REVISIONS
REV.
A
ECO. NO
2002
DESCRIPTION
INITIAL RELEASE
DATE
7/17/2009
BY
JH
F
F
E
0.30±0.05 .012±.002
A±0.10[.004]
1.25±0.10 .049±.004
FRONT
VIEW
E
BACK
VIEW
D
0.50±0.05 .020±.002
RECOMMENDED PCB LAYOUT
1.25±0.10 .049±.004
A±0.20[.008]
D
B±0.25[.010]
3.20±0.25 .126±.010
C
C
4.70±0.25 .185±.010
4.20±0.20 .165±.008
CIRCUIT 1
B
2.30±0.20 .091±.008
0.30±0.05 .012±.002
B
A
NOTES:
1. INSULATOR MATERIAL: NYLON6T, UL94V-0, COLOR:BEIGE.
2. CONTACT MATERIAL: PHOSPHOR BRONZE.
3. CONTACT PLATING: TIN OVERALL.
4. CURRENT RATING: 1 AMP.
5. VOLTAGE RATING: 125V AC/DC.
6. INSULATOR RESISTANCE: 100 MEGOHMS MIN.
7. CONTACT RESISTANCE: 20 MILLIOHMS MAX.
8. DIELECTRIC WITHSTANDING VOLTAGE: 500V AC.
9. OPERATING TEMPERATURE: -25° C TO +85° C.
10. MATES WITH SWH120 SERIES SINGLE ROW HOUSING.
8
7
6
5
Pb
R
oHS COMPLIANT
4
DIMENSIONS ARE IN MM[INCHES]
TOLERANCES:
ANGULAR: 5
.X= .3 [.01]
.XX= .15 [.006]
.XXX= .050 [.0020]
SURFACE FINISH: 63 Ra
UNLESS OTHERWISE SPECIFIED:
DRAWN
DATE
NAME
7/30/2009
JH
REMOVE ALL BURRS AND SHARP EDGES .010 MAX
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
DESCRIPTION
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
PART NUMBER
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
WAFER, 1.25mm CC, 1 ROW, RA
A
SWR120-NPEG-S_ _-RA-BG
SIZE DWG. NO.
INTERPRET DIMENSIONS AND GEOMETRIC
TOLERANCING
PER: ANSI Y14.5M-1994
3
2
SCALE: 10:1
1
C
REV
11293
A
SHEET 1 OF 1
FILE NAME: Z:\ECO PENDING\2002, wafer 120 series\11293, SWR120-NPEG-S_ _-RA-BG PRINT: 9/23/2009
