Corcom Product Guide
Dual Configuration Power Entry Module
Catalog: 1654001
Issue Date: 06.2011
L Series
UL Recognized
CSA Certified
VDE Approved
EDL4C / EHL4C
EDL1S / EHL1S
L Series
• Power entry module with switch or fuse
• For 10A capability and high performance filtering
see the P Series on page 192
• Two element circuit provides extended EMI
attenuation similar to EAB inlet filter
• North American or metric fuse holders
• Available with minimal leakage current for medical
applications (HL models)
Specifications
Maximum leakage current each Line to Ground:
DL Models
HL Models
@ 120 VAC 60 Hz:
.25 mA
2
A
@ 250 VAC 50 Hz:
.50 mA
5
A
Hipot rating (one minute):
Line to Ground:
Line to Line:
Operating Voltage:
1S & 1SC models (fixed):
4 & 4C Suffix:
Operating Frequency:
Rated Current:
Required Fuse(s):
North American:
Metric:
Switch:
2250 VDC
1450 VDC
250 VAC max.
100, 120, 220 or 240 VAC.
50/60 Hz
2 to 6A
one .25 x 1.25”
(not included)
two 5 x 20mm
(not included)
3
Power Inlet Filters & Power Entry Modules
Ordering Information
6EDL1SCM
Fuseholder Type
(pre-installed)
M – Metric
Omit for North American
Mounting Type
C– Snap-In
Omit for flange mount
Switch Option
S – DPST on/off switch
Omit for none
Voltage Selection Positions
1 or 4
L Series
Filter Type
D – General Purpose
H – Medical
omit for none
Leakage current designation
E – Low Leakage
(<0.5 mA)
Current Rating
2, 4 or 6A
DPST
10,000 operations at 51A max. inrush
175
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Corcom Product Guide
Dual Configuration Power Entry Module
(continued)
Catalog: 1654001
Issue Date: 06.2011
L Series
North American Fusing
Metric Fusing
Available Part Numbers
Flange Mount
Single Voltage,
Switched
Non-Filtered
4 Voltage Select,
No Switch
Snap-In
Flange Mount
Snap-In
6EL1S
6EL4
2EDL1S
6EL1SC
6EL4C
2EDL1SC
4EDL1SC
6EDL1SC
2EDL4C
4EDL4C
6EDL4C
6EHL1SC
6EHL4C
6EL1SM
6EL4M
2EDL1SM
4EDL1SM
6EDL1SM
2EDL4M
4EDL4M
6EDL4M
6EHL1SM
6EHL4M
6EL1SCM
6EL4CM
2EDL1SCM
4EDL1SCM
6EDL1SCM
2EDL4CM
4EDL4CM
6EDL4CM
6EHL1SCM
6EHL4CM
Single Voltage,
Switched
4EDL1S
6EDL1S
General
Purpose Filter
2EDL4
4 Voltage Select,
No Switch
4EDL4
6EDL4
Single Voltage,
Switched
Medical Filter
4 Voltage Select,
No Switch
6EHL1S
6EHL4
Voltage Selection
Recommended Panel Cutouts
.06 R
1.52
(1)
(3)
(3)
2.201
*
55.91
2.213*
56.21
(2)
(4)
.020
R
.508
1.122
*
28.50
1.575
(3)
40.00
*
+.008 -.00
+.203 -.00
To change selected voltage: disconnect the power
cord; open cover using a small blade screwdriver or
similar tool; insert the tool into the voltage selection
slot and remove wheel from unit; select desired
voltage; replace wheel into unit and close cover,
making sure the selected voltage appears in
connector window.
½
½
½
176
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Corcom Product Guide
Dual Configuration Power Entry Module
(continued)
Catalog: 1654001
Issue Date: 06.2011
L Series
Electrical Schematics
DL Models
Single Voltage, Switched (DL1S)
Note 1
Neutral
Ground
Hot
G
Note 2
H On/O
2
(1)
(2)
4
1
(1a)
(2a)
3
Accessories
GA400: NEMA 5-15P to IEC 60320-1 C-13 line cord
Customer
Transformer
Primaries
Device
LA303: Voltage Select Wheel, 3 position
Selection drum for use with L4 models.
Marked with 110V, 220V and 240V
4 Voltage Select, No-Switch (DL4)
Customer
120V
100V
220V
Transformer
240V
Primaries
LA304: Voltage Select Wheel, 4 position
Selection drum for use with L4 models.
Marked with 100V, 110V, 220V and 240V.
One LA304 comes standard with each L4 model.
Hot
Note 1
G
Note 2
On/O
A
B
C
D
E
A
B
C
D
E
F
A
20V
3
Power Inlet Filters & Power Entry Modules
B
100V
Ground
C
D
E
F
120V
Neutral
F
H
HL Models
Single Voltage, Switched (HL1S)
Customer
Note 1
Neutral
Ground
Hot
G
Note 2
H On/O
2
(1)
(2)
4
1
(1a)
(2a)
3
LA400: Blank insert
Blank to replace switch in single voltage models
LA601: Insulating Boot
Plastic shroud to cover back of module to prevent
inadvertent access
Device
Transformer
Primaries
4 Voltage Select, No-Switch (HL4)
120V
100V
Replacement Fuse Holders
LA200: North American Fuseholder
Accommodates one .25 x 1.25” fuse
LA201: Metric Fuseholder
Accommodates one 5 x 20mm metric fuse
120V
Customer
Transformer
220V
240V
Primaries
A
B
C
D
E
F
A
20V
Hot
Note 1
G
Note 2
On/O
A
B
C
D
E
B
100V
Ground
C
D
E
F
Neutral
F
H
½
177
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Corcom Product Guide
Dual Configuration Power Entry Module
(continued)
Catalog: 1654001
Issue Date: 06.2011
L Series
Case Styles
Flange Models, Non-filtered
3
1
4
2
Snap-in Models, Non-filtered
A
B
G
C
D
H
E
F
G
H
C D
C D
F
B
A
.221
5.61
E
F
A
.221
5.61
E
½
½
½
½
½
½
Flange Models, Filtered
3
1
4
2
Snap-in Models, Filtered
A
B
G
C
D
H
E
F
G
H
C D
C D
F
B
A
.221
5.61
E
F
A
.221
5.61
E
½
½
½
½
½
½
Case Dimensions
A
Model No.
Flange
Unfiltered
Snap-in
Unfiltered
Flange
Filtered
Snap-in
Filtered
½
B
C
½
D
½
E
½
F
178
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Corcom Product Guide
Dual Configuration Power Entry Module
(continued)
Catalog: 1654001
Issue Date: 06.2011
L Series
Performance Data
Typical Insertion Loss
Measured in closed 50 Ohm system
2EDL
db
100
90
80
70
60
50
40
30
20
10
0
0.1
1
10
30
Frequency in MHz
4EDL
db
100
90
80
70
60
50
40
30
20
10
0
0.1
1
10
30
Frequency in MHz
6EDL
db
100
90
80
70
60
50
40
30
20
10
0
0.1
1
10
30
Frequency in MHz
6EHL
db
100
90
80
70
60
50
40
30
20
10
0
0.1
1
10
30
Frequency in MHz
3
Power Inlet Filters & Power Entry Modules
Common Mode / Asymmetrical (L-G)
Differential Mode / Symmetrical (L-L)
Minimum Insertion Loss
Measured in closed 50 Ohm system
Common Mode / Asymmetrical (Line to Ground)
Differential Mode / Symmetrical (Line to Line)
179
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
