3 Watt
o Wide Input Range
o Regulated Outputs
o Single & Dual Outputs
o Efficiency up to 80%
24 Pin DIL Package V
2:1 Input Range
o Short Circuit Protection - Power Fold Back
o Option 3000 VDC I/O-Isolation (With Remote Control)
o Option Conductive EMI/RFI Meet EN55022 Class B add Suffix „B“
o Option SMD-Case add Suffix "S" (see separate data sheet)
MODEL NUMBER
3VRS5W3.3LC*
3VRS5W5LC*
3VRS5W12LC*
3VRS5W15LC*
3VRD5W5LC*
3VRD5W12LC*
3VRD5W15LC*
3VRS12W3.3LC
3VRS12W5LC
3VRS12W12LC
3VRS12W15LC
3VRD12W5LC
3VRD12W12LC
3VRD12W15LC
3VRS24W3.3LC
3VRS24W5LC
3VRS24W12LC
3VRS24W15LC
3VRD24W5LC
3VRD24W12LC
3VRD24W15LC
3VRS48W3.3LC
3VRS48W5LC
3VRS48W12LC
3VRS48W15LC
3VRD48W5LC
3VRD48W12LC
3VRD48W15LC
*Suffix "B" not available
last up-date 27.01.2005
INPUT VOLTAGE
OUTPUT
VOLTAGE
3.3 VDC
5 VDC
12 VDC
OUTPUT
CURRENT
600 mA
600 mA
INPUT CURRENT
% EFF
NO LOAD
FULL LOAD
619 mA
850 mA
15 mA
800 mA
64
70
75
70
75
70
73
78
73
78
73
74
80
74
80
71
76
80
76
78
250 mA
200 mA
±300 mA
±125 mA
±100 mA
600 mA
600 mA
7.5 mA
250 mA
320 mA
200 mA
±300 mA
±125 mA
±100 mA
600 mA
600 mA
5 mA
250 mA
156 mA
200 mA
±300 mA
±125 mA
±100 mA
600 mA
600 mA
250 mA
200 mA
±300 mA
±125 mA
±100 mA
3 mA
80 mA
82 mA
2 mA
78 mA
3 mA
58 mA
82 mA
7.5 mA
156 mA
168 mA
113 mA
168 mA
12 mA
320 mA
340 mA
236 mA
340 mA
25 mA
800 mA
850 mA
4.5-6 VDC
15 VDC
±5 VDC
±12 VDC
±15 VDC
3.3 VDC
5 VDC
12 VDC
9-18 VDC
15 VDC
±5 VDC
±12 VDC
±15 VDC
3.3 VDC
5 VDC
12 VDC
18-36 VDC
15 VDC
±5 VDC
±12 VDC
±15 VDC
3.3 VDC
5 VDC
12 VDC
36-72 VDC
15 VDC
±5 VDC
±12 VDC
±15 VDC
3 Watt - 24 Pin DIL - Package V - 2:1 Input Range
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
INPUT SPECIFICATIONS
Input Voltage Range
Input Filter
2/3
2:1
Pi Type
OUTPUT SPECIFICATIONS
Voltage Accuracy
Voltage Balance, Dual Output
Temperature Coefficient
Ripple and Noise, 20MHz BW
Short Circuit Protection
Line Regulation
1)
Load Regulation
1) Measured from High Line to Low Line.
2) Measured from Full Load to 10% Load.
3) Measured from Full Load to 1/4 Load.
±2%max.
±1%max.
±0.05%/°C
3.3V, 5V
12V, 15V
100 mV p-p max.
1% p-p max.
Continuous
±0.5%
Single
2)
Dual
3)
±0.5%
±1.0%
GENERAL SPECIFICATION
Efficiency
Isolation Voltage
Suffix "H"
4)
Suffix "B"
Suffix "HBR"
Isolation Resistance
Switching Frequency
Operating Temperature Range
Case Temperature
Storage Temperature Range
Derating
Cooling
Humidity Non-Condensing
Weight
Case Material
Case Dimensions
Suffix "M"
5)
see table
500 VDC min.
3000 VDC min.
Option EMI/RFI EN55022 Class B
3KVDC + EN55022 Class B
+ Remote
Ctlr.
1000 Mohms
100 kHz min.
-25°C to +71°C
(Plastic Case)
(Copper Case)
+95°C max.
+100°C max.
-40°C to +100°C
-3.5%/°C
Free-Air Convection
20-95% RH
0.5 OZ (16.2 grams)
Non-Conductive Black Plastic
Standard 1.25 x 0.8 x 0.4 Inches (31.8 x 20.3 x 10.2 mm)
Suffix "B"+"HBR" 1.25 x 0.8 x 0.5 Inches (31.8 x 20.3 x 12.7 mm)
Black Coated Copper with Non-Conductive Base
1.186.000 hrs min.
MTBF (MIL-HDBK-217F)
4) Non-Conductive Black Plastic only
5) Suffix "HM" 1.5 KVDC instead of 3 KVDC Isolation
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
vertrieb@mrmultitronik.de
3 Watt - 24 Pin DIL - Package V - 2:1 Input Range
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
3/3
MECHANICAL SPECIFICATIONS
CASE "V"
PIN
1 & 24
2 & 23
3 & 22
9 & 16
10 & 15
11 & 14
12 & 13
PIN CONNECTIONS 500VDC
SINGLE
+INPUT
NC*
NC*
NO PIN
-OUTPUT
+OUTPUT
-INPUT
DUAL
+INPUT
-OUTPUT
COMMON
NO PIN
COMMON
+OUTPUT
-INPUT
* Option "NO Pin" at Single Output add Suffix "NP"
to Part No.
PIN CONNECTIONS 1.5 KVDC & 3KVDC
PIN
1 & 24
2&3
5
9
REMOTE ON/OFF CONTROL
Logic Compatibility
Ec-ON
Ec-OFF
Shutdown Idle Current
Control Common
CMOS or Open Collector TTL
>+5.5VDC or Open Circuit
<1.8VDC
10mA
Referenced to Input Minus
SINGLE
NO PIN
-INPUT
NP
NC*
NC*
NC
NO PIN
+OUTPUT
-OUTPUT
+INPUT
DUAL
NO PIN
-INPUT
NP
COMMON
NC*
-OUTPUT
NO PIN
+OUTPUT
COMMON
+INPUT
10 & 15
11
12 & 13
14
16
22 & 23
PIN 5 = Remote Control at Suffix "HBR"
*) Option "NO PIN" add Suffix "NP" to Part-No.
N O T I C E:
The information in this document has been carefully checked. However, no responsibility is assumed for inaccuracies!
Specifications can be changed without notice. The latest and most complete information can be found on our website.
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
vertrieb@mrmultitronik.de
