L
0.18-0.12
0.18-0.12
B
2 Places
Label 1
A
0.019m max
Connector(s): SC-Duplex
Mode: MM
Housing Color: Beige
Geom. Spec: N/A
Number of Fibers: 2
Mode: MM
Jacket Diameter:
3.0 mm
Jacket Color: Orange
FiberType: 62.5/125
Connector(s): ST
Mode: MM
Housing Color: N/A
Geom. Spec: N/A
A
B
-
-
B
A
SC and FC 3.0mm Boot
Color: Beige/Beige
ST Short 3.0 mm
Color: Beige/Beige
Notes:
1 Includes dust caps (not shown on print).
2 Trace label centered on cable assembly for 1-504958-4
Cable Assy Configurator
-
-
Tyco Electronics, Inc.
Harrisburg, PA 17105-3608
meters
Cable Assy Configurator
-
-
-
-
-
Refer to Engineering Change
CE
M
Rev Per EC#
OA40-0576-04
11/12/2004
-
FO C/A - 2 fiber, 3mm, 62.5/125, OFNR (Riser) jacket, SC-Duplex
to ST
16
CAC Customer Layout Rev: D
Customer Print
NTS
A2
C- 504958
1 of 2
M
SC-Duplex, Beige
Part #
0-504958-1
0-504958-2
0-504958-3
0-504958-4
0-504958-5
0-504958-6
0-504958-7
0-504958-8
0-504958-9
1-504958-0
1-504958-1
1-504958-2
1-504958-3
1-504958-4
1-504958-5
1-504958-6
2-504958-5
3-504958-0
L (meters)
0.950 - 1.050
1.950 - 2.050
2.950 - 3.050
4.920 - 5.080
9.850 - 10.150
14.850 - 15.150
19.800 - 20.200
5.920 - 6.080
6.920 - 7.080
7.920 - 8.080
10.850 - 11.150
12.850 - 13.150
2.388 - 2.488
0.300 - 0.360
3.920 - 4.080
90.527 - 92.356
24.750 - 25.250
29.700 - 30.300
IL
(dB)
0.50
0.50
0.50
0.51
0.52
0.52
0.53
0.51
0.51
0.51
0.52
0.52
0.50
0.50
0.51
0.64
0.54
0.55
RL
(dB)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
IL
ST
(dB)
0.50
0.50
0.50
0.51
0.52
0.52
0.53
0.51
0.51
0.51
0.52
0.52
0.50
0.50
0.51
0.64
0.54
0.55
RL
(dB)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Label 1
Per specification 107-1645-1
Trace # - Bar Code
XXXXXXXXXXXXXXX
Tyco logo
Made in XXXX
X-XXXXXXX-X
Trace # - Human Readable
Part Number
Country of Origin
This label is used on all lengths on this drawing.
Cable Assy Configurator
-
-
Tyco Electronics, Inc.
Harrisburg, PA 17105-3608
meters
Cable Assy Configurator
-
-
-
-
-
Refer to Engineering Change
CE
M
Rev Per EC#
OA40-0576-04
11/12/2004
-
FO C/A - 2 fiber, 3mm, 62.5/125, OFNR (Riser) jacket, SC-Duplex
to ST
16
CAC Customer Layout Rev: D
Customer Print
NTS
A2
C- 504958
2 of 2
M
