DTA124 EM/EE/EUA/ECA/ESA
PNP Small Signal Transistor
Small Signal Product
Features
◇Built-in
bias resistors enable the configuration of an inverter
circuit without connecting external input resistor
(see equivalent circuit)
◇The
bias resistors consist of thin-film resistors with
complete isolation to allow negative biasing of the input.
They also have the advantage of almost completely
eliminating parasitic effects.
◇Only
the on/off conditions need to be set for
operation, marking device design easy.
◇Green
compound (Halogen free) with suffix "G" on
packing code and prefix "G" on date code.
Equivalent Circuit
Ordering Information (example)
Part No.
DTA124 EM
Package
SOT-723
Packing
8K / 7" Reel
Packing code
RM
Packing code
(Green)
RMG
Marking
15
Manufacture code
M0
Note : Detail please see "Ordering Information(detail, example)" below.
Maximum Ratings and Electrical Characteristics
Rating at 25
o
C ambient temperature unless otherwise specified.
Maximum Ratings
Parameter
Power Dissipation
Supply Voltage
Input Voltage
Output Current
Junction and Storage Temperature Range
Symbol
P
D
V
CC
V
IN
I
O
T
J
, T
STG
Value
EM
100
EE
150
-50
-40 ~ +10
-30
- 55 to + 150
EUA
200
ECA
ESA
300
Units
mW
V
V
mA
o
C
Note 1：Valid provided that electrodes are kept at ambient temperature
Electrical Characteristics
Parameter
Input Voltage
Output Voltage
Input Current
Output Current
DC Current Gain
Input Resistance
Resistance Ratio
Transition Frequency
Symbol
V
I(off)
V
I(on)
V
O(on)
I
I
I
O(off)
G
I
R1
R
2
/R
1
f
T
Min
-0.5
Typ
Max
-3
-0.3
-0.36
-0.5
Condtion
V
CC
= -5V, I
O
= -100μA
V
O
= -0.2V, I
O
= -5mA
I
O
/ I
I
= -10mA / -0.5mA
V
I
=-5V
V
CC
= -50V, V
I
=0
V
O
= -5V, I
O
= -5mA
Units
V
V
mA
μA
KΩ
56
15.4
0.8
22
1
250
28.6
1.2
V
O
= -10V,I
O
= -5mA, f=100MHz
MHz
Version：C13
Small Signal Product
Ordering information (Detail, example)
Part No.
DTA124 EM
DTA124 EE
DTA124 EUA
DTA124 ECA
DTA124 ESA
DTA124 EM
DTA124 EE
DTA124 EUA
DTA124 ECA
DTA124 ESA
Package
SOT-723
SOT-523
SOT-323
SOT-23
TO-92S
SOT-723
SOT-523
SOT-323
SOT-23
TO-92S
Packing
8K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
8K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
Packing code
RM
RN
RV
RU
A3
RM
RN
RV
RU
A3
Packing code
(Green)
RMG
RNG
RVG
RUG
A3G
RMG
RNG
RVG
RUG
A3G
15
15
15
15
M0
M0
M0
M0
M0
Marking
15
15
15
15
Manufacture code
(Note)
Note : Manufacture special control, if empty means no special control requirement.
Dimensions
TO-92S
DIM.
A
B
C
D
E
F
G
Unit(mm)
Min
3.90
3.05
15.10
0.35
1.42
0.66
0.36
Max
4.10
3.25
15.50
0.48
1.62
0.86
0.51
Unit(inch)
Min
0.15
0.12
0.59
0.01
0.06
0.03
0.01
Max
0.16
0.13
0.61
0.02
0.06
0.03
0.02
Version：C13
