138-4696-001 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 138-4696-001

138-4696-001: Descriptionconn N plug str 50 ohm solder; CategoryThe connector; File Size3MB，24 Pages; ManufacturerAll Sensors; Environmental Compliance

Download Datasheet Parametric View All

138-4696-001 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	138-4696-001	-	-	View	Buy Now

138-4696-001 Overview

conn N plug str 50 ohm solder

138-4696-001 Parametric

Parameter Name	Attribute value
Datasheets
N Type Connectors Catalog
138-4696-001/007 Drawing
Product Photos
138-4696-001
Standard Package	25
Category	Connectors, Interconnects
Family	Coaxial Connectors (RF)
Packaging	Bulk
Connector Style	N Type
Connector Type	Plug, Male Pi
Contact Terminati	Solde
Shield Terminati	Solde
Impedance	50 Ohm
Mounting Type	Free Hanging (In-Line)
Cable Grou	RG-401 (.250" Semi Rigid)
Fastening Type	Threaded
Frequency - Max	18GHz
Features	-
Housing Col	Silve
Ingress Protecti	-
Body Material	Brass
Body Finish	Gold
Center Contact Material	Brass
Center Contact Plating	Gold
Dielectric Material	Polytetrafluoroethylene (PTFE)
Voltage Rating	1000V
Operating Temperature	-65°C ~ 165°C
Other Names	J854

Preview

Download Datasheet

View All

Connectivity....for

Business-Critical Continuity

Type N Connectors

Product Catalog

Connectivity....for

Business-Critical Continuity

Type N Connectors

ELECTRICAL SPECIFICATIONS

Impedance:

50 Ohms

Frequency Range:

Flexible Cabled and Receptacles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0-11 GHz

Semi-Rigid Cabled and Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0-18 GHz

VSWR:

(f = GHz)

Straight Flexible Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

0-9 GHz

1.35 MAX

0-11 GHz

1.07+.01f

1.05+.01f

1.06+.01f

1.15+.02f

1.10+.02f

0-11 GHz

1.30 Max

9-11 GHz

1.50 Max

11-18 GHz

<1.25 Typical

<1.50 Typical

0-18 GHz

1.05+.01f

N/A

Right Angle Flexible Cabled. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RG-405 Semi-Rigid Plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RG-402 Semi-Rigid Plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RG-401 Semi-Rigid Plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RG-405 Semi-Rigid Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RG-402 Semi-Rigid Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RG-401 Semi-Rigid Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Un-cabled Receptacles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Insertion Loss:

(dB, tested at 9 GHz)

Straight Flexible Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.15 Max

Right Angle Flexible Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.30 Max

Semi-Rigid Cabled and Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.05 f (GHz)

Un-cabled Receptacles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . N/A

Working Voltage:

(Vrms maximum)

Sea Level

RG-316, 316DS Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250

RG-58, 142, 405 Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335

RG-402 Cabled. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500

RG-213, 214, 401, LMR-400 Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000

Un-cabled Receptacles and Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000

Dielectric Withstanding Voltage:

(Vrms minimum)

Sea Level

750

RG-316, 316DS Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

RG-58, 142, 405 Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000

RG-402 Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1500

RG-213, 214, 401, LMR-400 Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2500

Un-cabled Receptacles and Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2500

Corona Level:

(Volts minimum)

70K Feet

RG-316, 316DS Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190

RG-58, 142, 405 Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250

RG-402 Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 375

RG-213, 214, 401, LMR-400 Cabled and Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500

Un-cabled Receptacles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . N/A

70K Feet

125

250

Type N Connectors

Connectivity....for

Business-Critical Continuity

ELECTRICAL SPECIFICATIONS cont’d

RF High Potential Withstanding Voltage:

(Vrms minimum, tested at 4 and 7 MHz)

RG-316, 316DS Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500

RG-58, 142, 405 Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 670

RG-402 Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000

RG-213, 214, 401, LMR-400 Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1500

Un-cabled Receptacles and Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1500

Insulation Resistance:

5000 Megohms minimum

Contact Resistance:

(milliohms maximum)

Initial

Center Contact

Straight Cabled (non-captivated) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0

Straight Cabled (captivated) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.5

Right Angle Cabled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.5

Un-cabled Receptacles and Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0

Outer Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.2

Braid to Body (Flexible Cabled Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.05

RF Leakage:

(dB minimum, tested at 2.5 GHz)

Cabled Connectors and Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -90

Un-cabled Receptacles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . N/A

IMP3:

Typically <-90 dBm (tested per IEC Guidelines using 20W inputs swept over 1930-1990 MHz)

After Environmental

1.5

3.0

1.5

N/A

Type N In-Series Adapter Return Loss

138-4901-807

-10

138-4901-817

VSWR = 1.05+.01F

-20

-30

S11 (dB)

-40

-50

-60

Frequency (GHz)
