THERMAL SENSORS / CIRCUIT PROTECTORS
TECHNOLOGY OF TOMORROW
THERMAL SENSORS
LINEAR PTC, MELF
MLT
L
D
Lacquer
STRUCTURE
1
2
3
4
5
6
Ceramic rod
Metal film
Cap (iron solder plated)
Trimming cut
Protective coating
Marking
D
Cap
3
5
6
2
4
1
C
IDENTIFICATION
PRODUCT CODE
MLT
COATING COLOR
Grey
MARKING
Color code, 3 bands
TYPE DESIGNATION (HOW TO ORDER)
Old Part No.
New Part No.
MLT
MLT
PRODUCT CODE
T.C.R.
(ppm/K)
3600
2B
2B
STYLE
J
L
RESISTANCE
TOLERANCE
TERMINATION
SURFACE MATERIAL
T: Sn
L: Sn/Pb
T
TE
TAPING*
*Please see “PACKAGING”
100R
101
NOMINAL
RESISTANCE
3 digits
J
RESISTANCE
TOLERANCE
3600
T.C.R.
(ppm/K)
FEATURES
■
■
■
■
■
■
■
Cylindrical linear PTC, metal film resistor
Excellent solderability and high electrode strength
Superior in the linearity of resistance change to temperature
25 specific temperature coefficients
Rated ambient temperature: + 70° C
Operating temperature range: – 40° C ... + 125° C
Suitable for reflow and wave soldering
DIMENSIONS (mm)
SIZE
0204
0207
TYPE
MLT 2B
MLT 2E
L ± 0.2
3.5
5.9
C
min
0.5
0.5
∅
D
CAP
1.45 ± 0.1
2.20 ± 0.1
∅
D
LACQUER
MAX.
1.55
2.40
Min.
1.45
2.25
RATING
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
SIZE
TYPE
T.C.R.
150 • 250 • 350 • 450 • 500 ppm/K
600 • 700 ppm/K
800 • 900 ppm/K
1000 • 1200 • 1400 ppm/K
1600 • 1800 ppm/K
2000 • 2200 • 2400 ppm/K
2600 • 2800 ppm/K
3000 • 3300 ppm/K
3600 ppm/K
3900 ppm/K
4200 ppm/K
4500 ppm/K
150 • 250 • 350 • 450 • 500 ppm/K
600 • 700 ppm/K
800 • 900 ppm/K
1000 • 1200 • 1400 ppm/K
1600 • 1800 ppm/K
2000 • 2200 • 2400 ppm/K
2600 • 2800 ppm/K
3000 • 3300 ppm/K
3600 ppm/K
3900 ppm/K
4200 ppm/K
4500 ppm/K
T.C.R.
TOLERANCE
± 100 ppm/K
± 150 ppm/K
± 15%
POWER
RATING
MAX.
WORKING
VOLTAGE
MAX.
OVERLOAD
VOLTAGE
RESISTANCE RANGE
E24 • G (±2%)
510
Ω
... 51 kΩ
––
––
––
––
––
––
––
––
––
––
––
1 kΩ ... 100 kΩ
––
––
––
––
––
––
––
––
––
––
––
E24 • J (±5%)
––
1 kΩ ... 43 kΩ
2 kΩ ... 43 kΩ
3 kΩ ... 27 kΩ
1 kΩ ... 10 kΩ
820
Ω
... 9.1 kΩ
820
Ω
... 6.2 kΩ
10
Ω
... 5.1 kΩ
10
Ω*
... 5.1 kΩ
10
Ω*
... 3.3 kΩ
10
Ω*
... 680
Ω
10
Ω*
... 330
Ω
––
2 kΩ ... 82 kΩ
3.9 kΩ ... 82 kΩ
6.2 kΩ ... 51 kΩ
3 kΩ ... 27 kΩ
1 kΩ ... 22 kΩ
1 kΩ ... 18 kΩ
10
Ω
... 7.5 kΩ
10
Ω*
... 7.5 kΩ
10
Ω*
... 6.2 kΩ
10
Ω*
... 1.3 kΩ
10
Ω*
... 680
Ω
0204
MLT 2B
0.125 W
150 V
300 V
± 10%
± 100 ppm/K
± 150 ppm/K
± 15%
0.25 W
250 V
500 V
0207
MLT 2E
± 10%
* Values below < 10
Ω
on request
EUROPE GmbH • Kaddenbusch 6 • D-25578 Dägeling / ITZEHOE • PHONE: +49 (0) 48 21 / 89 89-0 • FAX: +49 (0) 48 21/ 89 89 89 • Internet: www.koaeurope.de
