598-8080-102F datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> 598-8080-102F

598-8080-102F: DescriptionSingle Color LED, Green, Water Clear, 1.1mm, 1.60 X 0.80 MM, 0.70 MM HEIGHT, ROHS COMPLIANT, SMD, 2 PIN; CategoryLED optoelectronic/LED photoelectric; File Size1MB，2 Pages; ManufacturerDIALIGHT; Websitehttps://www.dialight.com; Environmental Compliance

Download Datasheet Parametric Compare View All

598-8080-102F Overview

Single Color LED, Green, Water Clear, 1.1mm, 1.60 X 0.80 MM, 0.70 MM HEIGHT, ROHS COMPLIANT, SMD, 2 PIN

598-8080-102F Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	DIALIGHT
package instruction	1.60 X 0.80 MM, 0.70 MM HEIGHT, ROHS COMPLIANT, SMD, 2 PIN
Reach Compliance Code	compliant
color	GREEN
color@wavelength	Green
Configuration	SINGLE
Maximum forward current	0.025 A
Maximum forward voltage	3.5 V
JESD-609 code	e4
Lens type	WATER CLEAR
Nominal luminous intensity	220.0 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
Optoelectronic device types	SINGLE COLOR LED
total height	0.7 mm
method of packing	TAPE
Maximum reverse voltage	5 V
shape	RECTANGULAR
size	1.1 mm
surface mount	YES
Terminal surface	Nickel/Gold (Ni/Au)
Terminal pitch	1.6 mm
perspective	140 deg
Base Number Matches	1

Preview

Download Datasheet

View All

FEATURES / BENEFITS

Compatible with automatic placement equipment

Micro LED

SMD LED

“598 SERIES” 0603 PACKAGE

(1.6mm X 0.8mm X 0.7mm) Single Color

RoHS compliant

Packaged in 8mm tape, 7” reel and 20 per strip

Meets EIA-481-1 pkg. std.

Package Outline Drawing:

ORDERING INFORMATION

Notes 1. All dimensions are in mm [inches];

2. Tolerances are ±0.1mm [0.004inch] unless noted.

20 pieces on tape

7” reel 4000pcs / reel

PART NUMBERS

DIALIGHT P/N

EMITTED COLOR

MATERIAL

LUMINOUS

INTENSITY

If = 20 ma

MIN TYP

MAX

Water Clear 30

LENS

COLOR

Water Clear 120

Water Clear

Water Clear 100

Water Clear

150

130

220

300

140

200

150

160

300

400

140

160

DOMINANT

WAVELENGTH

If = 20 ma

MIN

TYP

MAX

630

635

642

620

600

590

583

570

562

520

470

625

523

473

630

610

595

590

575

570

525

475

FORWARD

VOLTAGE

If = 20 ma

MIN

TYP

MAX

1.7

2.2

2.4

1.7

1.8

2.8

3.2

2.4

2.2

2.4

3.5

VIEWING

ANGLE

° DEGREES

140

598-8010-107F

598-8020-107F

598-8030-107F

598-8040-107F

598-8050-107F

598-8060-107F

598-8070-107F

598-8080-107F

598-8081-107F

598-8090-107F

598-8091-107F

RED

RED-ORANGE

ORANGE

YELLOW

YELLOW-GREEN

GREEN

BLUE

AlInGaP

GaP

InGaN

Water Clear 150

Water Clear 220

Water Clear

ABSOLUTE RATINGS

(@ Ta = 25ºC)

DIALIGHT P/N

Power

Dissipation

(mW)

598-8010-107F

598-8020-107F

598-8030-107F

598-8040-107F

598-8050-107F

598-8060-107F

598-8070-107F

598-8080-107F

598-8081-107F

598-8090-107F

598-8091-107F

87.5

Forward

Current

(mA)

Reverse

Voltage

(V)

Operating

Temperature

Range

(ºC)

-30~+85

Storage

Temperature

Range

(ºC)

-40~+100

Peak Pulse

Forward

Current

(mA)

100

Electrostatic

Discharge

(HBM)

2000

1000

2000

1000

Dialight Corporation

1501 Route 34 South • Farmingdale, NJ 07727 USA

Tel: (1) 732-919-3119 • Fax: (1) 732-751-5778 • www.dialight.com

MDEI5980603_A
