DDTA
(R1-ONLY SERIES)
E
PNP PRE-BIASED SMALL SIGNAL SURFACE MOUNT TRANSISTOR
Features
•
•
•
•
•
Epitaxial Planar Die Construction
Complementary NPN Types Available (DDTC)
Built-In Biasing Resistor, R1 only
Lead Free/RoHS Compliant (Note 2)
"Green" Device (Note 3 and 4)
B
G
H
K
M
A
C
TOP VIEW
E
B C
NEW P R ODUC T
SOT-523
Dim
A
B
C
Min
0.15
0.75
1.45
⎯
0.90
1.50
0.00
0.60
0.10
0.10
0.45
0°
Max
0.30
0.85
1.75
⎯
1.10
1.70
0.10
0.80
0.30
0.20
0.65
8°
Typ
0.22
0.80
1.60
0.50
1.00
1.60
0.05
0.75
0.22
0.12
0.50
⎯
Mechanical Data
•
•
•
•
•
•
•
•
•
Case: SOT-523
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020C
Terminals: Solderable per MIL-STD-202, Method 208
Lead Free Plating (Matte Tin Finish annealed over
Alloy 42 leadframe).
Terminal Connections: See Diagram
Marking & Date Code Information: See Diagrams
& Page 4
Ordering Information: See Page 4
Weight: 0.002 grams (approximate)
N
D
G
J
D
L
H
J
K
L
M
R
1
P/N
DDTA113TE
DDTA123TE
DDTA143TE
DDTA114TE
DDTA124TE
DDTA144TE
DDTA115TE
DDTA125TE
R1 (NOM)
1KΩ
2.2KΩ
4.7KΩ
10KΩ
22KΩ
47KΩ
100KΩ
200KΩ
MARKING
P01
P03
P07
P12
P16
P19
P23
P25
@T
A
= 25°C unless otherwise specified
Symbol
V
CBO
V
CEO
V
EBO
I
C
(Max)
P
d
(Note 1)
R
θ
JA
T
j
, T
STG
C
N
α
B
All Dimensions in mm
E
SCHEMATIC DIAGRAM
Maximum Ratings
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Power Dissipation
Characteristic
Value
-50
-50
-5
-100
150
833
-55 to +150
Unit
V
V
V
mA
mW
°C/W
°C
Thermal Resistance, Junction to Ambient Air
Operating and Storage Temperature Range
Notes:
1. Mounted on FR4 PC Board with recommended pad layout as shown on Diodes Inc., suggested pad layout document AP02001, which can be found on
our website at http://www.diodes.com/datasheets/ap02001.pdf
2. No purposefully added lead.
3. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
4. Product manufactured with Date Code UO (week 40, 2007) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code UO are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
DS30319 Rev. 6 - 2
1 of 4
www.diodes.com
DDTA (R1-ONLY SERIES) E
© Diodes Incorporated
Electrical Characteristics
Characteristic
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
@T
A
= 25°C unless otherwise specified
Symbol
BV
CBO
BV
CEO
BV
EBO
I
CBO
I
EBO
Min
-50
-50
-5
⎯
⎯
Typ
⎯
⎯
⎯
⎯
⎯
Max
⎯
⎯
⎯
-0.5
-0.5
Unit
V
V
V
μA
μA
I
C
= -50μA
I
C
= -1mA
I
E
= -50μA
V
CB
= -50V
V
EB
= -4V
I
C/
I
B
= -10mA/-1mA
I
C/
I
B
= -5mA/-0.5mA
I
C/
I
B
= -2.5mA/-.25mA
I
C/
I
B
= -1mA/-.1mA
I
C/
I
B
= -5mA/-0.5mA
I
C/
I
B
= -2.5mA/-.25mA
I
C/
I
B
= -1mA/-0.1mA
I
C/
I
B
= -.5mA/-.05mA
I
C
= -1mA, V
CE
= -5V
V
CE
= -10V, I
E
= 5mA,
f = 100MHz
DDTA113TE
DDTA123TE
DDTA143TE
DDTA114TE
DDTA124TE
DDTA144TE
DDTA115TE
DDTA125TE
Test Condition
NEW PRODUCT
