D Subminiature
40 A High Power Straight — European PC Tails (Sizes DE-DC)
Receptacle
Part Numbers with Standoff #4-40 UNC
Shell Size
DE
DA
DA
DA
DA
DB
DB
DB
DB
DB
DC
DC
DC
DC
DC
DC
Layout
5W1
7W2
11W1
3W3
3WK3
5W5
9W4
13W3
17W2
21W1
8W8
13W6
17W5
21WA4
25W3
27W2
Part Number
Without Screw Locks
Without Boardlocks
DEMV5H1SYA197
DAMV7H2SYA197
DAMV11H1SYA197
DAMV3H3SYA197
DAMV3HK3SYA197TM
DBMV5H5SYA197
DBMV9H4SYA197
DBMV13H3SYA197
DBMV17H2SYA197
DBMV21H1SYA197
DCMV8H8SYA197
DCMV13H6SYA197
DCMV17H5SYA197
DCMV21HA4SYA197
DCMV25H3SYA197
DCMV27H2SYA197
Part Number
Without Screw Locks
With Boardlocks
DEMZ5H1SYA197
DAMZ7H2SYA197
DAMZ11H1SYA197
DAMZ3H3SYA197
DAMZ3HK3SYA197TM
DBMZ5H5SYA197
DBMZ9H4SYA197
DBMZ13H3SYA197
DBMZ17H2SYA197
DBMZ21H1SYA197
DCMZ8H8SYA197
DCMZ13H6SYA197
DCMZ17H5SYA197
DCMZ21HA4SYA197
DCMZ25H3SYA197
DCMZ27H2SYA197
Combo D
Reader’s Resource
For contact cavity arrangements,
see page 223.
For P.C. hole patterns, see pages 257-258.
For panel cutouts, see page 221.
Part Number
With Screw Locks
With Boardlocks
DEMN5H1SYA197
DAMN7H2SYA197
DAMN11H1SYA197
DAMN3H3SYA197
DAMN3HK3SYA197TM
DBMN5H5SYA197
DBMN9H4SYA197
DBMN13H3SYA197
DBMN17H2SYA197
DBMN21H1SYA197
DCMN8H8SYA197
DCMN13H6SYA197
DCMN17H5SYA197
DCMN21HA4SYA197
DCMN25H3SYA197
DCMN27H2SYA197
For M3 threads replace MV with MT, MZ with MQ, MN with MU.
Notes: For performance class 2 substitute K126 for A197. Example: DEMV5H1SYK126
For DD shell sizes, see page 73.
Keyed.
Engaging Face
A
C
B
E
D
10°
BOARDLOCK
4,65
(.183)
Ø 3,18
(.125)
Ø 0,60
(.024)
4,52 (.178)
2,84
(.112)
7,62
±
0,25
(.300
±
.010)
2,92
(.115)
STANDOFF
#4-40 UNC
L
F
W
6,50
±
0,25
(.256
±
.010)
SCREW LOCK
#4-40 UNC
Screw lock, boardlock, and high power contact
removed for clarity
Dimensions
Shell Size
DE
DA
DB
DC
A
±0,38
(.015)
30,81 (1.213)
39,14 (1.541)
53,04 (2.088)
69,32 (2.729)
B
±0,13
(.005)
16,33 (.643)
24,66 (.971)
38,38 (1.511)
54,84 (2.159)
C
±0,13
(.005)
24,99 (.984)
33,32 (1.312)
47,04 (1.852)
63,50 (2.500)
D
±0,13
(.005)
7,90 (.311)
7,90 (.311)
7,90 (.311)
7,90 (.311)
E
±0,38
(.015)
12,55 (.494)
12,55 (.494)
12,55 (.494)
12,55 (.494)
F
±0,25
(.010)
10,90 (.429)
10,90 (.429)
10,90 (.429)
10,90 (.429)
W
±0,38
(.015)
6,94 (.273)
6,94 (.273)
6,94 (.273)
6,94 (.273)
L
±0,25
(.010)
0,76 (.030)
0,76 (.030)
0,76 (.030)
0,76 (.030)
Dimensions are shown in mm (inch)
Dimensions subject to change
71
