03 = Solder Tail for .094 to .125 [2.39 to 3.18] Thick Board
TS-0774-H
Sheet 3 of 3
3
Electronic Solutions Division
Interconnect Solutions
http://www.3Mconnectors.com
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M
™
Four-Wall Condo Header
3M
×
™
Three-Wall Header
.100” .100” Right Angle
.100” × .100” Latch/Ejector, Straight and Right Angle
Polarizing Post
.318
[8.08]
.100 Dia
[2.54]
Note: Insert Post into one mounting hardware hole on
bottom of header. Set post to protrude .115” [2.92]
3000 Series
3000 Series
3 2 0 1 -4
3 2 0 1 -5
LCP
PBT
B la c k
G ra y
Polarizing Keys
Dim A
N3518
3518
LCP
PBT
Blac k
Gray
.02
.02
Breakaway Tab
.34 Ref
[8.6]
.15
[3.8]
A
.09
[2.3]
Note: #2216 B/A Scotchweld can be used to adhere keys.
Mounting Hardware
3341-5
(Installed from bottom of board)
3341-6
(Must be inserted prior to latch on
vertical headers)
.31
[7.9]
.50
[12.7]
Panhead Thread Cutting Screw:
#4-24 X 5/16”
Type: USA Std BT, Federal BG
Hex Head Bolt, Nut and Washer
Bolt - #2-56 X 1/2”
3341-5 & 6
Material - Stainless Steel
Not for use with Condo headers.
TS-0774-H
TS-0771-E
Sheet 4 of 3
Sheet 5 of 5
3
Electronic Solutions Division
Electronic Solutions Division
Interconnect Solutions
Interconnect Solutions
http://www.3Mconnectors.com
http://www.3Mconnector.com
3M is a trademark of 3M Company.
For technical,
3M is a trademark
information call
sales or ordering
of 3M Company.
For technical, sales or ordering information call
800-225-5373
800-225-5373
