MMT-128-01-FM-SH-005 datasheet, PDF

Datasheet> All Categories > The connector> The connector> MMT-128-01-FM-SH-005

MMT-128-01-FM-SH-005: DescriptionBoard Connector, 27 Contact(s), 1 Row(s), Male, Right Angle, Surface Mount Terminal,; CategoryThe connector The connector; File Size480KB，6 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/

Download Datasheet Parametric View All

MMT-128-01-FM-SH-005 Overview

Board Connector, 27 Contact(s), 1 Row(s), Male, Right Angle, Surface Mount Terminal,

MMT-128-01-FM-SH-005 Parametric

Parameter Name	Attribute value
Objectid	7342713316
Reach Compliance Code	compliant
ECCN code	EAR99
YTEOL	8.4
Other features	POLARIZED
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact completed and terminated	NOT APPLICABLE
Contact point gender	MALE
Contact material	NOT SPECIFIED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	2 mm
Termination type	SURFACE MOUNT
Total number of contacts	27
UL Flammability Code	94V-0

Preview

Download Datasheet

View All

REVISION DN

DO NOT

SCALE FROM

THIS PRINT

NOTES:

MMT-1XX-XX-XX-XX-XX-XXX-X-XX

REPRESENTS A CRITICAL DIMENSION.

2. MINIMUM PUSHOUT FORCE: 2 LB.

OPTION

3. FOR NON -LC & -A, USE 2TS-XX-D.

-TR: TAPE AND REEL

4. COPLANARITY TO INCLUDE INSULATOR.

No OF POSITIONS

(37 POSTION MAX)

5. MAXIMUM BURR ALLOWANCE: .002[0.05].

-02 THRU -50 (PER ROW)

(SEE SHT 5)

6. MAXIMUM CUT FLASH: .015[0.38]. (NO FLASH TO BE ON BOTTOM OF BODY).

PAD OPTION

7. -MT OPTION: PIN B TO BE FLUSH TO +/- .003" A LINE MADE BY THE BODY

-P: PICK & PLACE PAD

-DH OPTION: PIN A TO BE FLUSH TO .003" ABOVE A LINE MADE BY THE BODY

(USE PPP-13)

PIN B TO BE FLUSH TO .001" BELOW/.003" ABOVE A LINE MADE BY THE BODY

LEAD STYLE

(2 POSITION MINIMUM)

-SH OPTION: PIN A TO BE FLUSH TO +/- .003" A LINE MADE BY THE BODY.

-K: POLYIMIDE FILM PAD

-01: .126 [3.20] POST

C 8. ORIENTATE PINS TO REDUCE THE NUMBER OF BANDOLIER MARKS IN THE

(SEE FIG 14, SHT 6)

-02: .175 [4.45] POST

POST AREA. (SEE TABLE 4)

(3 POS MIN)

(SEE TABLE 2)

9. DUE TO THE HIGH AMOUNT OF INSERTION FORCE NEEDED. THE -LC

(USE K-DOT-.177-.281-.005)

OPTION IS NOT COMPATIBLE WITH AUTO PLACEMENT. SAMTEC

RECOMMENDS MANUAL PLACEMENTFOR ALL ASSEMBLIES WITH

OPTION

THE -LC OPTION.

PLATING SPECIFICATION

-XXX: POLARIZED POSITION

10. NOTE DELETED.

-H: 30µ" HEAVY GOLD IN CONTACT AREA,

-XXX SPECIFIES POSITION OMITTED

3µ" ON TAIL

(SEE POLARIZATION VIEW)

-S: 30µ" SELECTIVE GOLD IN CONTACT AREA,

MATTE IN ON TAIL

OPTION

(SEE NOTE 3)

-L: 10µ" LIGHT SELECTIVE GOLD IN CONTACT AREA,

-LC: LOCKING CLIP (SEE NOTE 9)

MATTE TIN ON TAIL

(FOR -DH USE 2TS-XX-DH-LC-XX)

-F: 3µ" FLASH SELECTIVE GOLD IN CONTACT AREA,

(FOR -SH USE 2TS-XX-SH)

MATTE TIN ON TAIL

(NOT AVAILABLE WITH -A)

-T: MATTE TIN CONTACT AND TAIL

-A: ALIGNMENT PIN

-SM: 30µ" SELECTIVE GOLD IN CONTACT AREA,

(FOR -DH USE 2TS-XX-DH-A-XX)

MATTE TIN ON TAIL

(FOR -SH USE 2TS-XX-SH-A-XX)

-LM: 10µ" LIGHT SELECTIVE GOLD IN CONTACT AREA,

(NOT AVAILABLE WITH -LC)

MATTE TIN ON TAIL

ROW OPTION

-FM: 3µ" FLASH SELECTIVE GOLD IN CONTACT AREA,

MATTE TIN ON TAIL.

-SH: SINGLE (2TS-XX-SH-X-XX)

-TM: MATTE TIN CONTACT AND TAIL

-DH: DOUBLE (2TS-XX-DH-XX-XX)

(NO. OF POS x .07874[2.0000])

+.005 [0.13]

- .010 [0.25]

-MT: MIXED TECHNOLOGY (2TS-XX-DH-XX-XX)

(NOT AVAILABLE WITH -LC, OR -A OPTIONS)

(NO OF POS - 1) x .07874[2.0000])

.003[0.08]

2 MAX SWAY

(EITHER DIRECTION)

.0787 2.000

.15748 4.0000

REF

2TS-XX-DH-XX-XX

.055 1.40

SEE NOTE 6

LC-06-TM

"C"

(SEE TABLE 2)

.0197 0.500 SQ

(TYP) REF

.11 2.8

.245±.010 6.22±0.254

SEE NOTE 5

.003 0.08 MAX

(SEE NOTE 7)

3°

SEE TABLE 5

(SEE NOTE 4)

THIS DOCUMENT CONTAINS CONFIDENTIAL AND

PROPRIETARY INFORMATION AND ALL DESIGN,

MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS

AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,

INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE

OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR

REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY

OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS

WRITTEN CONSENT OF SAMTEC, INC.

UNLESS OTHERWISE SPECIFIED,

DIMENSIONS ARE IN INCHES.

TOLERANCES ARE:

DECIMALS

PROPRIETARY NOTE

SEE NOTE 5

(NO. OF POS x .07874[2.0000]

- .15748[4.0000]) .003[0.08]

.XX: .01 [.3]

.XXX: .005 [.13]

.XXXX: .0020 [.051]

ANGLES

520 PARK EAST BLVD, NEW ALBANY, IN 47150

PHONE: 812-944-6733

FAX: 812-948-5047

e-Mail info@SMATEC.com

code 55322

DESCRIPTION:

MATERIAL:

DO NOT SCALE DRAWING

SHEET SCALE: 4:1

MMT-108-01-X-DH-LC SHOWN

FIG 1

INSULATOR: LCP VECTRA;

UL 94 V0;

COLOR: BLACK

TERMINAL: PHOS BRONZE

F:\DWG\MISC\MKTG\MMT-1XX-XX-XX-XX-XX-XXX-X-XX-MKT.SLDDRW

2mm HORIZONTAL TERMINAL SURFACE MOUNT STRIP ASSEM

DWG. NO.

MMT-1XX-XX-XX-XX-XX-XXX-X-XX

12/12/2000

SHEET

BY:

DEAN P