Emitter-Base Breakdown Voltage
Collector Cutoff Current
Emitter Cutoff Current
Collector-Emitter Saturation Voltage
V
CE(sat)
⎯
⎯
-0.3
V
DC Current Transfer Ratio
Gain-Bandwidth Product*
* Transistor - For Reference Only
h
FE
f
T
100
⎯
250
250
600
⎯
⎯
MHz
DS30319 Rev. 6 - 2
2 of 4
www.diodes.com
DDTA (R1-ONLY SERIES) E
© Diodes Incorporated
Typical Curves – DDTA114TE
V
CE(SAT)
, MAXIMUM COLLECTOR VOLTAGE (V)
250
P
d
, POWER DISSIPATION (MILLIWATTS)
1
I
C
/I
B
= 10
200
0.1
75
°
C
25
°
C
-25
°
C
NEW PRODUCT
150
100
0.01
50
0
-50
0
50
100
150
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 1 Derating Curve
0.001
0
10
20
30
40
50
I
C
, COLLECTOR CURRENT (mA)
Fig. 2 V
CE(SAT)
vs. I
C
12
I
E
= 0V
1,000
hFE, DC CURRENT GAIN (NORMALIZED)
10
C
OB
, CAPACITANCE (pF)
100
8
6
10
4
2
0
1
1
10
I
C
, COLLECTOR CURRENT (mA)
Fig. 3 DC Current Gain
100
0
5
10
15
20
25
30
V
R
, REVERSE BIAS VOLTAGE (V)
Fig. 4 Output Capacitance
100
10
V
O
= 0.2
I
C
, COLLECTOR CURRENT (mA)
10
1
V
in
, INPUT VOLTAGE (V)
0
1
2
3
4
5
6
7
8
9
10
1
0.1
0.01
0.001
0
0
10
20
30
40
50
V
in
, INPUT VOLTAGE (V)
Fig. 5 Collector Current vs. Input Voltage
I
C
, COLLECTOR CURRENT (mA)
Fig. 6 Input Voltage vs. Collector Current
DS30319 Rev. 6 - 2
3 of 4
www.diodes.com
DDTA (R1-ONLY SERIES) E
© Diodes Incorporated
Ordering Information
(Note 5)
Device
DDTA113TE-7-F
DDTA123TE-7-F
DDTA143TE-7-F
DDTA114TE-7-F
DDTA124TE-7-F
DDTA144TE-7-F
DDTA115TE-7-F
DDTA125TE-7-F
Notes:
NEW PRODUCT
Packaging
SOT-523
SOT-523
SOT-523
SOT-523
SOT-523
SOT-523
SOT-523
SOT-523
Shipping
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
5. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
XXXYM
XXX = Product Type Marking Code (See Page 1, e.g. P01 = DDTA113TE)
YM = Date Code Marking
Y = Year ex: T = 2006
M = Month ex: 9 = September
Date Code Key
Year
Code
Month
Code
2006
T
Jan
1
Feb
2
2007
U
Mar
3
Apr
4
2008
V
May
5
Jun
6
2009
W
Jul
7
2010
X
Aug
8
Sep
9
2011
Y
Oct
O
Nov
N
2012
Z
Dec
D
IMPORTANT NOTICE
Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes
without further notice to any product herein. Diodes Incorporated does not assume any liability arising out of the application or use of any product
described herein; neither does it convey any license under its patent rights, nor the rights of others. The user of products in such applications shall
assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on our website,
harmless against all damages.
LIFE SUPPORT
Diodes Incorporated products are not authorized for use as critical components in life support devices or systems without the expressed written
approval of the President of Diodes Incorporated.
DS30319 Rev. 6 - 2
4 of 4
www.diodes.com
DDTA (R1-ONLY SERIES) E
© Diodes Incorporated
