMATTE TIN
Terminal formWIRE
Terminal locationAXIAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Base Number Matches1

Preview

Download Datasheet
MCC
TM
Micro Commercial Components

omponents
20736 Marilla Street Chatsworth

  !"#
$ %   !"#
SF500 GP
thru
SF504 GP
5 Amp Surper Fast
Recovery Rectifiers
50 - 400Volts
DO-201AD
Features
•
•
•
•
Low forward voltage, high current capability
Hermetically sealed
High surge capability
Superfast recovery times-epitaxial construction
•
•
•
Maximum Ratings
Operating Temperature: -55°C to +150°C
Storage Temperature: -55°C to +150°C
Maximum Thermal Resistance;
25.0°C/W
Junction To Lead
Microsemi
Catalog
Number
Device
Marking
Maximum
Reccurrent
Peak
Reverse
Voltage
50V
100V
200V
300V
400V
Maximum
RMS
Voltage
Maximum
DC
Blocking
Voltage
50V
100V
200V
300V
400V
D
SF500GP SF500GP
SF501GP SF501GP
SF502GP SF502GP
SF503GP SF503GP
SF504GP SF504GP
35V
70V
140V
210V
280V
A
Cathode
Mark
B
Electrical Characteristics @ 25°C Unless Otherwise Specified
Average Forward
Current
Peak Forward Surge
Current
Maximum
Instantaneous
Forward Voltage
SF500~SF502
SF503~SF504
D
I
F(AV)
I
FSM
5.0A
150A
T
A
=
55°C
8.3ms, half sine
C
V
F
.95V
1.25V
5.0uA
300uA
I
FM
= 5.0A;
T
A
= 25°C*
T
A
= 25°C
T
A
= 125°C
Test Conditions
IF=.5A,IR=1A,Irr=.25A
DIM
A
B
C
D
DIMENSIONS
INCHES
MIN
.287
.189
.048
1.000
MM
MIN
7.30
4.80
1.20
25.40
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Maximum Reverse
Recovery Time
Typical Junction
Capacitance
I
R
MAX
.374
.208
.052
---
MAX
9.50
5.30
1.30
---
NOTE
T
rr
C
J
35nS
45pF
Measured at
1.0MHz, V
R
=4.0V
*Pulse test: Pulse width 300
µsec,
Duty cycle 2%
Revision: 3
www.mccsemi.com
2003/04/30
