fischer
connectors
4032 Series
Plastic connectors
M
EDICAL
P
ORTABLE
E
QUIPMENT
D
ATA
A
CQUISITION
H
IGH
-P
ERFORMANCE
V
ERSATILE
P
ACKAGE
I
NSTRUMENTATION
IN A
PERFECT PACKAGE
www.fischerconnectors.com
S E R I E S
F
EATURES
4032
B
ENEFITS
Patient-worn medical devices
Diagnostic equipment
Marine applications
Entertainment equipment
2 - 19 contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . High signal density
14.5 mm diameter plug . . . . . . . . . . . . . . . . . . . . . . Ideal for miniature equipment
Gold-plated contacts (greater than 1
µm)
. . . . . . . . Highly reliable signal path
Greater than 5000 mating cycles . . . . . . . . . . . . . . . Minimizes end product warranty claims
IP68 sealing available (submersible) . . . . . . . . . . . . Ideal for exterior applications
60% lighter than equivalent metal models . . . . . . . . Minimizes total product weight
Fischer
®
-pioneered keying system . . . . . . . . . . . . . . Facilitates easy operation and eliminates
contact damage
Insulated construction . . . . . . . . . . . . . . . . . . . . . . . Ideal for IEC 60601-1 applications
Disposable versions available . . . . . . . . . . . . . . . . . High reliability for cost-sensitive applications
SureGrip
TM
plastic housing . . . . . . . . . . . . . . . . . . . . Promotes user and patient safety
Color keying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Easy identification of multiple connectors
A
PPLICATIONS
Disposable medical equipment
Hand-held instrumentation
Data acquisition equipment
Surgical hand tools
Bar code readers
Medical catheters
Portable field equipment
Meteorological instrumentation
2
Connectors and Accessories
IP65
or IP
Rated 68
(Max. cap nut torque: 0.4 Nm)
All dimensions shown are in millimeters and are for reference only
SI
• Cable Plug
• Sealed to IP65 or IP68
• Color-coded back nut permits easy identification
• Accepts cable diameters 2.2 – 6.7 mm (0.09 – 0.26 in.)
• See cable clamps on page 5
IP65
Rated
IP68
Rated
(In Preparation)
(Max. mounting nut torque: 1.0 Nm)
DBP
• Chassis Receptacle
• Sealed to IP65 when mated
• Color-coded mounting nut permits easy identification
Maximum panel
thickness = 4.0 mm
(Max. mounting nut torque: 1.0 Nm)
DBPO
• Same as DBP, except with sealing to panel and mating
plug
• Sealed to IP68 when mated
• Color-coded mounting nut permits easy identification
Sealing Cap - Plug
Part Number: 4032.703
• Integral o-ring seals and protects
plug when unmated
• Supplied with 150 mm PTFE
coated stainless steel lanyard
and hardware
• Material: POM (Delrin
®
)
Sealing Cap - Receptacle
Part Number: 4032.701
• Integral o-ring seals and protects
receptacle when unmated
• Supplied with 150 mm PTFE
coated stainless steel lanyard
and hardware
• Material: POM (Delrin
®
)
Nut Driver
Part Number: TH00.001
• Use for easy assembly of DBP
and DBPO to panel
3
Standard Contact Configurations
Number of
Designation
Contacts
4032 A051
4032 Z 051
4032 A052
4032 Z 052
4032 A053
4032 Z 053
4032 A054
4032 Z 054
4032 A056
4032 Z 056
4032 A057
4032 Z 057
4032 A010
4032 Z 010
4032 A012
4032 Z 012
4032 A019
4032 Z 019
1
Test
Maximum Current
2
Contact Wire Barrel
1
Voltage
per
o
Contact
o
(A)
Diameter Diameter
(kVAC)
20 C
40 C
2.2
1.5
1.6
1.4
1.3
1.3
1.5
1.5
0.9
10
8.9
4.6
4.4
3.3
3.3
2.3
2.2
1.0
14.1
12.6
6.5
6.2
4.6
4.6
3.3
3.2
1.5
2
AWG
20
20
22
22
26
26
26
26
28
Insulator
Material
PEEK
PEEK
PEEK
PEEK
PEEK
PEEK
PEEK
PEEK
PEEK
Available
Contact Styles
3
J, L
J, L
J, L
J, K, L
J, K, L
J, K, L
J, K, L
J, K, L
J, K, L
2
3
4
5
6
7
10
12
19
1.3
1.3
0.9
0.9
0.7
0.7
0.7
0.7
0.5
1.2
1.2
0.8
0.8
0.6
0.6
0.6
0.6
0.4
3
www.fischerconnectors.com
per IEC 512-2, 4a
per IEC 512-3, 5a
J = Solder; K = Crimp; L = PCB
Materials
Component
Bodies, Cap Nut, Mounting Nut
Metal Parts (except contacts)
Contacts
Contact Block
O-rings
Plastic Cable Clamps
4
Material
PBT
Brass
Male: Brass
Male: Bronze
Female: Bronze
Female: Bronze
PEEK
NBR
POM (Delrin
®
)
5
Plating
–
3
µm
Nickel
5
Minimum 1
µm
Gold
4
on 4
µmNickel
5
–
–
–
similar to MIL-C26074E
Solder:
Crimp:
per AMS2422D or ASTMB488
Performance
Operating Temperature Range
Mechanical Endurance
Cable Mounted
Radiation Resistance
Autoclaveability
–65°C to +135°C
5000 mating cycles
10
8
Rad
Maximum of 50 mating cycles
Maximum of 50 cycles
4
Part Numbers
Connectors
Body Style
Series
Contact
Polarity
Contact
Configuration
Body
Material
Insulator
Material
Contact
Style
Color
1
Coding
Bend Relief
Material
SI
DBP
Plug
Receptacle,
rear panel
mounted.
Receptacle,
rear panel
mounted,
sealed
when
mated
(IP68).
1
A
DBPO
4032
Z
Plugs
have pins.
Receptacles
have sockets.
Plugs
have sockets.
Receptacles
have pins.
J
See page 4
Solder
Crimp
PCB
D
PBT
3
PEEK
K
L
www.fischerconnectors.com
1
2
3
4
5
6
7
White
Black
Green
Blue
Yellow
Red
Grey
R
T
None
TPE
2
Plug: Cap nut
Receptacle: Mounting nut
2
Future availability
Cable Clamps
Plastic
Cable O.D. (mm)
2.2 – 3.7
3.7 – 5.2
5.2 – 6.7
3
3
Sealed
Cable O.D. (mm)
2.2 – 2.7
2.7 – 3.2
3.2 – 3.7
3.7 – 4.2
4.2 – 4.7
4.7 – 5.2
5.2 – 5.7
5.7 – 6.2
6.2 – 6.7
4
4
Part Number
4032.1003
4032.1002
4032.1001
Part Number
E3 1031.2/2.7
E3 1031.2/3.2
E3 1031.2/3.7
E3 1031.2/4.2
E3 1031.2/4.7
E3 1031.2/5.2
E3 1031.2/5.7
E3 1031.2/6.2
E3 1031.2/6.7
For unshielded applications
For use when sealing shielded or
unshielded cable to plug body
5
