Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) 2-row | Plug
connectors, THR solder connection | S2L-SMT 3.5/90 | S2L-SMT 3.5/90LF Box
Material data
Constant operating temp., min.
Constant operating temp., max.
Storage temperature, min.
Storage temperature, max.
Max. relative humidity during storage
DIN IEC rating data
Rated current, min. No. pins (Tu=20°C)
Rated current, max. No. pins (Tu=20°C)
Rated current, min. No. pins(Tu=40°C)
Rated current, max. No. pins (Tu=40°C)
Rated voltage for overvoltage class/pollution
severity III/3
Rated impulse withstand voltage for overvoltage
class/pollution severity III/3
Rated voltage for overvoltage class/pollution
severity III/2
Rated impulse withstand voltage for overvoltage
class/pollution severity III/2
Rated voltage for overvoltage class/pollution
severity II/2
Rated impulse withstand voltage for overvoltage
class/pollution severity II/2
Short-time withstand current resistance
CSA rating data
Rated voltage (Use group D)
Rated current (Use group D)
UL 1059 rating data
Rated voltage (Use group D)
Rated current (Use group D)
Approvals
Approvals institutes
-25 °C
100
-25 °C
55 °C
93 %
10 A
10 A
9A
8.5 A
50 V
2.5 kV
125 V
1.5 kV
160 V
1.5 kV
3 x 1s with 77 A
50 V
5A
150 V
10 A
Downloads
CAD Library (P-CAD Format - Standard)
Classifications
ETIM 2.0
ETIM 3.0
eClass 4.1
eClass 5.0
eClass 5.1
S2L-SMT.LIB
NK
EC001284
27-26-07-01
27-26-07-01
27-26-07-01
-2-
Product catalogue | PCB connection systems | PCB plug-in connectors | Pitch 3.50 mm (0.138 inch) 2-row | Plug
connectors, THR solder connection | S2L-SMT 3.5/90 | S2L-SMT 3.5/90LF Box
Similar products
Order No.
1001300000
1794860000
1794870000
1794880000
1794890000
1794900000
1794910000
1794920000
1794930000
1794940000
1794950000
1794960000
1794970000
1794980000
1794990000
1795010000
Part designation
S2L-SMT3.5/04/90LF3.2SN SW
S2L-SMT3.5/6/90LF3.2SN
S2L-SMT3.5/8/90LF3.2SN
S2L-SMT3.5/10/90LF3.2SN
S2L-SMT3.5/12/90LF3.2SN
S2L-SMT3.5/14/90LF3.2SN
S2L-SMT3.5/16/90LF3.2SN
S2L-SMT3.5/18/90LF3.2SN
S2L-SMT3.5/20/90LF3.2SN
S2L-SMT3.5/22/90LF3.2SN
S2L-SMT3.5/24/90LF3.2SN
S2L-SMT3.5/26/90LF3.2SN
S2L-SMT3.5/28/90LF3.2SN
S2L-SMT3.5/30/90LF3.2SN
S2L-SMT3.5/32/90LF3.2SN
S2L-SMT3.5/36/90LF3.2SN
Version
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 4, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 6, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 8, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 10, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 12, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 14, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 16, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 18, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 20, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 22, 90°, Tape
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 24, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 26, 90°, Tape
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 28, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 30, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 32, 90°, Box
PCB plug-in connector, Male connectors, Reflow solder connection,
Pitch: 3.50 mm, No. of poles: 36, 90°, Box
