Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) 2-row | Plug
connectors, THR solder connection | S2L-SMT 3.5/90 | S2L-SMT 3.5/90G Box
System parameters
Electric shock protection to DIN VDE 0470
Material data
Insulating material
Colour
colour chart
Insulating material group
Flammability class UL 94
CTI
Contact base material
Contact surface
Constant operating temp., min.
Constant operating temp., max.
Storage temperature, min.
Storage temperature, max.
Max. relative humidity during storage
DIN IEC rating data
Rated current, min. No. pins (Tu=20°C)
Rated current, max. No. pins (Tu=20°C)
Rated current, min. No. pins(Tu=40°C)
Rated current, max. No. pins (Tu=40°C)
Rated voltage for overvoltage class/pollution
severity III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
Rated voltage for overvoltage class/pollution
severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated voltage for overvoltage class/pollution
severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Short-time withstand current resistance
CSA rating data
Rated voltage (Use group D)
Rated current (Use group D)
UL 1059 rating data
Rated voltage (Use group D)
Rated current (Use group D)
Approvals
Approvals institutes
Safe from back-of-hand touch
LCP GF
black
Similar to RAL 9011
IIIb
V-0
>= 175
Copper alloy
tinned
-25 °C
100
-25 °C
55 °C
93 %
10 A
10 A
9A
8.5 A
50 V
2.5 kV
125 V
1.5 kV
160 V
1.5 kV
3 x 1s with 77 A
50 V
5A
150 V
10 A
-2-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) 2-row | Plug
connectors, THR solder connection | S2L-SMT 3.5/90 | S2L-SMT 3.5/90G Box
Classifications
ETIM 2.0
ETIM 3.0
eClass 4.1
eClass 5.0
eClass 5.1
NK
EC001284
27-26-07-01
27-26-07-01
27-26-07-01
Similar products
Order No.
1920850000
1794210000
1794220000
1794230000
1794240000
1794250000
1794260000
1794270000
1794280000
1794290000
1794300000
1794320000
1794330000
1794340000
1794350000
1794360000
Part designation
S2L-SMT3.5/4/90G SN
S2L-SMT3.5/6/90G SN
S2L-SMT3.5/8/90G SN
S2L-SMT3.5/10/90G SN
S2L-SMT3.5/12/90G SN
S2L-SMT3.5/14/90G SN
S2L-SMT3.5/16/90G SN
S2L-SMT3.5/18/90G SN
S2L-SMT3.5/20/90G SN
S2L-SMT3.5/22/90G SN
S2L-SMT3.5/24/90G SN
S2L-SMT3.5/28/90G SN
S2L-SMT3.5/30/90G SN
S2L-SMT3.5/32/90G SN
S2L-SMT3.5/34/90G SN
S2L-SMT3.5/36/90G SN
Version
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 4, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 6, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 8, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 10, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 12, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 14, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 16, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 18, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 20, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 22, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 24, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 28, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 30, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 32, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 34, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 36, 90°, Box
