NTC Disc Thermistors
ND 03/06/09 • NE 03/06/09 • NV 06/09
APPLICATIONS
• Commodity Product: 2 families
ND or NE : general purpose
NV : professional
• Alarm and temperature measurement application
• Temperature regulation application
• Level detection application
• Compensation application
TECHNOLOGY
• ND: epoxy-phenolic resin coating
NE: epoxy resin coating (recommended for severe
mounting conditions)
NV: epoxy varnish coating
• Leads: Radial copper wire tinned
• Marking: on package only for ND03 & NE03
ND/NE 06/09:Nominal resistance and tolerance for
±5%, ±10%
NV06/09:
Nominal resistance and tolerance
• Delivery Mode: Bulk, reeled or ammopacked
Leaded Discs
N.03
N.06
N.09
PERFORMANCE CHARACTERISTICS
Types
ND03 or NE03
Climatic category
Operating Temperature
Tolerance on Rn
(25°C)
–55 to +150°C
330Ω to 1MΩ : ±
5, 10, 20%
1500Ω to 150 kΩ : ±
3%
0.25 W
5 mW/°C
10 s
< 3s
General purpose
ND06 or NE06
–55 to +150°C
±5%, ±10%, ±20%
Professional
ND09 or NE09
–55 to +150°C
±5%, ±10%, ±20%
NV06
55/125/56-434
–55 to +150°C
±2%, ±5%, ±10%
NV09
55/125/56-434
–55 to +150°C
±2%, ±5%, ±10%
Maximum dissipation
at 25°C
Thermal dissipation
factor
Thermal time constant
Response time
0.71 W
7.1 mW/°C
22 s
0.9 W
9 mW/°C
30 s
0.69 W
6.9 mW/°C
18 s
0.85 W
8.5 mW/°C
30 s
STANDARDIZATION
NV range : approved by NFC 93271
Type: TN115 A for NV06
TN116 for NV09
List: GAM-T1
List: LNZ
OPTIONS
Consult factory for availability of options:
• other nominal resistance values
• other tolerances
• alternative lead materials or lengths
• controlled dimensions
21
NTC Disc Thermistors
Packaging for Automatic Insertion
PACKAGING AND KINK SUFFIXES
Tables below indicate the suffixes to specify when ordering to
get the required kink and packaging. For devices on tape, it
is necessary to specify the height (H or Ho) which is the
distance between the tape axis (sprocket holes axis) and
the seating plane on the printed circuit board. The following
types can be ordered on tape either in AMMOPACK
(fan folder) or on REEL in accordance with IEC 286-2.
– Straight leads:
H
represents the distance between the sprocket holes axis
and the bottom plane of component body (base of resin or
base of stand off).
– Kinked leads and flat leads:
Ho
represents the distance between the sprocket holes
axis and the base on the knee (kinked leads) or the bottom
of the flat part (flat leads).
• Reel & Ammopack
millimeters (inches)
Types
ND/NE
03
&
NJ28
Suffix
CA
CB
CC
CD
H or Ho
16
(0.630
16
(0.630
19.5
(0.768
19.5
(0.768
16
(0.630
16
(0.630
19.5
(0.768
19.5
(0.768
16
(0.630
16
(0.630
19.5
(0.768
19.5
(0.768
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
0.5
0.020)
0.5
0.020)
0.5
0.020)
0.5
0.020)
0.5
0.020)
0.5
0.020)
0.5
0.020)
0.5
0.020)
0.5
0.020)
0.5)
0.020)
0.5
0.020)
0.5
0.020)
Leads
Straight
Straight
Straight
Straight
Straight
Straight
Straight
Straight
Kinked
Kinked
Kinked
Kinked
Quantity/Size
3000
3000
3000
3000
1500
1500
1500
1500
1500
1500
1500
1500
Packaging
AMMOPACK
REEL
AMMOPACK
REEL
AMMOPACK
REEL
AMMOPACK
REEL
AMMOPACK
REEL
AMMOPACK
REEL
NTC
Type
ND03
NE03
NJ28
H
ND/NE/NV
06/09
DA
DB
DC
DD
DL
DM
DN
DP
2.54 (0.10)
NTC
Types
ND/NE/NV
06/09
H
Ho
5.08 (0.20)
• Bulk
Type
ND/NE03
ND/NE06
ND/NE09
NV06
NV09
NI24
NJ28
NK20
Quantity/box
3000
1500
1500
100
100
1000
HOW TO ORDER
ND06
P0
0103
K
––
Type
Material Code
P
Resistance
10 kΩ
Tolerance
K (±10%)
Packaging
Bulk
25
