• Applicable PC board thickness: 0.6 to 1.2mm,1.6mm
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
The ZH connector is very small with a
mounting height of 5.6mm and a thickness
of only 3.5mm. Contact retention lances on
the housing make insertion easier, while
the dimple at the center of the contact
ensures reliable contact with the post.
• Compact, low profile design
• Housing lances
• Reliable contact construction
• Distortion resistant construction
• Compatible with the ZR insulation
displacement connectors
Standards ––––––––––––––––––––––
1
Certified LR20812
3.5
0
Recognized E60389
PC board layout and Assembly layout
〈
Through-hole type (viewed from soldering side)
〉
Top entry type
1.5
±
0.05
1.5min
2.2min
Side entry type
1.5
±0.05
1.5min
7.1
4.6min
5.6
φ0.7
±
0.03
2.7
（3.4）
4.6
φ0.7
±0.03
Note: 1. Tolerances are non-cumulative:
±
0.05mm for all centers.
2. Hole dimension differ according to the kind of PC board and piercing method. If PC boards made of hard material are used, the hole dimensions should
be larger. The dimensions above should serve as a guideline. Contact JST for details.
〈
SMT type (viewed from component side)
〉
SM2 type
Side entry type
1.5 × (N-1)＋ 0.9
± 0.05
0.7min 1.5
0.9
±0.05
SM4 type
Top entry type
1.3
±0.1
1.5
±0.05
1.5
±0.1
0.6
3.7
2.0min
（7.4）
0.7
min
3.7
φ1.1
＋ 0.1
0
2.5max
Side entry type
1.5
1.4
±0.05
±0.1
1.1
±0.1
2.3
±0.1
（6.4）
2.0
（7.4）
1.9
±0.1
4.3
Note: 1. N...Number of circuits
2. Tolerances are non-cumulative:
±
0.05mm for all centers.
3. The dimensions above should serve as a guideline. Contact JST for details.
0.7
min
1
1.4
±0.1
3.7
2.7
（3.4）
3.7
ZH CONNECTOR
Contact
4.0
2.2
0.5
1.0
1.4
1.1
Model No.
SZH-002T-P0.5
SZH-003T-P0.5
mm
2
0.08 ∼0.13
0.032∼0.08
Applicable wire
AWG#
Insulation O.D. (mm)
28∼26
32∼28
0.8∼1.1
0.5∼0.9
Q'ty /
reel
13,000
16,000
Material and Finish
1.5
Phosphor bronze, tin-plated (reflow treatment)
RoHS compliance
0.3
Contact
SZH-002T-P0.5
Crimping
machine Crimp applicator
AP-K2N
MKS-L
―
Applicator
Dies
MK/SZH-002-05
―
Crimp applicator with dies
APLMK SZH002-05
―
Contact
SZH-003T-P0.5
Crimping
machine Crimp applicator
AP-K2N
MKS-L
*MKS-SC
Applicator
Dies
MK/SZH-003-05
SC/SZH-003-05
Crimp applicator with dies
APLMK SZH003-05
APLSC SZH003-05
Note: *Strip-crimp applicator.
Housing
Circuits
2
B
1.5
1.5
0.3
A
3.4
Model No.
ZHR-2
ZHR-3
ZHR-4
ZHR-5
ZHR-6
ZHR-6(3.0)
ZHR-7
ZHR-8
ZHR-9
ZHR-10
ZHR-11
ZHR-12
ZHR-13
A
Dimensions (mm)
B
4.5
6.0
7.5
9.0
10.5
18.0
12.0
13.5
15.0
16.5
18.0
19.5
21.0
Q'ty /
bag
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1.5
3.0
4.5
6.0
7.5
15.0
9.0
10.5
12.0
13.5
15.0
16.5
18.0
3
4
5
6
6
4.2
0.3
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
ZHR-2-oo-
(blank)…natural (white)
K…black R…red E…blue M…green L…lemon yellow
LE…light blue DO…dark orange H…gray
Through-hole type shrouded header
Top entry type
(2 circuits)
B
3.5
(3 circuits or more)
B
3.5
4.5
4.5
2.7
Note)
3.4
2.7
Note)
3.4
A 1.5
2.2
Side entry type
B
2.4
3.7
φ0.5
A
1.5
1.5
4.6
1.4
2.7
Note)
3.4
6
φ0.5
A
1.5
1.5
2.2
5
3
2
1
H JST
7
8
9
10
11
12
13
Material
PA 66, UL94V-0, natural (white)
RoHS compliance
Note: 1. ZHR-6(3.0) is 6 circuits 3.0mm pitch plugged up.
